- Page 1 Cordless Impact Wrench INSTRUCTION MANUAL Boulonneuse sans Fil MANUEL D’INSTRUCTIONS Akku - Schlagschrauber BETRIEBSANLEITUNG Avvitatrice ad impulso a ISTRUZIONI PER L’USO batteria Accuslagmoersleutel GEBRUIKSAANWIJZING MANUAL DE Llave de Impacto Inalámbrica INSTRUCCIONES Chave de Impacto a Bateria MANUAL DE INSTRUÇÕES Κρουστικό κλειδί μπαταρίας ΕΓΧΕΙΡΙΔΙΟ...
- Page 2 Fig.4 Fig.1 Fig.5 Fig.2 Fig.6 Fig.3...
- Page 3 Fig.10 Fig.7 Fig.11 Fig.12 Fig.8 Fig.13 Fig.9...
- Page 4 Fig.14 Fig.15 Fig.16...
-
Page 5: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model: TW001G TW002G TW003G Fastening capacities Standard bolt M12 - M36 High tensile bolt M10 - M27 Square drive 19.0 mm 12.7 mm No load speed (RPM) Max impact mode (4) 0 - 1,800 min Hard impact mode (3) 0 - 1,400 min 0 - 1,000 min 0 - 1,200 min... -
Page 6: Safety Warnings
SAFETY WARNINGS WARNING: Wear ear protection. WARNING: The noise emission during actual use of the power tool can differ from the declared General power tool safety warnings value(s) depending on the ways in which the tool is used especially what kind of workpiece is WARNING Read all safety warnings, instruc- processed. -
Page 7: Functional Description
Do not touch the terminals with any con- CAUTION: Only use genuine Makita batteries. ductive material. Use of non-genuine Makita batteries, or batteries that Avoid storing battery cartridge in a con- have been altered, may result in the battery bursting tainer with other metal objects such as causing fires, personal injury and damage. It will nails, coins, etc. - Page 8 Electric brake recharged battery(ies). Let the tool and battery(ies) cool down. This tool is equipped with an electric brake. If the tool If no improvement can be found by restoring protection consistently fails to quickly stop after the switch trigger system, then contact your local Makita Service Center. is released, have the tool serviced at a Makita service center. Indicating the remaining battery Lighting up the front lamp capacity Press the check button on the battery cartridge to indi- CAUTION: Do not look in the light or see the cate the remaining battery capacity. The indicator lamps...
- Page 9 approximately 10 seconds after releasing the switch Reversing switch action trigger. With the lamp status OFF, the lamp does not turn on CAUTION: even if pulling the trigger. Always check the direction of ► Fig.4: 1. Lamp rotation before operation. CAUTION: ► Fig.5: 1. Button Use the reversing switch only after the tool comes to a complete stop.
- Page 10 Auto-stop mode Auto-stop mode helps for good control when driving bolts. This mode has 3 steps. It also works differently for clockwise and counterclockwise rotation. Main purpose • Clockwise: Reduce the risk of breakage of bolts/nuts due to overtightening. • Counterclockwise: Prevent a bolt from falling off. When loosening a bolt, the tool automatically stops or slows down after the bolt/nut has been loosened enough. The type of the auto-stop mode changes every time you press the button NOTE: The timing to stop the driving varies depending on the type of the bolt/nut and material to be driven. Make a test driving before using this mode. NOTE: This mode works only when the switch trigger is fully pulled.
-
Page 11: Operation
position in the impact socket groove to retain the pin. Ring To remove the impact socket, follow the installation procedures in reverse. Country specific ► Fig.10: 1. Impact socket 2. O-ring 3. Pin CAUTION: Before using the ring, always For impact socket without O-ring and pin make sure that the bracket and ring are secured and not damaged. -
Page 12: Maintenance
► Fig.16: 1. Hammer case NOTE: Hold the tool pointed straight at the bolt or nut. CAUTION: These accessories or attachments NOTE: Excessive fastening torque may damage the are recommended for use with your Makita tool bolt/nut or impact socket. Before starting your job, specified in this manual. The use of any other always perform a test operation to determine the accessories or attachments might present a risk of proper fastening time for your bolt or nut.
