Page 21: Introduction
Section 2 Introduction This manual describes the installation and use of PURBlue 4 adhesive melters. When necessary, the reader is referred to the documentation supplied with other Nordson products or products supplied by third parties. Part 1107607A E 2011 Nordson Corporation...
Page 22: Other Sources Of Information
Refer to the following additional resources for quick-reference information, technical support, and information about getting the most out of your PURBlue 4 melter. Online Support Visit www.enordson.com/support to download melter firmware updates and Blue Series software utilities. Part 1107607A E 2011 Nordson Corporation...
Page 23: Product Description
Product Description See Figure 2-1. Nordson PURBlue 4 adhesive melters are used in conjunction with Nordson hot melt hoses and guns to create a hot melt application system. The melter liquifies solid-form hot melt in foil bags and maintains the hot melt at the desired temperature.
Page 24: Intended Use
(EVA), and polyolefine (PO) adhesives, that are engineered to be liquified and extruded at temperatures at or below 125 _C (257 _F) Be used with compatible hot melt hoses and guns that are manufactured by Nordson Corporation Be used in non-explosive environments Limitations of Use Use PURBlue 4 melters only for the purpose for which they are designed.
Page 25: Modes Of Operation
Melter Faults in Section 6, Troubleshooting. Manual and gear-to-line—The melter allows you to manually set the adhesive output rate or the melter can automatically adjust the adhesive output based on production requirements. Part 1107607A E 2011 Nordson Corporation...
Page 26: Pressure Control Options
PCV is set to maximum and the entire output of the pump is delivered through the applicator. This allows for consistent, metered adhesive application because the hydraulic pressure is consistent in both the applicator-open and applicator-closed states. Part 1107607A E 2011 Nordson Corporation...
Page 27 Introduction This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 28: Key Components
4. Hopper lid 8. Drive removal jack screw 12. Switch receptacles 5. Behind service cover—hopper, grid, 9. Drive cover or optional pressure and reservoir (tank) assembly control drive cover (F option drive cover not shown) Part 1107607A E 2011 Nordson Corporation...
Page 29 11. Clock key/LED 18. Hopper empty LED 5. Keypad 12. Setup key/LED 19. Piston down key/LED 6. Left display and scroll key 13. Clear/reset key 7. Service LED 14. Pump speed display (rpms) and arrow keys Part 1107607A E 2011 Nordson Corporation...
Page 30: Optional Equipment
Communications cards that allow the melter to communicate with other process equipment or a controller using standard network protocols. Footswitch that allows remote pump activation. Refer to Section 7, Parts, for a complete list of optional equipment. Part 1107607A E 2011 Nordson Corporation...
Page 31: Installation
If optional equipment was ordered with the melter, refer to the documentation provided with the optional equipment for installation and operating instructions. Part 1107607A E 2011 Nordson Corporation...
Page 32: Installation Tasks
The instructions provided in this section are intended to be used by personnel who have experience in the following subjects: Hot melt application processes Industrial power and control wiring Industrial mechanical installation practices Basic process control and instrumentation Part 1107607A E 2011 Nordson Corporation...
Page 33 Installation This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 34: Installation Requirements
Minimum horizontal space required to remove the 290 mm (11.4 in.) service cover Depth of melter including service handles 678 mm (26.7 in.) Minimum vertical space required for the melter if 964 mm (37.9 in.) mounting feet are not used Part 1107607A E 2011 Nordson Corporation...
Page 35 Installation Figure 3-1 Minimum installation clearances Part 1107607A E 2011 Nordson Corporation...
Page 36: Electrical Power
Nordson recommends that an isolation valve be installed in the plant air supply line just before the melter.
Page 37: Other Considerations
The melter must be installed where it will be in conformance with the ventilation requirements specified in the Material Safety Data Sheet for the hot melt being used. Part 1107607A E 2011 Nordson Corporation...
Page 38: Unpacking The Melter
Before starting the installation, remove the melter from the pallet, locate the installation kit, and inspect the melter for damaged and missing parts. Report any problems to your Nordson representative. Customer-Supplied Materials The following additional materials are required to install the melter:...
Page 39 Installation kit components 1. Voltage plug (2) 3. Input/output connectors (2) 5. Straight hose fitting (1) 2. Voltage plug with neutral (2) 4. Spare fuses (8) 6. 90-degree hose fitting (1) 7. Strain relief connector (1) Part 1107607A E 2011 Nordson Corporation...
Page 40: Mounting The Melter
12.7 10.3 15.0 4X M6X1.0 -- 6H THRU ALL FOR MOUNTING FEET (NOT SHOWN) 4X M10X1.5 -- 6H THRU ALL ATTACHING BOLT THREAD ENGAGEMENT MIN 10MM / MAX 30MM Figure 3-3 Bolt mounting pattern Part 1107607A E 2011 Nordson Corporation...
Page 41: Configuring The Electrical Service
To configure the melter to function in your facility, you must connect a power cable to the melter and designate the service type by installing a Nordson-supplied voltage plug into the melter. To connect a power cable to the melter WARNING! Risk of electrocution! Install a lockable power disconnect switch between the electrical service and the melter.
Page 42 The ground lug is marked PE/G. Opening the electrical enclosure EXAMPLE ONLY (3/N/PE AC wiring shown) L1 L2 L3 N PE/G Figure 3-4 Connecting the power cable and ground lead Part 1107607A E 2011 Nordson Corporation...
Page 43 The 400/230 VAC 3-phase service (4-wire service including neutral) includes the 415/240 VAC 3-phase (4-wire service, including neutral) voltage. The 230 VAC 1-phase service (2-wire service, including a neutral) includes the 240 VAC 1-phase (2-wire service, including a neutral) voltage. Part 1107607A E 2011 Nordson Corporation...
Page 44 If the electrical service was configured correctly, the melter control panel Typical voltage plugs (plugs with and without the neutral will display dashes. lead shown) P/N 232617 P/N 227567 P/N 227569 P/N 227568 Figure 3-5 Connecting a voltage plug Part 1107607A E 2011 Nordson Corporation...
Page 45 3-15 Installation This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 46: Connecting Hoses And Guns
Installation Connecting Hoses and Guns PURBlue 4 melters use standard Nordson hoses and guns and support the connection of up to three hose/gun pairs. The hose/gun capacity of each melter is determined by the number of hose/gun receptacles on the melter.
