Pinehurst Chaise Lounge
Assembly Guide
1) Place (4) "D" Flanged Washers
into Both Sides of Holes in Back
Support as Shown.
D
2) With Seat Assembly
Facing Downward, Attach Back
Support Using (2) "B" Bolts
as Shown.
SEQUOIA
PROFESSIONAL
by
highwood
All manuals and user guides at all-guides.com
BACK SUPPORT
D
BACK SUPPORT
B
For information on Care and Cleaning or to register your
PROFESSIONAL
www.highwood-usa.com.
A
B
C
D
SEAT ASSEMBLY
product by highwood , please visit
HARDWARE
x16
1/4"-20 X 1-1/4"
x2
1/4"-20 X 2"
1/4"-20 X 3"
x4
Flanged Washer
IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
SEQUOIA
x8
CM-LNGSQ61
03.05.19
PAGE 1 OF 2
