METHVEN WAIPORI Installation Manual

Equal High Pressure (Mains) Installation:
Install mixer as supplied
Unequal Pressure and Equal Low Pressure Installation*:
Remove flow restricted (green) aerator using cache key.
Replace with unrestricted (blue) aerator.
Unequal Pressure Installation*:
Cold
Install the brass nipple into the cold inlet hose.
*Note: Unrestricted aerator and brass nipple not included in some regions.
Care and Cleaning:
Never use abrasives or abrasive cleaning agents to clean this product. Clean regularly with
contamination free warm soapy water and a damp soft cloth.
Periodically the stream shaper should be removed as shown above and cleaned under running water.
Methven warrants this product against manufacturing defects and that it is suitable for use
under the general operating conditions specified in this instruction sheet. However, regional
regulations apply and may a°ect y our warranty. Please refer to www.methven.com or call
customer service for full details.
New Zealand
0800 804 222
IS2060
Australia UK
13 14 16
0800 195 1602
WAIPORI SINK MIXER
INSTALLATION GUIDE
TECHNICAL SPECIFICATIONS
Operating Pressure:
Min 35kPa, Max 1000kPa.
Recommended 35kPa - 500kPa.
Recommended installation of a pressure
limiting valve if supply exceeds 500kPa.
Operating Temperature:
Hot: Max 70°C.
Cold: Min 5°C.
AS/NZS 3500 requires all hot water supplies to any
sanitary fitting to be tempered to 50°C
Inlet Connections:
All ½" BSP.
This product complies with the Lead Free requirements
of the National Construction Code Volume Three.
* Regional specific regulations apply. Please refer to your
warranty statement at www.methven.com
Issue A www.methven.com
