Adirondack Collection
Folding & Reclining
Adirondack Chairs
Assembly Guide
IMPORTANT!
DO NOT fully tighten the bolts until all bolts are started.
Once all bolts are inserted, go back & tighten all the bolts.
HARDWARE INCLUDED
A
#7 x 2-1/4"
B
1/4"-20 x 2"
C
1/4"-20 x 3"
D
1-1/2"
STEPS 1-2
Attach Seat to Back using Bolt B.
Repeat on other side.
SEAT
Qty: 10
AD-CHL1 (Qty: 4)
AD-ADRID29A (Qty: 4)
AD-KING1 (Qty: 10)
Qty: 4
Qty: 2
BACK
For information on Care and Cleaning or to Register your
highwood product, please visit www.highwood-usa.com.
(7) BACK SLATS
Qty: 2
CUSTOMER SUPPLIED TOOLS
Cordless screwdriver/drill OR
Multi-bit handle for the Torx Bit
STEP 3
Attach Back Support Brace to Back
Support Sides with (4) A Screws.
B
BACK SUPPORT BRACE
AD-CHL1
AD-KING1
(8) BACK SLATS
TOOLS INCLUDED
5/32" HEX KEY
T-15 TORX BIT
BACK SUPPORT SIDES
A
AD-CHL1|AD-ADRID29A|AD-KING1
AD-ADRID29A
02.08.21
PAGE 1 OF 2
Advertisement
Related Manuals for highwood Adirondack AD-CHL1
Summary of Contents for highwood Adirondack AD-CHL1
- Page 1 Attach Seat to Back using Bolt B. BACK Support Sides with (4) A Screws. Repeat on other side. BACK SUPPORT SIDES BACK SUPPORT BRACE SEAT AD-CHL1|AD-ADRID29A|AD-KING1 For information on Care and Cleaning or to Register your 02.08.21 highwood product, please visit www.highwood-usa.com. PAGE 1 OF 2...
