- Page 2 Intercom panel Installation Instructions Interface description Front Back ①Speaker: restore the remote voice. ①Panel connection port. ②Status indicator light. ②Dial switch. The indicator light fast flash within the conversation; And the indicator is normal on when it`s free. If intercom terminal and server connection is abnormal, the indicator will be slowly flash.
- Page 3 Intercom panel Installation Instructions 3＃ 4＃ 5＃ 6＃ 7＃ 8＃ 9＃ 10＃ 11＃ 12＃ 13＃ 14＃ 15＃ 16＃ The 5 dial code switch to "ON" panel ID number as follows: Panel ID No. The 1st dial code The 2nd dial code 1＃...
- Page 4 Intercom panel Installation Instructions Installation diagram Note: Please use 16X7.5 (plug the top)and SPSI-09 plug if incoming line from the back; If incoming line from the top, please use SPSI-08 plug and Φ16 PVC casing, make the plug up side into PVC tube, then put the plug bottom into the shell. Packing list...
