DESCRIPTION
The digital call panel includes a camera (horizontal and vertical
adjustment 10 degrees) with auto iris lens complete with LED's
for illumination, a 2 x 16 character LCD display with back light-
ing, keypad illumination plus a keypad with 15 or 18 push but-
tons depending on the panel version.
The panel with the repertory name has 15 buttons 3 of which
for the repertory management, 10 numeric buttons (0..9) plus
ENTER and CLEAR. While the standard panel has 18 buttons, 10
numeric buttons (0..9) plus ENTER and CLEAR and 6 alphabetic
buttons (A..F).
Both version have speech board (with volume adjustment) facil-
ity which guides the visitor through verbal messages. The panel
allows the connection of an external coax camera for which pro-
vide also the 12Vdc power supply (150mA max).
You can set, between the panel built-in camera and the external,
which is the main camera by the switch 1 of the two way dip-
switch bank located near the connection terminals: the main
camera is the one from which the video came on a call or camera
recall, anyway the other camera can be switched by the proper
videophone push button.
AVAILABLE VERSIONS
Art. 4302N Art. 4302NR
Audio only Audio only
with repertory
name
Art. 4302N - Installation instructions
Digital call panel
A
B
C
D
E
Art. 4302NRV
Art. 4302NV Art. 4302NRV
Audio/video Audio/video
with repertory
Fig. 2
LEGEND
Camera and illumination LEDs
A
Loudspeaker
B
Display
C
Illumination LEDs for keypad
D
Keypad
E
Speech board volume
F
Camera orientation adjustment
G
Connection terminals
H
2 way dip-switch (only switch 1 is used)
I
Balance
L
Loudspeaker volume
M
Microphone volume
N
Serial RS-232 connector (for PC connection)
O
CONTROLS
Speech board volume
Adjust the Speech board volume.
SPB
Rotate clockwise to increase or anti-clockwise to decrease.
Balance
Prevent Larsen effect on bidirectional audio conver-
sation.
Loudspeaker volume
Adjust the loudspeaker volume.
Rotate clockwise to increase or anti-clockwise to decrease.
Microphone volume
Adjust the microphone volume.
Rotate clockwise to increase or anti-clockwise to decrease.
name
- 1 -
F
SPB
H
Switch 1 OFF = Main Camera internal
Switch 1 ON = Main Camera External
