Summary of Contents for Spon IP NETWORK INTERCOM TERMINAL
-
Page 2: Table Of Contents
Contents Summarize ..................................1 Safety precaution ...................................1 Product Presentation ................................2 Hardware Interface Introduction ............................2 Introduction ..................................4 Packing List .................................... 4 Connection Diagram ................................5 Basic Network Setting ................................6 User-Define Terminal Parameters ..........................7 Login Web Interface ................................7 Basic Setting ...................................8 Network Parameters ................................... -
Page 3: Summarize
IP Network Intercom Terminal User Manual Summarize Safety precaution Please abide by the warning and the relevant safety tips. Please take this manual in convenient place after you reading the guide for future reference. Warning The sign means there is potential safety hazard, when operate wrong may result in death or serious injury. -
Page 4: Product Presentation
IP Network Intercom Terminal User Manual Product Presentation IP network intercom terminal is embedded with the independent intellectual property rights IP Audio digital network audio technology. The terminal equipped with power input interface、short circuit input and output、audio power output、audio line etc ports. - Page 5 IP Network Intercom Terminal User Manual Back ①Power input: connect to 12V DC power supply (with anti-power connection and anti-protection circuit). ②Alarm input/ output: Alarm input port has two pins, the two pins` state won`t affect the audio terminal working state in normal use, only when the two pins are short sub, then the audio terminal will make some special operations automatically (eg: generate an alarm signal and sent to the server or give an alarm from the local terminal etc.) Alarm button, signal generator all these devices...
-
Page 6: Introduction
IP Network Intercom Terminal User Manual Introduction Packing List IP network intercom terminal contains the following accessories. Please check the accessories before installation, if you find any missing, please contact your supplier. IP Network Intercom Terminal 1PCS （2）Power adapter（DC12V/1.5A）1PCS(Optional) （3）Plastic expansion suit (F7) 3PCS （4）Half round head Phillips screw (ST4*25) 3PCS... -
Page 7: Connection Diagram
（9）Quick Install Manual 1PCS Connection Diagram （1）Connect one end of the power adapter to the DC12V of the IP network intercom terminal, and the other end to the power socket （2）Alarm output interface can be connected to the electric lock. -
Page 8: Basic Network Setting
3. If you need IP audio terminal configuration tools, please contact our customer service. Web Page Mode Enter the IP network intercom terminal web interface, then revise the terminal network parameters according to the live environment, after finish Setting, click "save". -
Page 9: User-Define Terminal Parameters
Note: Google browser is recommended, IE browser is not supported. （2）In the login window enter the user name and password (the default is admin). （3）Press [Login] to enter the IP network intercom terminal web page. The home page displays the running status of the terminal... -
Page 10: Basic Setting
IP Network Intercom Terminal User Manual Basic Setting Network Parameters Set the network parameters, please modify the parameters in the network parameters according to the on-site environment. After the setting is completed, click [Save] to restart the device to take effect. -
Page 11: Protocol Settings
IP Network Intercom Terminal User Manual Protocol settings Set the communication protocol between the terminal and the server, and the server platform parameters of the terminal login. After setting, click [Save], the device will be restarted automatically, and the reboot will take effect. -
Page 12: Quick Call
IP Network Intercom Terminal User Manual protocol, just set the NAS local port (default is 2048). Set whether to enable jitter buffer function, when it is enabled, set the jitter Jitter buffer buffer size. enable, jitter If it is enabled, it can improve the audio quality in a poor network environment buffer size (such as network packet loss). -
Page 13: Offline Intercom
IP Network Intercom Terminal User Manual Offline intercom Set whether to enable the offline intercom function. After the settings are saved, manually restart the device to take effect. (You can restart the device by pressing the [Restart] button in the "Device Maintenance"-"System Tools" interface) -
Page 14: Intercom Parameter
IP Network Intercom Terminal User Manual Intercom Parameter Set the terminal intercom parameters, click [Save] after modification, and the reboot will take effect. Parameters meaning as following： Terminal intercom audio input mode, can choose microphone, line input, Input automatic recognition. -
Page 15: Broadcast Parameters
IP Network Intercom Terminal User Manual Broadcast Parameters Set the terminal broadcast parameters, click [Save] after the modification is complete, and restart the device to take effect. Parameter meaning as following Terminal broadcast audio input mode, can choose microphone, line input, Input automatic recognition. -
Page 16: Listener Parameters
IP Network Intercom Terminal User Manual Listener Parameters Set the terminal monitor parameters, click [Save] after the modification is complete, and restart the device to take effect. Parameter meaning as following: Audio input mode when terminal is monitored, microphone, line input and... -
Page 17: Alarm Parameters
IP Network Intercom Terminal User Manual Alarm Parameters Set the terminal alarm input parameters, click [Save] after the modification is complete, and restart the device to take effect. Parameter meaning as following: According to the alarm parameters to obtain the corresponding channel Input channel number, the default is 1. -
Page 18: Advanced Settings
IP Network Intercom Terminal User Manual Advanced Settings Web Management The password for logging in to the web page can be modified in the Web management parameters. The default password is "admin". After the password modification is saved, restart the browser to take effect. -
Page 19: Equipment Maintenance
IP Network Intercom Terminal User Manual Equipment maintenance system tools （1）Reboot Device In the [Device Maintenance]-[System Tools] interface, click the [Restart] button, and the device will restart. （2）Restore factory setting In the [Device Maintenance]-[System Tools] interface, click the [Restore Factory Settings] button to restore all the device settings to the factory default state. -
Page 20: System Log
IP Network Intercom Terminal User Manual System Log The terminal can record the operation of the equipment and generate a log. Click the [download] button on the right to download the system log for viewing (TXT format). Version Enter the version information interface, you can view the terminal software version. -
Page 21: Basic Function
IP Network Intercom Terminal User Manual Basic Function Initiate Intercom Press the left key or the right key to directly call the called terminal designated by the server. Remarks: (1) If the communication protocol between the terminal and the server is the SIP protocol, the call destination of the left and right buttons can be set in the "terminal management"... -
Page 22: Malfunction Test
IP Network Intercom Terminal User Manual Malfunction Test The terminal is always offline 1).Check the software server and the main controller is normal opened or not. It`s required to close all firewall before open the software server (including system built-in firewall and other antivirus software firewall) 2).Check the network connection is normal or not. -
Page 23: Copyright Announcement
User should take the responsibility of the products applying. SPON shall not making any guarantee for the handbook, including but not only for the guarantee of implied marketability and specific purpose. Also SPON shall not take any responsibility, if any indirect or incidental...