Page 47 Connecting a switched handgun hose or footswitch To connect guns Observe the following guidelines: For information about choosing the most appropriate Nordson hot melt gun for your manufacturing process, refer to the latest edition of Nordson's hot melt dispensing equipment Replacement Parts Catalog or contact your Nordson representative.
Page 48 3-18 Installation This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 49: Connecting A Compressed Air Supply
3. Turn the air regulator (1) to set the melter's operating air pressure (pressure supplied to the piston) to 2 bar (30 psi). 2 (6 mm) Figure 3-7 Location of the air supply input port 1. Piston air regulator and gauge 2. Air supply inlet Part 1107607A E 2011 Nordson Corporation...
Page 50: Connecting A Pressure Control Signal
6 bar (87 psi). Table 3-4 I/P Transducer Connections for the Automatic Pressure Control Option I/P Transducer Terminal Wire Color Signal Numbers Brown Supply power White Input signal Blue GND (common) Black Monitor output Part 1107607A E 2011 Nordson Corporation...
Page 51 3-21 Installation Figure 3-8 Connecting a signal to the I/P transducer for the pressure control P option 1. I/P transducer 3. Pneumatic PCV 2. Drive cover assembly (P option) Part 1107607A E 2011 Nordson Corporation...
Page 52 Figure 3-9 Connecting a signal to the pressure control terminal block for the pressure control F option 1. Pressure control option terminal block 2. F Option drive cover assembly 3. Pneumatic PCV Part 1107607A E 2011 Nordson Corporation...
Page 53: Setting Up The Melter
If you need to make changes to the factory setup or if you want to learn about other operating parameters, go to the next part in this section, Operating Parameters. Part 1107607A E 2011 Nordson Corporation...
Page 54 A group of parameters that control the melter’s clock. The 50 to 77 clock is used to automatically turn the heaters on and off and Seven-day Clock Disabled to place the melter into the standby mode. Part 1107607A E 2011 Nordson Corporation...
Page 55: Operating Parameters
In addition to the ability to read and edit parameter values, you can also save and restore the current value of every operating parameter and review a log of the last ten changes that were made to editable parameters. Part 1107607A E 2011 Nordson Corporation...
Page 56: Selecting Operating Parameters
NOTE: Motor control parameters are set differently from operating parameters. Refer to Setting up the Motor Control later in this section. Some applications will require a change to one or more motor control parameters. Part 1107607A E 2011 Nordson Corporation...
Page 57: Reading Or Editing Operating Parameters
NOTE: If the keypad has no affect on the right display, the melter is password protected. You must enter a valid password before you can edit parameters. Refer to Entering the Melter Password in Section 4, Operation. Part 1107607A E 2011 Nordson Corporation...
Page 58 Change Hose 1 Output to Electric Gun 0 (disabled) or 1 (enabled) 0 (disabled) Activation Change Hose 2 Output to Electric Gun 0 (disabled) or 1 (enabled) 0 (disabled) Activation External Communications Lock-out 0 or 1 0 (disabled) Continued... Part 1107607A E 2011 Nordson Corporation...
Page 59 6 (Alert) Optional Output 4 0–6 0 (disabled) Optional Output 5 0–6 0 (disabled) Optional Output 6 0–6 0 (disabled) Optional Output 7 0–6 0 (disabled) PUR Timer PUR timer 10--120 minutes 30 minutes Continued... Part 1107607A E 2011 Nordson Corporation...
Page 60 NOTE: Motor control parameters are set differently from operating parameters. Refer to Setting Up the Motor Control later in this section. Some applications will require a change to one or more motor control parameters. Part 1107607A E 2011 Nordson Corporation...
Page 61: Setpoint Temperature Of The Tank, Hoses, And Guns
Adjusting Component Temperatures in Section 4, Operation. As with operating parameters, you can also save and restore setpoint temperatures and review past changes that were made to setpoint temperatures. Part 1107607A E 2011 Nordson Corporation...
Page 62 Each component begins to heat or cool to the new global setpoint temperature and the melter returns to the automatic scan mode. Tank key When all of the components reach the global setpoint temperature, the ready LED turns on (green). Ready LED Part 1107607A E 2011 Nordson Corporation...
Page 63: Save And Restore Melter Settings
With the melter in the automatic scan mode, simultaneously press the number 2 key and the Setup key. S-2 appears momentarily in the right display. Restoring current settings Part 1107607A E 2011 Nordson Corporation...
Page 64: Review Parameter And Setpoint Temperature Changes
3. Press a right-display scroll key to review each of the remaining nine log entries. Each press of a scroll key displays a progressively older log entry. 4. Press the Setup key to return to the automatic scan mode. Scrolling through the fault log Part 1107607A E 2011 Nordson Corporation...
Page 65 Parameter 4 (ready delay) was changed. Example 2: If the LED on the gun key is on, then this display would indicate that the global-by-component method was used to change the temperature of the guns. Part 1107607A E 2011 Nordson Corporation...
Page 66: Installing Melter Inputs
NOTE: Use a signal cable suitable for NEC class 1 remote control and signaling circuits. To reduce the possibility of electrical shorting, route the cable so that it does not touch nearby circuit boards. Opening the electrical enclosure Part 1107607A E 2011 Nordson Corporation...
Page 67 3. Plug the connector (P/N 277909) into the bottom receptacle of terminal Connector P/N 277909 XT7, which is located on the expansion board. If input number four is used, plug connector P/N 277908 into the top receptacle on terminal XT7. Figure 3-10 Wiring inputs Part 1107607A E 2011 Nordson Corporation...
Page 68 The input capacity of the melter may be Section 7, Parts increased from four inputs to a total of ten inputs by adding an optional I/O expansion card that is available from Nordson Corporation. Part 1107607A E 2011 Nordson Corporation...
Page 69: Control Option
Parameters 34 through 39 are reserved for the inputs created when either the optional I/O expansion card or optional I/O board is installed. Refer to Appendix B, Operating Parameters, for more information. Refer to the instruction sheet provided with the optional I/O expansion card or analog I/O board for wiring information. Part 1107607A E 2011 Nordson Corporation...
Page 70: Installing Melter Outputs
NOTE: Use a signal cable suitable for NEC class1 remote control and signaling circuits. To reduce the possibility of electrical shorting, route the cable so that it does not touch nearby circuit boards. Opening the electrical enclosure Part 1107607A E 2011 Nordson Corporation...
