Summary of Contents for Spon 9201
-
Page 2: Table Of Contents
Contents Summary ......................................1 Safety Precaution ......................................... 1 Product Introduction ......................................2 Interface Description ......................................2 Introduction ......................................3 Packing List ........................................... 3 Basic Network Setting ......................................4 User-Define Terminal Parameters ..............................5 Login Web Interface ......................................5 Net Options ........................................... 6 SIP Options ........................................... -
Page 3: Summary
IP network intercom terminal User Manual Summary Safety Precaution Please abide by the warning and the relevant safety tips. Please take this manual in convenient place after you reading the guide for future reference. Warning The sign means there is potential safety hazard, when operate wrong may result in death or serious injury. -
Page 4: Product Introduction
IP network intercom terminal User Manual Product Introduction IP network intercom terminal embedded SPON independent intellectual property rights - IP audio digital network audio technology, the terminal is equipped with power input interface, audio power output and other ports. Suitable for extremely harsh environments (such as: high noise, high dust and dust, strong acid and alkali, high temperature and low temperature, etc.) communication. -
Page 5: Introduction
IP network intercom terminal User Manual Hands-free call button “ ” Button Emergency call button, press it to call the server mapping “CALL” Button target ID directly. “PA” Button Initiate broadcast. Note: When picking up the handset, the digital zone light is normally on, and it is normally off when the handset is put down. -
Page 6: Basic Network Setting
IP network intercom terminal User Manual （4）Police light and supporting mounting plate 1sets (including assembly screws)(optional) （5）Certification 1pcs （6）Installation Instructions 1pcs Basic Network Setting After the terminal is connected according to the Installation Instruction, turn on the power and change the network parameters of the terminal according to the environment in the field. -
Page 7: User-Define Terminal Parameters
IP network intercom terminal User Manual Note: 1、When using the Windows 7 operating system, please use the administrator mode, and then shut down the firewall and the related software. 2、Terminal equipment scanning tools can only configure one terminal. When using this method, please make sure that the computer is only corresponding to one target terminal. -
Page 8: Net Options
IP network intercom terminal User Manual Net Options Set the local IP address (factory default IP is 192.168.1.101), subnet mask, default gateway and other related parameters. SIP Options Set the SIP server IP (the default IP address is 192.168.1.13), the account number (that is, the local ID number), the password and the network port. -
Page 9: Audio Options
IP network intercom terminal User Manual Audio Options The parameters are as follows: The total volume (0~15) entered by the terminal during talk Talking Input Volume Note: This setting is only effective when the terminal is offline, and the volume is controlled by the server when the terminal is online. -
Page 10: Talk Options
IP network intercom terminal User Manual Talk Options The parameters are as follows: Set the way the terminal answers the talk. When it is enabled, it is automatically Auto Answer answered. If it is disabled, you need to pick up the handset or press the “Hands-free”... -
Page 11: Alarm Options
IP network intercom terminal User Manual Alarm Options The parameters are as follows: Pannel speaker testing When enabled, the device will sound "drop" when it starts successfully. When enabled, the ambient volume of the terminal reaches a certain level Noise alarm and the terminal will automatically alarm for a certain period of time;... -
Page 12: Update Firmware(Note: Do Not Upgrade The Firmware Unless You Have Special Needs)
IP network intercom terminal User Manual Update Firmware(Note: Do not upgrade the firmware unless you have special needs) On the update firmware page, click "Browse", select the upgrade file provided by the manufacturer, and then click the "Update" button to start the update. Note: Do not power off during the update process. Otherwise, the update may fail and the device may fail. -
Page 13: Reboot
IP network intercom terminal User Manual Reboot Click "Reboot" to manually restart the terminal. System Logs The terminal can record the running status of the device and generate a log, and the user can browse the system log on the web page. -
Page 14: Basic Functions
IP network intercom terminal User Manual Basic Functions Emergency Call Press the [CALL] button, call the target terminal specified by the service software with one button, and press the [CALL] button again to end the talk. Initiate Talk . Pick up the handset, press the number keys to enter the target terminal ID number, press the "Confirm" button to initiate the call, press the cancel button or hang up the handset to end the call. -
Page 15: Custom Ringtone
IP network intercom terminal User Manual Custom Ringtone Enter terminal FTP://terminal IP (username and password are admin by default), and place 8k sampling rate and mono wav format audio files in the FTP root directory. The file naming requirements are as follows: Intercom ringtone：in_calling.wav Intercom outgoing ringtone：out_calling.wav Broadcast start tone：BroadcastStart_8k.wav... -
Page 16: Copyright Statement
Only for private use, downloading and printing of the manual is not prohibited when it is spreading on internet and media. No part of the manual is allowed to be reproduced or used for commercial purpose. And SPON shall take no responsibility for any losses or damages caused by the illegal reproduction and conversion of the manual.
