- Page 1 Installation Guide This guide contains an overview of the hardware and required components, suggested scenarios and step-by-step guide for installation, and safety and maintenance instructions. © Copyright Adaptive Recognition Inc. 03.02.2025. All rights reserved.
-
Page 2: Table Of Contents
BACK OF CAMERA ................................14 INSTALLATION OF THE DEVICE ............................16 4.1. PREPARATIONS..................................16 4.2. USAGE OF TRIPOD ................................16 4.2.1. SET UP OF TRIPOD ............................... 16 2/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 3 EXTERNAL BATTERY CHARGING PROCESS .................... 23 INSERT SIM CARD..................................25 FOLD UP OF TRIPOD ..................................28 MAINTENANCE ....................................30 SAFETY ........................................32 REGULATORY INFORMATION ..............................34 CONTACT INFORMATION ..................................35 3/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 4: Introduction
Installation Guide INTRODUCTION The S1 Speed Camera installation guide provides detailed instructions for proper assembly, commissioning, operation, and maintenance. The system is designed to serve as an effective tool for documenting traffic violations, monitoring traffic, and performing other specialized tasks. This document offers comprehensive information on every aspect of the device to ensure a complete user experience. -
Page 5: Hardware Overview
361 mm × 371 mm × 224 mm (14.2” × 14.6” × 8.8”) Weight 10.2 kg (22.44 lbs.) In the box S1, military grade carrying case, power cable with 12V plug (car cigarette lighter), ethernet cable, external GPS adapter, lifetime Carmen® license plate recognition software, user guide... - Page 6 Installation Guide Camera side Camera side Camera back Camera front 6/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 7: Components
Installation Guide 2. COMPONENTS The box contains: • S1 Speed Camera • Case with Wheels • Cable Set (Ethernet, Cigarette Lighter Adapter) Optional: • External battery with power cable • External battery charger • Tripod with case • Car Seat Adapter Bracket •... -
Page 8: In The Box
Content Protection: Foam padding and compartments for various components. • Cable Set: The cable set provides essential connectivity options for the S1 Speed Camera. Ethernet Cable: Ensures a stable and high-speed wired network connection for data transfer • and remote monitoring. -
Page 9: Optional Accessories
Safety Features: Includes overcharge protection to prevent damage to the batteries. • • Compatibility: Works with standard power outlets (230V) and is optimized for the S1-specific battery units. The camera cannot be connected directly to the battery charger! Tripod with case: The tripod stand provides a stable placement for the camera system. - Page 10 GDS Central Application Software: The Globessy Data Server is a universal traffic data collection and visualization middleware for S1 Speed Camera. Centralized Data Management: Allows for real-time data aggregation from multiple S1 •...
-
Page 11: The Components Of The Camera
3.1. FRONT OF CAMERA Housing The S1 is designed with a housing structure that meets touch protection standards and ensures proper functionality within an external temperature range of -20°C to +50°C. Camera Modules On the front of the device, there are two controllable camera optics. Thanks to its zoom capability, the camera can be utilized over a wide range of distances. - Page 12 This advanced infrared illumination technology ensures clear and precise image capture under challenging lighting conditions, making it an indispensable feature for 24/7 operations. 12/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
-
Page 13: Left Side Of Camera
The camera is equipped with sensitive internal GPS and GSM antennas (2G, 3G, 4G). It is also compatible with external GSM antennas, which can be connected via the designated SMA plug (50 ohms). External 3G antenna is not included with the device. 13/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... -
Page 14: Back Of Camera
Recommended Shutdown Procedure Always use the shutdown button located in the bottom right corner of the touchscreen display to safely power down the system after completing all measurements. 14/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 15 If the device freezes and the above process does not resolve the issue, holding the power button for about 50–60 seconds will cut off the power supply and turn off the device. 15/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM...
