- Page 1 EINAR Installation Guide This guide contains an overview of the hardware and required components, suggested scenarios and step-by-step guide for installation, and safety and maintenance instructions. © Copyright Adaptive Recognition Inc. 14.05.2025. All rights reserved.
-
Page 2: Table Of Contents
APPENDIX ......................................26 7.1. ETHERNET CONNECTION .............................. 26 7.2. ASSEMBLE THE WATERPROOF COVER OF THE RJ45 CONNECTOR ..........28 7.3. DISCONNECT THE RJ45 CONNECTOR ......................... 35 2/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 3 ADDING ALTERNATE IP ADDRESS .......................... 40 7.6. RESTORE FACTORY DEFAULTS ..........................41 7.7. POSITION OF THE STICKER ............................42 REGULATORY INFORMATION ..............................43 CONTACT INFORMATION ..................................44 3/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 4: Hardware Overview
EINAR Installation Guide HARDWARE OVERVIEW 4/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 5: Required Components
EINAR Installation Guide REQUIRED COMPONENTS In the box: • Einar ANPR/ALPR Camera • Bracket • IP67 Weather Cap for RJ45 Plug • Ground Terminal • 128GB MicroSD Card Optional: • ANPR and MMR license • Engine file • GPIO Cable Kit •... - Page 6 PC or laptop to configuration • Tools for applied mounting • Flat Head screwdriver for the junction box → • Phillips screwdriver for the junction box → 6/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 7: Recommended Installation Scenarios
(when the vehicle is near to the side of the lane or the plate is not at the middle of the vehicle). Try to adjust the direction of the camera so that the number plates are horizontal in the picture! 7/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 8 Adaptive Recognition channel. Also check Einar User Manual on page Einar ANPR Camera for Access Control & Parking - Adaptive Recognition's documents where additional installation tips can be found. Please note the following when mounting your camera: Please make sure that the camera does not roll neither to the left nor right.
-
Page 9: Installation Steps
Some examples for the accessories: Fuse: LITTELFUSE 0213.630 / EATON S506-630-R / SCHURTER 0034.3115. Power supply: MEAN WELL SDR-75-24 Some power injector order codes: Mouser: 485-435 Farnell: 3761249 9/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 10 IEC 62368-based safety standards. To reduce risk of fire, in case of DC power supply use a 630mA slow blow fuse series in one of the power wires. 10/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 11 Check the PoE+ power supply, if possible, try to use a different PoE+ power supply. Make a Factory reset of the camera. (See: Chapter 7.6.) If the above does not solve the issue please open a ticket in ATSS. 11/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 12: Assemble The Waterproof Cover Of The Rj45 Connector
The seal is then clamped to the cable with the clamping part D. Route the cable according to the image to avoid collecting rainwater at the socket. 12/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 13 'clicks' during the tightening process. The cable gland is watertight if it is properly tightened and the two inserts are positioned at the 5 o'clock and 11 o'clock positions, as shown in the image. 13/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 14 If the waterproof cover is not used, it will result in a loss of warranty! For more information about the detailed and proper assembly guide, see section 7.2 and section 7.3. 14/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 15: Insert The Microsd Card
Take care when fully releasing the screw, it can be dropped. To replace the cover, turn the screws clockwise. Do not overtighten the screws! Perform the operation in a clean, low-humidity room! 15/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 16: Mounting The Camera
In the case of concrete or brick walls, the following solution is often suitable: 3x Fischer DuoSeal 6 x 38 S PH TX A2 or, 3x Fischer DuoPower 8 x 40 + Fischer FPF II PTF 5,0 x 50 BC 100 16/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 17: Ground The Camera
The grounding of the STP / FTP cable is only allowed on the remote side (patch panel, PoE switch, server). 17/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM... -
Page 18: Adjust The View Direction Of The Camera
“knock down”, then set it to the desired position. The horizontal direction can be adjusted by loosening screw 1. If the device is in the correct direction, tighten all screws on the bracket. 18/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM... -
Page 19: Gpio Cable Connection
• Web browser: Mozilla Firefox 52, Microsoft Edge, Google Chrome 51.X.X.X or later editions. If it is possible, update your browser (Firefox or Chrome) to the newest available version. 19/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 20: Accessing The Web Interface
3. Type the username and the password on the displayed login interface and click on [Login]. 4. After signing in, the web interface of the camera is displayed on which the required settings can be performed. 20/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 21 You can find the camera on the network using the DeviceTool. Double-click on the selected camera, and the Einar camera web interface will open in the default browser. While running, the program continuously looks for detectible cameras on the network and displaysthem in a list with their current IP addresses.
