Summary of Contents for LEGRAND Ecotap DC30
- Page 1 DC30 Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction General Warranty Symbols used in this manual and on the charging station Device description Application Accessories Safety features Safety Safety instructions Mandatory checks before initial use Operation / installation manual Wall mounting Mounting on a frame Open the cover Template for drilling holes Insert cable and attach strain relief... -
Page 3: Introduction
1. INTRODUCTION Thank you for selecting an Ecotap® DC Charger. This manual contains important information on correct and safe installation and use of the DC Charger. The charging station was designed for charging vehicles fitted with a mode 4 charging system and a CHAdeMO connector plug or a CCS2 connector plug. -
Page 4: Device Description
For maintenance: first disconnect the installation from its power supply and test it to make sure there is no voltage left, before engaging in any maintenance activities Wear special gloves. Disconnect the electrical installation from its power supply Reading this manual is mandatory 3. -
Page 5: Mandatory Checks Before Initial Use
Make sure that there is no danger of anyone tripping over objects or paving while you are digging the hole for the foundation. Make sure to wear good, suitable gloves for any special actions throughout the entire installation and connection process. Always check any measuring instruments you will be using to disconnect the installation from its power supply before you use them, checking them several times to make sure they are working properly. - Page 6 Figure 1 Figure 2 Figure 3 www.ecotap.nl 30-08-23...
-
Page 7: Open The Cover
6.3 Open the cover Proceed as follows to open the cover. Use a screwdriver bit to remove the screws on the bottom of the charger. See figure 1 The cover can then be removed by sliding de cover to the side and then upward. To close the cover, perform this procedure in the reverse order. -
Page 8: Maintenance
7. MAINTENANCE Always disconnect the charging station from the power supply and read the manual before performing maintenance or fixing a malfunction. Only products approved by the supplier can be used to repair or replace components. Repairs and replacements should always be carried out by a certified specialist. Maintenance should always comply with and be carried out in accordance with NEN3140 and NEN50110 low voltage EU regulations. -
Page 9: Technical Specifications
11. TECHNICAL SPECIFICATIONS GENERAL CHARACTERISTICS Reference number 80030042, 80030008 Dimension H x W x D (mm) 710 mm x 480 mm x 225 mm Casing material Steel 2,2 mm Standard colour Body: Ral 7011 / Cover: Ral 9016 Steel treatment Anti-corrosion (KTL) and powder coating Weight (kg) 57 kg... - Page 10 Type of load Mode 4 charging terminal Use of extension and adapter prohibited. Vehicle connection Mode 4 attache cable connector 3.5m straight AC meter Not included DC meter Not included Back office protocol OCPP 1.6 Json Positioning Connectivity Ethernet RJ45 connector ENVIRONMENT Operating temperature -25°C / +50°C...
-
Page 11: Contact Details Supplier
12. CONTACT DETAILS SUPPLIER Ecotap® B.V. Kruisbroeksestraat 23 5281RV Boxtel – The Netherlands Tel.: 0031 (0) 411-210210 E-mail: info@ecotap.nl 13. EU CONFORMITY STATEMENT (Directive 2014/35/EU, Annex II page 96/369, EMC 2014/30/EU) Ecotap® B.V. Kruisbroeksestraat 23, 5281RV Boxtel, the Netherlands, hereby states that the following charging station meets the requirements of the listed directives and standards. - Page 12 Ecotap B.V. Kruisbroeksestraat 23 5281 RV Boxtel The Netherlands +31(0) 411 210 210 info@ecotap.nl www.ecotap.nl...