Page 71 Set up the parameter control option for each output that you connected to the melter. Table 3-10 lists the available control options. Refer to Setting Up the Melter earlier in this section for information about how to select operating parameters and edit parameter control options. Part 1107607A E 2011 Nordson Corporation...
Page 72: Output Terminals
For PURBlue 4 melters, a reservoir-empty state produces a melter fault after several seconds. When the fault occurs, the reservoir-empty output reverts back to its standard condition. In most cases, Nordson Corporation recommends the use of control option 3 (Fault), which will indicate a reservoir-empty state or any other condition that will stop production.
Page 73 3-43 Installation This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 74: Setting Up Gear-To-Line Operation
See Figure 3-12. Opening the electrical enclosure 2. Connect a 0-10 VDC line speed reference signal to terminals A8-X5-1 (+) and A8-X5-2 (-) on the motor control assembly. Part 1107607A E 2011 Nordson Corporation...
Page 75 3-45 Installation A8-X5-1 (+) A8-X5-2 (- -) Figure 3-12 Connecting a line speed reference signal for gear-to-line operation Part 1107607A E 2011 Nordson Corporation...
Page 76: Setting Up The Motor Control
5. Repeat steps 3-4 for each parameter you want to change. 6. To exit the setup mode, press the Pump mode key one additional time after the last parameter has been displayed. Pump mode key Part 1107607A E 2011 Nordson Corporation...
Page 77 After the set number of turns, the melter will shut down and display an F9/1 melter fault code. Refer to Melter Faults in Section 6, Troubleshooting, for more information on melter fault codes. Part 1107607A E 2011 Nordson Corporation...
Page 78: Installing Optional Equipment
Flushing the Melter Flush the melter before initial operation. Refer to Flushing the Melter in Section 5, Maintenance. Refer to Section 4, Operation, for information about filling the hopper and operating the melter. Part 1107607A E 2011 Nordson Corporation...
Page 79: Operation
Most of the controls described in this section are located on the control panel. Refer to Key Components in Section 2, Introduction, for the location of the controls and indicators described in this section. Part 1107607A E 2011 Nordson Corporation...
Page 80: Grid Operation And More About Heated Components
When the adhesive slug becomes empty, the grid turns off. The actual temperature of the grid can be displayed by pressing the Tank key and then 2. Part 1107607A E 2011 Nordson Corporation...
Page 81: Loading An Adhesive Slug
Piston up key 3. See Figure 4-1. When the piston is fully raised, pull up on the handle to open the lid. Figure 4-1 Opening the lid Part 1107607A E 2011 Nordson Corporation...
Page 82 (PIP) over the hopper. If the piston is in place, it applies downward force for 30 seconds after the Piston down key is pressed. After 30 seconds, the downward force is turned on and off by the melt-on-demand Piston down key sensor functionality. Part 1107607A E 2011 Nordson Corporation...
Page 83: Starting The Melter
3 _C (5 _F) of their assigned setpoint temperature. NOTE: If the Ready Delay Time (parameter 4) is set to a value other than 0, then this additional time must pass before the ready state will be reached. Part 1107607A E 2011 Nordson Corporation...
Page 84: Operating In Manual Mode
NOTE: When the melter is operating in the manual mode, the pump speed is determined by the following equation. Refer to Section 8, Technical Data, for pump displacement values. Adhesive output = displayed rpm × pump displacement (cc/min) Part 1107607A E 2011 Nordson Corporation...
Page 85: Operating In Gear-To-Line Mode
NOTE: When the melter is operating in the gear-to-line mode, the pump speed is determined by the following equation. Refer to Section 8, Technical Data, for pump displacement values. Adhesive   input voltage output = displayed rpm × pump displacement × (cc/min) Part 1107607A E 2011 Nordson Corporation...
Page 86: Adjusting The Pcv
With the melter at operating temperature, the line running, and the guns dispensing adhesive, turn the adjustment screw on the PCV clockwise to increase the adhesive output counterclockwise to decrease the adhesive output Adjusting the PCV Part 1107607A E 2011 Nordson Corporation...
Page 87: Automatic Pressure Control (P Option)
1. Press the Standby key to reduce the system temperature and place the system in standby mode. 2. Cover the applicator nozzles with petroleum jelly or submerge them in a suitable oil. Standby key Part 1107607A E 2011 Nordson Corporation...
Page 88: Monitoring The Melter
Refer to Monitor Melter Faults and Using Melter Function Keys later in this section for information about melter faults and using the seven-day clock and standby functions. Refer to Appendix B, parameter 4, for information about the ready delay. Part 1107607A E 2011 Nordson Corporation...
Page 89: Monitor The Adhesive Level
The melter is shipped with both level sensors calibrated for standard adhesive. If recalibration becomes necessary, refer to Calibrating the Hopper-Empty Sensor or Calibrating the Level Sensors in Section 5, Maintenance. Figure 4-2 Location of the level sensors 1. Melt-on-demand sensor 2. Reservoir-empty monitor Part 1107607A E 2011 Nordson Corporation...
Page 90: Monitor Component Temperatures
NOTE: On PURBlue 4 melters, 1 is the pump temperature and 2 is the Component keys grid temperature when the tank LED is on. Part 1107607A E 2011 Nordson Corporation...
Page 91 The right display indicates the actual temperature of the selected component. Component temperature display 3. Press the Setup key twice to return to the automatic scan mode. Setup key Part 1107607A E 2011 Nordson Corporation...
Page 92: Monitor Melter Faults
RAM backup Clock does not Insufficient voltage from Replace CPU F4/3 battery function RAM backup battery Internal clock Heaters remain on, Battery-backed RAM Replace CPU F4/4 battery backed but fault condition failure persists Continued... Part 1107607A E 2011 Nordson Corporation...
Page 93 CPU and the F4/d card persists optional I/O card Alert output (if output Fieldbus option 6 is selected) Replace the Fieldbus F4/E communications Fieldbus card failure Melter continues to card failure operate normally. Continued... Part 1107607A E 2011 Nordson Corporation...
Page 94 B: For a detailed description of how the melt-on-demand functionality of this melter works, refer to Modes of Operation in Section 2, Introduction. Part 1107607A E 2011 Nordson Corporation...
