Lehigh Collection
Armchair - Counter Height
Assembly Guide
IMPORTANT!
DO NOT fully tighten the bolts until all bolts are started.
Once all bolts are inserted, go back & tighten all the bolts.
HARDWARE INCLUDED
A
1/4-20 x 1.5"
B
1/4-20 x 2"
C
1/4-20 x 3"
SEAT
B
RUNG
LEG / ARM
Qty: 2
Qty: 8
BACK
C
B
BACK ALIGNMENT
For information on Care and Cleaning or to Register your
highwood product, please visit www.highwood-usa.com.
Qty: 4
A
TOOLS INCLUDED
5/32" HEX KEY
1)
Attach Seat to Leg/Arm using
(2) B bolts and (2) C bolts.
(Align Back as shown for C
bolts)
2)
Attach Back to Leg/Arm
using (1) A bolt
3)
Attach Rungs to Leg/Arm using
(2) B bolts per Leg/Arm
assembly.
4)
Repeat on other Side.
AD-CHCL2|AD-CHCW2
04.21.21
PAGE 1 OF 2