-
Page 22: Safety
Care must be taken to replace the SD card cover. Improper installation can degrade the integrity of the enclosure, causing moisture penetrate into the camera. Power the camera with an IEEE802.3at compatible POE switch, injector or DC 48V power supply. 22/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 23 EINAR Installation Guide Avoid to clean the camera with high-pressure water jets! For detailed information see the User Manual: https://adaptiverecognition.com/doc/cameras/einar-anpr-camera-for-access-control-parking/ Check our website: https://adaptiverecognition.com/ 23/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 24: Maintenance
Immediately after wet wiping, use a dry microfiber wipe to polish the surface. Apply circular motions from the center outwards to remove any remaining streaks or stains. 5. Repeat if Needed: 24/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 25 (no spider webs or any other contaminants inhibit the visibility), there are no strange circumstances (vapor, damage). 25/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
-
Page 26: Appendix
Connector allocation standard: EIA / TIA-568B (straight cable pinout) Due to the POE power supply, all 4 pairs of wires must be connected even with a 10 / 100BaseTX data connection! 26/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 27 EINAR Installation Guide 27/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 28: Assemble The Waterproof Cover Of The Rj45 Connector
Thread the shielded ethernet cable through the elements of the connector housing as shown in the picture. Use at least a Cat5e-rated, outdoor, UV-resistant cable. Check the presence of the two red sealing rubbers. 28/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 29 Installation Guide Mount the shielded RJ45 connector on the cable. The shading stocking should hang out only slightly. Push the bayonet lock onto the connector housing. 29/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
- Page 30 Connect the RJ45 connector to the camera, then push the connector housing onto it so that the RJ45 connector fits into the cavity. For this, the fixing tab of the RJ45 jack must also be slightly pushed up. 30/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 31 EINAR Installation Guide Check that the sealing rubber of the connector housing fits properly from all directions 31/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 32 EINAR Installation Guide Secure the connector housing with the bayonet lock. 32/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 33 EINAR Installation Guide Fasten the cable with a sealing screw. Tighten it right! 33/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 34 Check that the connector housing closes to right angle to the back of the camera. Route the cable according to the image to avoid collecting rainwater at the socket. 34/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 35: Disconnect The Rj45 Connector
Installation Guide 7.3. DISCONNECT THE RJ45 CONNECTOR Always disassemble the connector in the following order! Loosen the sealing screw and then pull it back on the cable. 35/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 36 EINAR Installation Guide Release the bayonet lock, then pull it back on the cable. 36/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 37 EINAR Installation Guide Remove the RJ45 connector by pressing the fixing tab. 37/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 38: Io Connection
EINAR Installation Guide 7.4. IO CONNECTION EINAR IO waterproof connector and cable pin layout: PIN4: IO_I_N (black) PIN5: IO_I_P (brown) PIN6: IO_O_A (white) PIN7: IO_O_B (blue) 38/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 39 EINAR Installation Guide Einar camera connection diagram with IO cable and ParkIT junction box: Camera GPIO cables: • Blue: 3. Opto_out_G (-) • White: 4. Opto_out_S (+) • Brown: 4. Opto_in_S (+) • Black: 6. Opto_in_G (-) User side cables: •...
-
Page 40: Adding Alternate Ip Address
2. Enter the ifconfig command to see the reserved Ethernets (e.g. eth0). 3. Enter the following command: ifconfig ethY 192.0.2.25 where Y is a free eth (e.g. eth1) and 192.0.2.25 is a sample IP address. 40/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 41: Restore Factory Defaults
Perform the operation in a clean, low-humidity room! Further disassembly of the camera is prohibited, as this may void the warranty and damage the watertight insulation! 41/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... -
Page 42: Position Of The Sticker
The device data sticker is located at the bottom of the product and contains the following information: • Product type • MAC Address • Power data • Serial Number 42/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 43: Regulatory Information
European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. 43/44 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... -
Page 44: Contact Information
Web: adaptiverecognition.com/support/ Adaptive Recognition Hungary Technical Support System (ATSS) is designed to provide you the fastest and most proficient assistance, so you can quickly get back to business. Information regarding your hardware, latest software updates and manuals are easily accessible for customers via our Documents Site (www.adaptiverecognition.com/doc...