Page 95: How F1, F2, And F3 Faults Are Handled
LED will turn off, the red fault LED will turn on, the heaters turn off, and the melter records the fault in the fault log. Refer to To review the fault log later in this section. Fault LED Part 1107607A E 2011 Nordson Corporation...
Page 96: How F4 Faults Are Handled
I/Os. Refer to Section 6, Troubleshooting, for information about diagnosing F4 faults. 5. The melter records the fault in the fault log. Refer to To review the fault log later in this section. Part 1107607A E 2011 Nordson Corporation...
Page 97 2. Return the melter to the automatic scan mode by pressing the Setup key twice. Setup key 3. Press the Clear/reset key. Clear/reset key 4. Press the Heaters key to turn on the heaters. Heaters key Part 1107607A E 2011 Nordson Corporation...
Page 98 Scrolling through 4. Press the Setup key to return to the automatic scan mode. the fault log Part 1107607A E 2011 Nordson Corporation...
Page 99: Monitor Motor/Piston Control Or Motor Drive Faults
The pump speed display and the display on the motor drive located inside the electrical enclosure alert the operator to abnormal motor/piston-related faults. These faults may cause the pump to stop. Refer to Motor/Piston Control Faults or Motor Drive Faults in Section 6, Troubleshooting. Part 1107607A E 2011 Nordson Corporation...
Page 100: Monitor The Service Interval
Service LED To reset the service LED With the melter in the scan mode, press the Clear/Reset key to turn off the service LED and reset the service interval time. Clear/reset key Part 1107607A E 2011 Nordson Corporation...
Page 101: Adjusting Component Temperatures
The right display indicates all dashes (----) and the LEDs on all of the component keys turn green. Left display and scroll key 3. Press the Enter key. The right display flashes. Enter key Part 1107607A E 2011 Nordson Corporation...
Page 102 5. Press the Tank key. All components begin to heat or cool to the new global setpoint temperature. When all of the components reach their setpoint temperature, the ready LED turns on (green). Tank key Part 1107607A E 2011 Nordson Corporation...
Page 103 Refer to Entering the Melter Password later in this section. 5. Press the Enter key. The hoses or the guns begin to heat or cool to their new setpoint temperature. Part 1107607A E 2011 Nordson Corporation...
Page 104 To register the new setpoint temperature and return to the automatic scan mode, go to step 6. 6. Press any component key (tank, hose, or gun). The selected component begins to heat or cool to its new setpoint temperature. Part 1107607A E 2011 Nordson Corporation...
Page 105: Entering The Melter Password
If the password is incorrect, the left display remains at 0 and the right display momentarily indicates dashes (----) and then returns to 4000. If the password is incorrect, re-enter it and then press the Enter key. Part 1107607A E 2011 Nordson Corporation...
Page 106: Using Melter Function Keys
When a fault occurs (refer to Monitor Melter Faults earlier in this section) the heaters automatically turn off. The heater key is used to turn the heaters back on after correcting a fault condition. Part 1107607A E 2011 Nordson Corporation...
Page 107: Pump Enable Key
The LED on the pump mode key is green when the melter is in the manual mode. When the melter is operating in the gear-to-line mode, a 0-10 VDC signal must be supplied. Refer to Setting Up Gear-to-Line Operation in Section 3, Pump mode key Installation. Part 1107607A E 2011 Nordson Corporation...
Page 108: Setup Key
Refer to Appendix B, Operating Parameters, Seven-day Clock, for information about setting up the seven-day clock and the standby delta. Part 1107607A E 2011 Nordson Corporation...
Page 109: Standby Key
Using the standby key overrides the control of the melter (on or off) by the seven-day clock or a remote input. Refer to Section 3, Installation, Setting Up the Melter, and to Appendix B, Operating Parameters, for information about setting the standby delta and the standby timer. Part 1107607A E 2011 Nordson Corporation...
Page 110: Shutting Down The Melter
Ensure that material connections are closed such that they are airtight. 4. If the system will be shut down for a longer period of time, rinse it with a suitable cleaning agent. Use only a cleaning agent recommended by the material manufacturer. Part 1107607A E 2011 Nordson Corporation...
Page 111: Maintenance
PURBlue 4 melters operating within their specified limits and to prevent equipment malfunctions. For information about maintaining optional equipment that was supplied by Nordson, refer to the instructions provided with the equipment. If the melter stops operating or is operating incorrectly, refer to Section 6, Troubleshooting, for information about diagnosing common problems and performing corrective maintenance.
Page 112 (sensors are Sensor or Calibrating the Level factory-calibrated) Sensors Calibrating the pump speed display As needed throughout the life of the Calibrating the Pump Speed Display melter (the pump speed display is factory-calibrated) Part 1107607A E 2011 Nordson Corporation...
Page 113: Relieving System Pressure
2. Set the control option for parameter 14 to 1 (enabled). 3. When the service activity is complete, return parameter 14 to 0 (disabled). Pump mode key Refer to Setting Up the Melter in Section 3, Installation, for information about changing operating parameters. Part 1107607A E 2011 Nordson Corporation...
Page 114: Flushing The Melter
Process a minimum of one tank volume of hot melt or flushing material through the melter, hoses, and applicators. At some point, set the pressure control to a low value and close the applicator(s) to flush the pressure control recirculation loop. Part 1107607A E 2011 Nordson Corporation...
Page 115: Cleaning The Melter
5. Reverse steps 2-4 to reinstall each cover. To clean the electrical enclosure After covers are removed, inspect the fan area and ensure that the air flow path for both side covers is clear. Remove excessive dust from inside the cabinet. Part 1107607A E 2011 Nordson Corporation...
Page 116 Maintenance Cleaning the Melter (contd) Figure 5-1 Removing the service covers 1. Hopper cover 2. Service cover 3. Manifold cover Part 1107607A E 2011 Nordson Corporation...
Page 117: Cleaning The Hopper And Grid
NOTE: It is particularly important to remove the adhesive from the flat portion of the outer diameter of the grid. This surface must be clear so that a good seal with the adhesive slug foil bag is possible. 4. Restore the system to normal operation. Part 1107607A E 2011 Nordson Corporation...
Page 118: Cleaning The Tank And Level Sensors
9. See Figure 5-2. Clean the melt demand and reservoir empty sensor probes at the back of the reservoir. 10. Restore the system to normal operation. Part 1107607A E 2011 Nordson Corporation...
