Page 2
SPECIFICATIONS Model: TW001G TW002G TW003G Fastening capacities Standard bolt M12 - M36 High tensile bolt M10 - M27 Square drive 19.0 mm 12.7 mm No load speed (RPM) Max impact mode (4) 0 - 1,800 min Hard impact mode (3)
Page 3
The typical A-weighted noise level determined accord- declared value(s) depending on the ways in which ing to EN62841-2-2: the tool is used especially what kind of workpiece Model TW001G is processed. Sound pressure level (L ) : 103 dB (A) WARNING:...
Page 4
or moving parts. Damaged or entangled cords increase the risk of electric shock. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
Page 5
Battery tool use and care The proper fastening torque may differ depending upon the kind or size of the bolt. Recharge only with the charger specified by Check the torque with a torque wrench. the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire Make sure there are no electrical cables, water when used with another battery pack.
Page 6
18. Keep the battery away from children. SAVE THESE INSTRUCTIONS. CAUTION: Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. Tips for maintaining maximum battery life Charge the battery cartridge before completely discharged.
Page 7
To start the tool, simply pull the switch trigger. Tool Charge the battery(ies) or replace it/them with speed is increased by increasing pressure on the switch recharged battery(ies). trigger. Release the switch trigger to stop. Let the tool and battery(ies) cool down. If no improvement can be found by restoring protection system, then contact your local Makita Service Center. Indicating the remaining battery capacity Press the check button on the battery cartridge to indi- cate the remaining battery capacity. The indicator lamps light up for a few seconds. Fig.3 ► 1 . Switch trigger NOTE: The tool automatically stops when you keep pulling the switch trigger for about 6 minutes.
Page 8
ON. When the lamp does not come This tool is equipped with an electric brake. If the tool on, the lamp status is OFF. consistently fails to quickly stop after the switch trigger is released, have the tool serviced at a Makita service NOTE: When the tool is overheated, the light flashes center. for one minute, and then the LED display goes off. In this case, cool down the tool before operating again.
Page 9
You can change the impact force in four steps: 4 (max), 3 (hard), 2 (medium), and 1 (soft). The level of the impact force changes every time you press the button Fig.7 Operation mode Maximum blows (min (/min)) Purpose (Impact force grade displayed TW001G TW002G TW003G on panel) 4 (Max) 2,500 2,400 2,400 Tightening when the force and the speed are desired.
Page 10
Auto-stop mode Auto-stop mode helps for good control when driving bolts. This mode has 3 steps. It also works differently for clockwise and counterclockwise rotation. Main purpose • Clockwise: Reduce the risk of breakage of bolts/nuts due to overtightening. • Counterclockwise: Prevent a bolt from falling off. When loosening a bolt, the tool automatically stops or slows down after the bolt/nut has been loosened enough. The type of the auto-stop mode changes every time you press the button NOTE: The timing to stop the driving varies depending on the type of the bolt/nut and material to be driven. Make a test driving before using this mode. NOTE: This mode works only when the switch trigger is fully pulled.
Page 11
For impact socket with O-ring and pin When full speed mode is turned on, the tool speed becomes fastest of the selected operation mode even if Only for model TW001G you do not pull the switch trigger fully. When full speed Move the O-ring out of the groove in the impact socket mode is turned off, the tool speed increases as you and remove the pin from the impact socket.
Page 12
Tool with the detent pin The hook is convenient for temporarily hanging the tool. This can be installed on either side of the tool. To install For tool with firm fit detent pin the hook, insert it into a groove in the tool housing on either side and then secure it with two screws. To Only for model TW003G remove, loosen the screws and then take it out.
Page 13
1. Fastening time (second) 2. Fastening torque CAUTION: If the tool is operated continu- ously, do not touch the hammer case. The hammer case may be extremely hot and could burn your skin. Fig.15 Model TW001G/TW002G Proper fastening torque for high tensile bolt with max impact mode (4) N•m (kgf•cm) 1600...
Page 14
To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. •...
