Summary of Contents for Spon NAS-8523CV
-
Page 2: Table Of Contents
Contents Summary ........................................... 1 Safety precaution ......................................1 Products introduction ....................................2 Hardware interface description ................................... 3 Introduction ........................................4 Packing list ........................................4 Wiring ..........................................5 Basic network settings ....................................5 User-defined terminal parameters ................................6 Log-in web page ......................................6 Network parameters ..................................... -
Page 3: Summary
IP Video HD Intercom Terminal User Manual Summary Safety precaution Please abide by the warning and the relevant safety tips. Please take this manual in convenient place after you reading the guide for future reference. Warning The sign means there is potential safety hazard, when operate wrong may result in death or serious injury. The sign is used to remind the user that attached is the important operation and maintenance data. -
Page 4: Products Introduction
IP Video HD Intercom Terminal User Manual Products introduction IP video HD intercom terminal which is embedded with IP Audio digital audio technology of independent intellectual property right, equipped with HD camera, power input interface, alarm input, line input, line(or recording) output port, combined with other camera device, it can support two-way video intercom. -
Page 5: Hardware Interface Description
IP Video HD Intercom Terminal User Manual Hardware interface description 【Front】 【Back】 【Front】 ①Loudspeaker :amplify the remote sound. ②Photoresistor: test the ambient illumination, control camera day and night mode. ③Wide angle camera: collect local video. ④Alarm button: click this button to call the target terminal named by the server and trigger alarming, lighten the three color door light or alarm light(it can’t connect the three color door light) ⑤Intercom button: click this button to call the target terminal named by server. -
Page 6: Introduction
IP Video HD Intercom Terminal User Manual Introduction Packing list IP HD video intercom terminal includes follow parts, checking all the parts before install it ,if any parts are missing ,please contact with your distributor (1) IP HD video intercom terminal 1 pcs (2) Wiring terminal (3.5-3P) 1 pcs (3) Wiring terminal (3.5-4P) 1 pcs (4) Wiring terminal (3.5-6P) 1 pcs... -
Page 7: Wiring
IP Video HD Intercom Terminal User Manual (8) Quick installation manual 1 pcs （9）Certification 1pcs Wiring (1) Use one end of the power adapter to connect with the power port of IP video intercom terminal, the other end connect with the power socket. （2）Use one end of the Ethernet cables to connect with the IP video intercom terminal, the other end connect with the switcher. -
Page 8: User-Defined Terminal Parameters
IP Video HD Intercom Terminal User Manual User-defined terminal parameters Log-in web page (1) Please input the network intercom terminal IP address to the browser address column (the factory default IP address is 192.168.1.101, it will automatically play the IP address when press the terminal key without the cable inserted), then enter. -
Page 9: Network Parameters
IP Video HD Intercom Terminal User Manual Network parameters The parameters specification as following: The only number to identify the terminal, it can’t repeat with other terminal or host, Terminal ID the factory default is 1. Notes: otherwise the special condition of the port, please don’t modify randomly.(the Local port factory default is 2046) Terminal IP... -
Page 10: Sip Parameters
IP Video HD Intercom Terminal User Manual Version server IP, when the terminal restart it can connect to the version server to Version server update program automatic. File server IP, it can download the file contents named by server to the SD card or FTP server built-in Flash through FTP . -
Page 11: Audio Parameters
IP Video HD Intercom Terminal User Manual Audio parameters Parameter specification as following: The sound source input of intercom Talking input select Microphone: the sound source is microphone input; Line input: collect audio of external device as the intercom input sound source. The audio output way of intercom Talking output... -
Page 12: Talk Parameters
IP Video HD Intercom Terminal User Manual Talk parameters Parameter as following: Setting up the mode of terminal receiving talking, start for automatic answering; If Auto answer forbidden, please pressing the button to turn on the talking. Setting terminal hang up ways. Disabled, intercom can’t be hung up; Enabled, Allow to hang up terminal can hang up. -
Page 13: Alarm Parameters
IP Video HD Intercom Terminal User Manual Alarm parameters Parameters specification as following: Alarm source is “emergency alarm” port of external alarm control module, alarm trigger modes are following three kinds. Open circuit alarm: when the port is off to trigger alarm: Close circuit alarm: closed port to trigger alarm;... -
Page 14: Password Setting
IP Video HD Intercom Terminal User Manual Disabled, the terminal can’t detect the door magnetic state. Priority level as the above. Enabled, terminal will automatically alarm if the environment volume reaches a certain level and lasting a period time. Hubbub alarm Hubbub disabled, can’t realize such functions, priority level as the above Terminal make the hubbub alarm, three color door light is on(flashing in cyan),when alarm is disabled, light will be off. -
Page 15: Language Setting
IP Video HD Intercom Terminal User Manual Language Setting You can switch Web language between Chinese and English, save the revise and restart WEB to come into effective. Update Firmware (Note: Otherwise special needs, please do not update the firmware ) click the "browse"，Choose the factory offered firmware update file, click "Update"... -
Page 16: Reboot Device
IP Video HD Intercom Terminal User Manual Reboot device Click “Reboot” to manual reboot the terminal. System Log Terminal can record device application condition and make the log, user can browser the system log in web page. -
Page 17: Other Functions
IP Video HD Intercom Terminal User Manual Other functions In addition to above function, IP network HD intercom terminal could coordinate with the server to accomplish the timing ringing, real-time broadcasting and the timing broadcasting all these functions, for the details please refer to the server software operation instruction. -
Page 18: Trouble Removal
IP Video HD Intercom Terminal User Manual Trouble Removal Terminal can not login to the server? 1. Check the server software and main control computer is normally open or not. It must close all the firewall before open the service software, (including the systemic firewall and other antivirus software.). 2. -
Page 19: Copyright Statement
Only for private use, downloading and printing of the manual is not prohibited when it is spreading on internet and media. No part of the manual is allowed to be reproduced or used for commercial purpose. And SPON shall take no responsibility for any losses or damages caused by the illegal reproduction and conversion of the manual.
