- Page 1 DC30 Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction General Warranty Symbols used in this manual and on the charging station Device description Application Accessories Safety features Safety Safety instructions Mandatory checks before initial use Operation / installation manual Wall mounting Mounting on a frame Open the cover Template for drilling holes Insert cable and attach strain relief... -
Page 3: Introduction
1. INTRODUCTION Thank you for selecting an Ecotap® DC Charger. This manual contains important information on correct and safe installation and use of the DC Charger. The charging station was designed for charging vehicles fitted with a mode 4 charging system and a CHAdeMO connector plug or a CCS2 connector plug. -
Page 4: Device Description
Electrical hazard For maintenance: first disconnect the installation from its power supply and test it to make sure there is no voltage left, before engaging in any maintenance activities Wear special gloves. Disconnect the electrical installation from its power supply Reading this manual is mandatory 3. -
Page 5: Mandatory Checks Before Initial Use
- Make sure that the charging station, tools and components will stay dry when it is raining. - After maintenance, make sure that all doors and/or panels are closed and locked before putting the charger back into operation! Make sure that there is no danger of anyone tripping over objects or paving while you are digging the hole for the foundation. - Page 6 Figure 1 Figure 2 Figure 3 www.ecotap.nl 11-03-25...
-
Page 7: Open The Cover
6.3 Open the cover Proceed as follows to open the cover. Use a screwdriver bit to remove the screws on the bottom of the charger. See figure 1 The cover can then be removed by sliding de cover to the side and then upward. To close the cover, perform this procedure in the reverse order. -
Page 8: Led Indication
6.6 LED indication Charger not working: No LED indication Charger switched on and not used: Flashing green 1 time per interval Charger charged and used Continuous blue Charger busy with network connection Steady red Charger malfunctioning Flashing red 6.7 For explanations of the various failures, see table in annex 7. -
Page 9: Technical Specifications
To stop the charging process, briefly hold the pass in front of the scan point. The charging process will be stopped. Remove the plug and put it back in its holder. The vehicle may have to be unlocked by means of a button on the vehicle to release the plug. - Page 10 DC output power range 1 - 30 kW DC output voltage range 200 - 1000 Vdc DC output current range 0 - 100A ≤ ±0.5% DC output voltage stabilized accuracy ≤ ±1% DC output current stabilized accuracy Effciency > 95% @full charge THDi (Total harmonic distortion) <...
-
Page 11: Contact Details Supplier
Protection rating IP 54 (IEC 60529), IK 10 (EN 62262) Plugged in or not Vandalism resistence IK 10 Noise level < 68 dB at 1m at 20° C, at full charging IEC 61851-1, IEC TS 61439-7 (AEVCS), IEC 61851-23, IEC 62477-1, Product IEC 61439-1 DC standard protocol (communications with the vehicle) -
Page 12: Eu Conformity Statement
13. EU CONFORMITY STATEMENT (Directive 2014/35/EU, Annex II page 96/369, EMC 2014/30/EU) Ecotap® B.V. Kruisbroeksestraat 23, 5281RV Boxtel, the Netherlands, hereby states that the following charging station meets the requirements of the listed directives and standards. Type: Ecotap® DC 30 Year of construction: 2019 EU directives used: - Low-voltage directive 2014/35/EU... -
Page 13: Annex
14. ANNEX If you have a problem, you can find a description of the message in the table below: Number of LED Status Description Solution flashes RCD error Check the RCD position (short circuit, differential problem) Check the installation Check differential current Replace the RCD by an Ecotap spare part Channel blocked Card identification un-... - Page 14 Energy meter failure Check that the Energy Meter works well Check the Modbus configuration (controller, Meter) Check the RS485 cabling inside the charger Check the presence of the 120 Ohms resistors (one on controller side, one on terminal block OR meter side) Replace the Energy Meter by an Ecotap spare part Fuse tripped Check the current configuration according to the protection (taking into...
- Page 15 Ecotap B.V. Kruisbroeksestraat 23 5281 RV Boxtel The Netherlands +31(0) 411 210 210 info@ecotap.nl www.ecotap.nl...