Page 119 Maintenance Figure 5-2 Hopper/grid assembly removal and the location of the level sensor probes Part 1107607A E 2011 Nordson Corporation...
Page 120: Cleaning The Piston
10. If the adhesive is cool, try to peel it from the release-coated parts. If the adhesive is hot, use a wooden or plastic scraper to remove it. 11. Restore the system to normal operation. Piston down key Part 1107607A E 2011 Nordson Corporation...
Page 121: Calibrating The Hopper-Empty Sensor
2. Loosen the hopper-empty sensor (1) and move it to the lowest position on the piston (2). 3. Move the sensor up until its LED illuminates and then secure the sensor at this location. Figure 5-3 Location of the hopper-empty sensor 1. Hopper-empty sensor 2. Piston Part 1107607A E 2011 Nordson Corporation...
Page 122: Calibrating The Level Sensors
NOTE: When an LED turns yellow, the system believes that adhesive is present. Because we know that adhesive is not present, turning an adjustment screw counterclockwise until the LED turns green and then adding an additional two (2) counterclockwise turns calibrates the sensors. Part 1107607A E 2011 Nordson Corporation...
Page 123 Green Amber Figure 5-4 Location of the level sensor adjustment screws and LEDs 1. Melt-on-demand sensor (S1) 3. Level sensor LED 4. Level sensor adjustment screw (behind plug) 2. Reservoir-empty monitor Part 1107607A E 2011 Nordson Corporation...
Page 124: Calibrating The Pump Speed Display
3. Press and hold both Pump speed arrow keys. 4. When the motor control display indicates CAL, release the keys. 5. Enter the actual pump rpm. Pump speed display and arrow keys 6. Press the Pump mode key. Pump mode key Part 1107607A E 2011 Nordson Corporation...
Page 125: Troubleshooting
If you cannot resolve the problem using the troubleshooting flowchart, contact your Nordson representative for technical assistance. Safety Never disconnect cables from, or reconnect cables to, any circuit board while the melter is energized.
Page 126: Melter Faults
RAM backup Clock does not Insufficient voltage from Replace CPU F4/3 battery function RAM backup battery Internal clock Heaters remain on, Battery-backed RAM Replace CPU battery backed but fault condition failure F4/4 persists Continued... Part 1107607A E 2011 Nordson Corporation...
Page 127 CPU and the F4/d card persists optional I/O card Alert output (if output Fieldbus option 6 is selected) Replace the Fieldbus communications F4/E Fieldbus card failure Melter continues to card failure operate normally. Continued... Part 1107607A E 2011 Nordson Corporation...
Page 128 B: For a detailed description of how the melt-on-demand functionality of this melter works, refer to Modes of Operation in Section 2, Introduction. Part 1107607A E 2011 Nordson Corporation...
Page 129: Motor/Piston Control Faults
Close the lid. (Lid Not Closed) Displayed rpms do not Pump speed display not Calibrate the pump speed match motor speed calibrated display. Refer to Calibrating the Pump Speed Display in Section 5, Maintenance. Continued... Part 1107607A E 2011 Nordson Corporation...
Page 130 5 minutes the piston has not lifted, increase the melter temperature to the maximum safe limit recommended by the material supplier. Allow the temperature to stabilize for 30 minutes (with the maximum air pressure still applied). Part 1107607A E 2011 Nordson Corporation...
Page 131: Motor Drive Faults
1. Motor drive power LED (steady=OK, flashing=fault, off=no power) 2. Display Note: Do not use the motor drive keys. Contact your Nordson representative for assistance if you need to adjust any motor drive settings. Part 1107607A E 2011 Nordson Corporation...
Page 132 Ensure that the unit ambient temperature does not exceed 50 _C (120 _F), that the electrical enclosure vents are not blocked, and that the electrical enclosure fan is operating properly. Continued... Part 1107607A E 2011 Nordson Corporation...
Page 133 Section 8, Technical Data, for allowable Overvoltage Disturbed line supply input voltage range. Motor drive parameter(s) changed Contact your Nordson representative. Configuration fault Check the unit input line voltage. Refer to Line supply too low Section 8, Technical Data, for allowable...
Page 134: Pump Operational Status
Ready status of the melter Activation of a switched input (handgun or footswitch) Activation of the pump key Table 6-4 provides the status of the pump LED for each combination of the pump operating variables. Part 1107607A E 2011 Nordson Corporation...
Page 135 B: If the remote motor input is assigned, then its status is described in this column. C: “On” means the pump key was pressed and the unit accepted the key press. “ ” means that the Ignored pump key will not respond to a key press. Part 1107607A E 2011 Nordson Corporation...
Page 136: Using The Troubleshooting Flow Chart
Use of the chart assumes that the melter is installed correctly and that it is set up to support the current manufacturing process. Refer to Section 3, Installation, for information about installing and setting up the melter. Troubleshooting question and action blocks a) Question b) Action Part 1107607A E 2011 Nordson Corporation...
Page 137: Troubleshooting Quick-Checks
Tank and Clear/reset keys, and then switch the melter back on, holding the Tank and Clear/reset keys until the letters PUR appear on the right display. This will reset the melter as a PUR melter. Part 1107607A E 2011 Nordson Corporation...
Page 138: Identifying Electrical Components
Grid heaters (6.3 A, 250 V, 5 x 20 mm) F9/F10 ---- Hose/gun 1 heaters (6.3 A, 250 V, 5 x 20 mm) F11/F12 ---- Motor start (6.3 A, 250 V, 5 x 20 mm) Continued... Part 1107607A E 2011 Nordson Corporation...
Page 139 Input voltage configuration plugs Input 24 VDC in from main board Input/output Ribbon cable connection between expansion board and power module (hoses/guns 2 and 3) Input/output Ribbon cable connection between expansion board and main board Part 1107607A E 2011 Nordson Corporation...
Page 140 Connection point for the wire harness between hose/gun 2 and the power module J4/J5 Input AC power input from XT2 on the expansion board Fuses F1, F2 ---- Hose 3 and gun 3 F3, F4 ---- Hose 2 and gun 2 Part 1107607A E 2011 Nordson Corporation...
Page 141 Sensor input Piston-in-place sensor connection Sensor input Melt on demand sensor connection Sensor input Reservoir empty sensor connection Sensor input Hopper empty sensor connection Switch Switch to put motor control CPU into software upgrade mode Part 1107607A E 2011 Nordson Corporation...
