NAS-8523DV
IP VIDEOINTERCOM TERMINAL
MAIN FUNCTIONS
Basic functions
Launch video intercom / alarm: the IP video intercom terminal includes two buttons, which can launch
full duplex video intercom / alarm to the preset target;
Receiving intercom: the IP video intercom terminal can receive the intercom initiated by other termi-
nals;
Receiving broadcast: the IP video intercom terminal can receive the broadcast initiated by the server
or other terminals;
Receiving monitoring: the IP video intercom terminal can receive monitoring initiated by other termi-
nals;
Support Onvif protocol;
Support standard SIP protocol;
Audio functions
Line input: the IP video intercom terminal can access other equipment audio signals as the intercom
sound source;
Line output: the IP video intercom terminal supports line output of audio signal;
Audio processing: built in digital audio processor to improve noise reduction effect, receiving distance
and audio quality;
Additional functions
Wide dynamic: it can automatically compensate backlight or suppress strong light according to the
scene to ensure high definition;
Power interface of fill light: provide power interface of fill light, users can connect infrared fill light;
Anti disassembly alarm: when someone forcibly disassembles it illegally, it can automatically send an
alarm to the management software;
Noisy alarm: when someone is noisy, brawling, fighting, etc., it can automatically send an alarm to the
management software;
Alarm output: with 1 channel alarm output, it can control the alarm light or door lock;
Alarm input: with one channel of alarm input, it can be externally connected with alarm button or probe.
IP VideoIntercom Terminal
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spon NAS-8523DV
Summary of Contents for Spon NAS-8523DV
- Page 1 IP VideoIntercom Terminal NAS-8523DV IP VIDEOINTERCOM TERMINAL MAIN FUNCTIONS Basic functions Launch video intercom / alarm: the IP video intercom terminal includes two buttons, which can launch full duplex video intercom / alarm to the preset target; Receiving intercom: the IP video intercom terminal can receive the intercom initiated by other termi- nals;...
- Page 2 IP VideoIntercom Terminal SPECIFICATIONS NAS-8523DV Codec protocol ADPCM、PCM、MP3 Audio Audio input Bulit in Mic (dwt-6502b) / microphone mast (dwt-6502a) parameters Audio samplingbit rate 8kHz～44.1kHz，16bit，8kbps-320kbps Video transmission bit 96Kbps-512Kbps Video rate parameters Camera CMOS, 720P Security Login password protection Network Support agreement TCP/IP、UDP、ARP、ICMP、IGMP、SIP、HTTP、FTP、...
- Page 3 IP VideoIntercom Terminal INTERFACE Front ① loudspeaker: amplify the remote sound; ② photoresistor: detect the ambient illumination and control the day / night mode of the camera; ③ wide angle camera: collect local video; ④ alarm button: press this button to call the target terminal specified by the server, trigger the alarm at the same time, and turn on the three-color door lamp or alarm lamp (without three-color door lamp);...
- Page 4 IP VideoIntercom Terminal ③ cascade port: connect the alarm control module, and the function definition is as follows: Note: one IP network HD video intercom terminal can connect two alarm control modules and one three color door lamp at the same time.
- Page 5 On the contrary, press the alarm button of nas-8523dv to initiate the call , it can also trigger the flashing of the alarm light to have a deterrent effect.
- Page 6 IP VideoIntercom Terminal Application 4 NAS-8523DV supports the monitoring function. The IP network visual console (such as NAS-8531V etc.) can monitor the dialogue and behavior of the suspects in the prison, and timely understand the psychological dynamics and behavior of the suspects in the prison.