-
Page 16: Installation Of The Device
6. Adjust height and lock patterns 7. Undraw legs until horizontal spreader is unbending You can adjust width of tripod with the fastening of horizontal spreader. 16/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 17 Installation Guide 8. Lock screw on horizontal spreader (3 pcs) 17/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 18 Clicking sound confirm right position of camera on the rail. 10. Ran fixing screw of the camera You can position S1 Speed Camera vertically and horizontally by release level handle under the rail of tripod.
-
Page 19: Vehicle Mount
Position the mount against the vehicle's seat backrest and use the included straps or screws to secure it firmly. Ensure the base of the mount rests evenly on the seat for stability. 19/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 20 Camera Attachment: Once the mount is installed, attach the tripod head to the top of the mount. Secure the S1 Speed Camera to the tripod head using the locking mechanism. Confirm that all connections are tight to prevent shifting during use.
-
Page 21: Fixed Installation
Installation Guide 4.4. FIXED INSTALLATION As an addition to the multi-year operation of the S1 under continuous personnel supervision, a new monitoring mode has been introduced. This mode is designed for use in fixed installations, such as boxes placed along roadsides, specifically tailored to house the S1 speed measurement device. -
Page 22: Power Supply
Installation Guide 4.5. POWER SUPPLY The power supply for the S1 Speed Camera is designed to ensure reliable and continuous operation, both in stationary and mobile deployments. Find below the detailed instructions for managing the power supply: • Battery Connection: The system uses high-capacity external batteries that connect to the device via specialized power cables. -
Page 23: External Battery Charging Process
EXTERNAL BATTERY CHARGING PROCESS 4.5.1. Recharging the external batteries of the S1 Speed Camera is an essential task to maintain uninterrupted operation. Find below the detailed instructions and precautions for charging: Preparation: •... - Page 24 Store the fully charged battery in a cool, dry place when not in use. These guidelines ensure the long-term reliability and safety of the external batteries, enabling consistent performance of the S1 Speed Camera during critical operations. 24/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM...
-
Page 25: Insert Sim Card
3. Remove heatsink screws and pads • Identify the heatsink that covers the internal components. • Unscrew the securing screws and remove any thermal pads carefully. 25/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 26 7. Put back heatsink screws and pads • Secure the heatsink by reattaching the screws. • Ensure that the thermal pads are correctly positioned for proper heat dissipation. 26/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
- Page 27 Verify that all screws are properly tightened and that no components are loose. • Ensure that the SIM card is properly inserted and recognized by the system upon powering on the device. 27/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
-
Page 28: Fold Up Of Tripod
5. Release lever-locks on the upper part of the tripod, push part together and fix locking. 6. Release fastening, push legs together and snap fixing locks. 28/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore... - Page 29 Installation Guide 29/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 30: Maintenance
Begin cleaning by gently wiping the surface from the center towards the edges using the moistened wipe. Use circular motions to cover the entire surface, moving from the center outwards. 30/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 31 Always use the sealing caps on the connectors to keep the camera unit waterproof! If you miss to use it, the warranty will be void! The maintenance of the devices is recommended on a quarterly basis. In case of extreme weather conditions more often. 31/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
-
Page 32: Safety
Regularly inspect power cables for signs of damage and replace them if necessary! Avoid exposing batteries to direct sunlight, extreme cold, or wet environments! Keep protective caps on unused connectors to prevent dirt, dust, or moisture from entering! 32/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM... - Page 33 If the system freezes, follow the extended power button press method (50–60 seconds) to safely cut off power! Clean the device with a soft, damp cloth! 33/35 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
-
Page 34: Regulatory Information
Laser safety compliance S1 Speed Camera which are equipped with a measuring laser module are Class 1 laser products according to the IEC 60825-1:2014 standard. -
Page 35: Contact Information
Web: adaptiverecognition.com/support/ Adaptive Recognition Hungary Technical Support System (ATSS) is designed to provide you the fastest and most proficient assistance, so you can quickly get back to business. Information regarding your hardware, latest software updates and manuals are easily accessible for customers via our Documents Site (www.adaptiverecognition.com/doc...