Page 142 Test Test Test Test Output Solenoid 1 Output Solenoid 2 Fuses Fuse Fuse for fan, motor drive, 24VDC power supply Fuse Same as above Fuse Fuse for 24 VDC power to and through board Part 1107607A E 2011 Nordson Corporation...
Page 143 6-19 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 144 6-20 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 145 6-21 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 146 6-22 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 147 6-23 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 148 6-24 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 149 6-25 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 150 6-26 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 151 6-27 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 152 6-28 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 153 6-29 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 154 6-30 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 155 6-31 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 156 6-32 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 157 6-33 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 158 6-34 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 159 6-35 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 160 6-36 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 161 6-37 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 162 6-38 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 163 6-39 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 164 6-40 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 165 6-41 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 166 6-42 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 167 6-43 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 168 6-44 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 169 6-45 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 170 6-46 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 171 6-47 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 172 6-48 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 173 6-49 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 174 6-50 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 175 6-51 Troubleshooting Figure 6-2 Opening the tank isolation valve 1. Open 2. Closed Part 1107607A E 2011 Nordson Corporation...
Page 176 6-52 Troubleshooting Part 1107607A E 2011 Nordson Corporation...
Page 177: Parts
Section 7 Parts Using the Illustrated Parts Lists To order parts, call the Nordson Customer Service Center or your local Nordson representative. Use these five-column parts lists, and the accompanying illustrations, to describe and locate parts correctly. The following chart provides guidance for reading the parts lists.
Page 178: Melter Part Numbers
NOTE: The following table is not a complete list of melter configurations. As new configurations are developed, additional melter part numbers will be created. Contact your Nordson representative for information on available PURBlue 4 melter configurations. Part Number...
Page 179 Parts This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 180: Top Support Plate Assembly Parts
S SHIELD, DOOR, ELEC, PB4 - - - - - - S SHIELD, PANEL, REAR, PB4 - - - - - - S RIVET, POP, 1/8X.250 CARBON STL 288221 S GASKET, .354X.216, MPL, 3000V (cut pcs) Part 1107607A E 2011 Nordson Corporation...
Page 181 Parts Figure 7-2 Top support plate assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 182: Hopper/Grid Assembly Parts
S CABLETIE,4 IN,338F/170C,TEFLON,BLUE 1096020 KIT, SERVICE, MANIFOLD/GRID, RTD SENSOR 1096027 KIT, SERVICE, GRID HEATER ASSY, 240V NOTE A: Optional hopper sizes are available. Refer to Optional Equipment later in this section. NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 183 Parts Figure 7-3 Hopper/grid assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 184: Reservoir Assembly Parts
S SENSOR ASSY,TANK RTD & TSTAT,PB4 - - - - - - S SCR,HEX,MACH,M5X8,ZN 1093681 S SCREEN, RESERVOIR, PB4 1096025 KIT, SERVICE, RES. HEATER ASSY, 240V NOTE A: To replace this part, order service kit 1095999. NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 185 Parts Figure 7-4 Reservoir assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 186: Pivot Lid Assembly Parts
S TUBING, TEFLON, 6 MM ODX 1 MM WALL 900344 S LUBRICANT, NEVER SEEZ, 8OZ CAN NOTE A: To replace these parts, order service kit 1093148. This kit includes item 12. NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 187 7-11 Parts Figure 7-5 Pivot lid assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 188 7-12 Parts This page intentionally left blank. Part 1107607A E 2011 Nordson Corporation...
Page 189: Pump/Drive/Manifold Assembly Parts
- - - - - - MODULE, PUMP MANIFOLD DRIVE — - - - - - - S DRIVE ASSY NOTE A: Refer to Drive Assembly later in this section. Figure 7-6 Pump/manifold/drive assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 190: Drive Assembly
S SCR, SKT, M5X10, BL - - - - - - S BRACKET, MANIFOLD COVER, PB4 NOTE A: To replace the motor, order service kit 1093143. B: Refer to Pump/Manifold Assembly later in this section. Part 1107607A E 2011 Nordson Corporation...
Page 191 7-15 Parts 2X TORQUE TO 54--60 IN--LB 4X TORQUE TO 2X TORQUE TO 7--8 FT--LB 7--8 FT--LB +.030 .030 -- .000 +0.8 SPACE BETWEEN COUPLING JAWS Figure 7-7 Drive assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 192: Pump/Manifold Assembly
1096027 KIT, SERVICE, MAN. HEATER ASSY, 240V NOTE A: To replace the manifold, order service kit 1093142 (240V melters). B: Refer to Pump Assembly later in this section. AR: As Required NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 193 7-17 Parts 4X TORQUE TO 16-18 FT-LB 03 17 18 17 18 Figure 7-8 Pump/manifold assembly parts (except PR100M3 pumps) Part 1107607A E 2011 Nordson Corporation...
Page 194: Pump Assembly
- - - - - - S ASSY BUSHING F.SHAFT SEALING D12,7 7146229 S IN-ASSEMBLY TOOLS 7136915, 7136918, EN/GE NOTE A: This instruction may be obtained from http://emanual.nordson.com, or contact your Nordson representative. NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 195: Pressure Control Option Parts
Manual PCV (X Option) See Figure 7-10. Item Part Description Quantity Note 1031222 S SVCE KIT, DURABLUE, PCV, 1100 PSI NOTE A: Order this kit to change to this pressure control option. Figure 7-10 Manual PCV Part 1107607A E 2011 Nordson Corporation...
Page 196: Automatic Pressure Control (P Option)
S SOLENOID ASSY, 35 SERIES, 1/8NPT, 24 VDC NOTE A: Order this kit to change to this pressure control option. To use this option, the pneumatic PCV contained in kit part 1034042 must be installed on the melter. Part 1107607A E 2011 Nordson Corporation...
Page 197 7-21 Parts Figure 7-11 Pressure control option parts Note: For a pneumatic schematic of the pressure control F option, refer to Section 8, Technical Data. Part 1107607A E 2011 Nordson Corporation...
Page 198: Electrical Component Parts
- - - - - - S CABLETIE,3.9 IN,185F/85C,NYLON, NATURAL NOTE A: To replace this item order service kit 1101619. B: To replace this item, order service kit 1093146. C: To replace this item, order service kit 1095998. Part 1107607A E 2011 Nordson Corporation...
