highwood Sequoia Professional Aurora Traditional Assembly Manual

Sequoia Professional
Aurora Traditional
Park Bench 4ft
Assembly Guide
IMPORTANT!
DO NOT fully tighten the bolts until all bolts are started.
Once all bolts are inserted, go back & tighten all the bolts.
HARDWARE INCLUDED
A
#7 x 2"
B
#7 x 3"
B
SEAT SLATS
1)
Attach (4) Seat Slats to (2) Bench Ends
using (16) "B" Wood Screws as shown.
SEQUOIA
PROFESSIONAL
by
Qty: 12
Qty: 16
BENCH ENDS
For information on Care and Cleaning or to Register your
SEQUOIA PROFESSIONAL product by highwood®, please visit
www.highwood-usa.com.
TOOLS INCLUDED
T-15 TORX BIT
CUSTOMER SUPPLIED TOOLS
Cordless screwdriver/drill OR
Multi-bit handle for the Torx Bit
2)
Attach (3) Back Slats to (2) Bench Ends
using (12) "A" Wood Screws as shown.
*The Slat with Badge to be on Top*
A
BACK SLATS
BENCH ENDS
CM-BENSQ43|CM-BENSQ63
06.20.22
PAGE 1 OF 2