Page 199 7-23 Parts Figure 7-12 Control panel assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 200: Other Circuit Boards And Electrical Components
NOTE A: For fuses, refer to the next parts list, Main Board Fuses. B: The location where this item is installed is shown in Figure 7-13. C: See Figure 7-4 and the accompanying parts list for the location of the sensor probe. NS: Not Shown Part 1107607A E 2011 Nordson Corporation...
Page 201 7-25 Parts Figure 7-13 Other circuit board and electrical component parts Part 1107607A E 2011 Nordson Corporation...
Page 202: Main Board Fuses
- - - - - - S FUSE, FAST, 5 A, 250 VAC, 5 X 20 MM, F5--F6 939683 S FUSE, 6.3 A, 250 VAC, 5 X 20 MM, F7--F12 Figure 7-14 Fuse service kit parts Part 1107607A E 2011 Nordson Corporation...
Page 203: Thermostat Assembly
Description Quantity Note 1096031 KIT, THERMOSTAT, O.O.R, 300 DEG F, PB4 - - - - - - SCR, SKT, M4X8, BL 900298 COMPOUND, HEAT SINK, 5 OZ TUBE, 11281 Figure 7-15 Thermostat assembly parts Part 1107607A E 2011 Nordson Corporation...
Page 204: Recommended Spare Parts
7-28 Parts Recommended Spare Parts Nordson Corporation recommends stocking these service kits and other components for a complete spare parts inventory. Assembly Part Description Note Top support plate 1102263 PROXSENSOR,INDUCTIVE,2MM,M12,W-CABLE Hopper/grid 1087919 INSULATOR, 154 ID, ALTA TT-RM 1096020 KIT, SERVICE, MANIFOLD/GRID, RTD SENSOR...
Page 205: Optional Equipment
KIT, FOOTSWITCH 1047093 KIT, REMOTE TRIGGER 1029938 CABLE ASSY, RIBBON, SERIAL PORT, 9 POS, DURA Cooling Fan and Light Tower Part Description Note 1095995 KIT, ACCESSORY, FAN, PB4 1097938 KIT, LIGHT TOWER, MAG. BASE, PB4 Part 1107607A E 2011 Nordson Corporation...
Page 206: Hoppers
To use the gear-to-line capability of the melter, you must install a device that measures the speed of the production line. The default type of line-speed signal input is 0-10 VDC, although other inputs can be accepted. Nordson Corporation offers the following 0-10 VDC generator.
Page 207: Technical Data
D: For displacement information, refer to Motor and Pump Specifications. Motor and Pump Specifications Item Data Note Viscosity range 45,000 cps Maximum hydraulic pressure 75 bar (1100 psi) PR2M1 pump: 0.30 cc/rev Displacement PR25M2 pump: 7.73 cc/rev Part 1107607A E 2011 Nordson Corporation...
Page 208: Electrical Specifications
2 x 400 240 V 137-160 ohms each Grid 2 x 400 240 V 137-160 ohms each NOTE A: Nominal wattage at 177-204 _C (350-400 _F). B: Measured at room temperature for a previously heated element. Part 1107607A E 2011 Nordson Corporation...
Page 209: Dimensions
Technical Data Dimensions 27.0 11.4 37.9 21.1 15.0 25.0 Figure 8-1 Melter dimensions Part 1107607A E 2011 Nordson Corporation...
Page 210: Conduit Penetration Sizes
Technical Data Conduit Penetration Sizes Figure 8-2 Conduit penetration sizes Part 1107607A E 2011 Nordson Corporation...
Page 211: Wiring Diagram
Technical Data Wiring Diagram Figure 8-3 Wiring diagram Part 1107607A E 2011 Nordson Corporation...
Page 212: Flow Control Bypass Pneumatic Schematic
Technical Data Flow Control Bypass Pneumatic Schematic FACTORY SET TO 70 PSI; DO NOT ADJUST. FROM AIR TO PNEUMATIC SUPPLY TO PRESSURE CONTOL MELTER VALVE Figure 8-4 Flow control bypass option pneumatic schematic (F option) Part 1107607A E 2011 Nordson Corporation...
Page 213: Calculating Melter Power Requirements
Two hose/gun pair maximum—The combined wattage of hose/gun pair 1 or hose/gun pairs 2 and 3 If your Nordson representative has already calculated the hose/gun power requirements and confirmed that the maximum allowable wattages will not be exceeded, then no further calculation is necessary. However, you should...
Page 214 Table A-2, then the configuration or position of the hose/gun pairs must be rearranged, shorter hoses must be used, or lower power guns must be used in order to reduce the power requirement. Part 1107607A E 2011 Nordson Corporation...
Page 215 Table A-2 Maximum Allowable Hose/Gun Wattages Column in Component Maximum Wattage Table A-1 Any single hose or gun 1000 W Any hose/gun pair 1200 W Sum of hose/gun pairs 2 and 3 2000 W Part 1107607A E 2011 Nordson Corporation...
Page 216 Calculating Melter Power Requirements Part 1107607A E 2011 Nordson Corporation...
Page 217: Operating Parameters
Configure the standard and optional outputs PUR Timer Set the PUR timer Seven-day Clock 50 to 77 Configure the clock feature Automatic Fill Timer Configure the external motor control switch PID Selection 80 to 91 Configure the PID settings Part 1107607A E 2011 Nordson Corporation...
Page 218: Standard
F1, F2, F3, and F4 Use: Use the right-display scroll keys to review the log entries for the last ten faults. Empty log entries are indicated by “_-F0.” Refer to Monitoring the Melter in Section 4, Operation. Part 1107607A E 2011 Nordson Corporation...
Page 219 The service LED will turn on after the pre-set time elapses. With the melter in the scan mode, press the Clear/Reset key to turn off the service LED and reset the time. Part 1107607A E 2011 Nordson Corporation...
Page 220 If Automatic Pump On is enabled, the pump will turn on automatically when the melter is ready. NOTE: If Automatic Pump On is disabled (0) while the pump is running, the pump will remain on until the pump key is pressed. Part 1107607A E 2011 Nordson Corporation...
Page 221: Create Password
Format: — Use: Use only when a Nordson manifold-mounted electric gun is installed and a switching device is connected to the melter’s switch receptacle. Refer to the electric gun manual for information on mounting and using the gun. Part 1107607A...
Page 222 Format: — Use: Use only when a Nordson manifold-mounted electric gun is installed and a switching device is connected to the melter’s switch receptacle. Refer to the electric gun manual for information on mounting and using the gun. External Communications Lock-out Description: Used as a safety feature when performing maintenance on the melter.
Page 223: Pressure Control
— Default Value: Format: — Use: This parameter is available only when the optional analog I/O board is installed on the melter. Refer to Section 7, Parts, for the I/O board kit part number. Part 1107607A E 2011 Nordson Corporation...
Page 224: Temperature Control
The number of degrees that the temperature of any component can decrease from its setpoint temperature before an under temperature fault (F2) occurs. Value: 5 _C (10 _F) to 60 _C (110 _F) Resolution: Default Value: 25 _C (50 _F) Format: — Use: — Part 1107607A E 2011 Nordson Corporation...
Page 225 (parameter 24) before the heaters turn off. Value: 0 to 1440 minutes (24 hours) Resolution: 1 minute Default Value: 0 (disabled) Format: — Use: Set parameter 24 (automatic standby timeout) to the desired value before setting parameter 25. Part 1107607A E 2011 Nordson Corporation...
Page 226 This parameter functions like parameter 23 except when it is set to 0, in which case it reverts to the setting for parameter 23. NOTE: The standby delta does not affect the under temperature delta (parameter 22). Part 1107607A E 2011 Nordson Corporation...
Page 227 Melter internal zones are designated as follows: DuraBlue D10/D16: primary=tank; secondary=pump DuraBlue D4L/D10L/D16L: primary=tank; secondary=pump AltaBlue TT: primary=tank; secondary=pump DuraBlue 25/50/100: primary=grid; secondary=reservoir AltaBlue 15/30/50/100: primary=grid; secondary=reservoir DuraDrum: primary=platen; secondary=pump PURBlue: 4 primary=tank; secondary=manifold; tertiary=grid Part 1107607A E 2011 Nordson Corporation...
Page 228: Input Setup
Control option that allows the unit to function as a PUR melter. Value: 19 - Melt demand Resolution: — Default Value: Format: — Use: Allows a PUR melter to control the melt demand logic. Part 1107607A E 2011 Nordson Corporation...
Page 229 NOTE: Parameter 78, Automatic Fill Timer, must be set to a value of 1 or greater in order to use option 13 or 14. Output option 6, Alert, can be used to signal when the Automatic Fill Timer expires. Part 1107607A E 2011 Nordson Corporation...
Page 230 NOTE: Parameter 78, Automatic Fill Timer, must be set to a value of 1 or greater in order to use option 13 or 14. Output option 6, Alert, can be used to signal when the Automatic Fill Timer expires. Part 1107607A E 2011 Nordson Corporation...
Page 231 NOTE: Parameter 78, Automatic Fill Timer, must be set to a value of 1 or greater in order to use option 13 or 14. Output option 6, Alert, can be used to signal when the Automatic Fill Timer expires. Part 1107607A E 2011 Nordson Corporation...
Page 232: Output Setup
If the potential fault condition clears before the end of the two minute period, the output signal ends. Refer to Section 4, Operation, Monitor Melter Faults, for information about fault monitoring. Part 1107607A E 2011 Nordson Corporation...
Page 233: Pur Timer
Refer to Calibrating the Level Sensors in Section 5, Maintenance, if this situation occurs and the S1Cal warning is displayed. Part 1107607A E 2011 Nordson Corporation...
Page 234: Seven-Day Clock
71 through 77 is schedule 0, which has no time values assigned to it. With the default set to sched- ule 0, unintentionally pressing the clock key will have no affect on the melter. Part 1107607A E 2011 Nordson Corporation...
Page 235: Example 1
1600 at the end of the day, every day of the week: Par 55 = 0600 Par 56 = 1600 Par 57 = 1130 Par 58 = 1230 Par 71 through 75 = 1 Par 71 and 77 = 1 Part 1107607A E 2011 Nordson Corporation...
Page 236 Resolution: 1 minute Default Value: 1700 Format: Hours, Hour: Minute, Minute Use: To disable this parameter, set the parameter’s value to “- - - -” by simultaneously pressing both of the right-display scroll keys. Part 1107607A E 2011 Nordson Corporation...
Page 237 Hours, Hour: Minute, Minute Use: Set the desired time for the heaters to turn on. To disable this parameter, set the parameter’s value to “- - - -” by simultaneously pressing both of the right-display scroll keys. Part 1107607A E 2011 Nordson Corporation...
Page 238 Note: Do not set an exit standby time that is outside of the time period defined by the schedule’s heater on and off time. The melter cannot enter the standby mode when the heaters are off. Part 1107607A E 2011 Nordson Corporation...
Page 239 Note: Do not set an enter standby time that is outside of the time period defined by the schedule’s heater on and off time. The melter cannot enter the standby mode when the heaters are off. Part 1107607A E 2011 Nordson Corporation...
Page 240 Default Value: Format: — Use: Selects the active schedule(s) for the day. NOTES: If the 0 schedule option is used, the heaters will not turn on again until the next scheduled heaters on time arrives. Part 1107607A E 2011 Nordson Corporation...
Page 241 Default Value: Format: — Use: Selects the active schedule(s) for the day. NOTES: If the 0 schedule option is used, the heaters will not turn on again until the next scheduled heaters on time arrives. Part 1107607A E 2011 Nordson Corporation...
Page 242 Default Value: Format: — Use: Selects the active schedule(s) for the day. NOTES: If the 0 schedule option is used, the heaters will not turn on again until the next scheduled heaters on time arrives. Part 1107607A E 2011 Nordson Corporation...
Page 243 Default Value: Format: — Use: Selects the active schedule(s) for the day. NOTES: If the 0 schedule option is used, the heaters will not turn on again until the next scheduled heaters on time arrives. Part 1107607A E 2011 Nordson Corporation...
Page 244: Automatic Fill Timer
0 or 1 depending on the channel type (hose or gun) Format: — Use: Consult your Nordson representative before changing PID settings. PID Selection for Hose/Gun Receptacles 5, 6, 7, 88 - 91 and 8 (DuraBlue D25, D50, and D100 melters only) Description: Used to change the preset PID selections.

Nordson PURBluet 4 Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Nordson PURBluet 4

Summary of Contents for Nordson PURBluet 4

Table of Contents
