- Page 1 Supplement Fabius GS premium Anesthesia workstation WARNING Software 3.n To properly use this medical device, read and comply with the instructions for use and this supplement.
- Page 2 ® ® Virkon DuPont Buraton ® Mikrozid Schülke & Mayr ® Perform ® Descogen Antiseptica Overview Compact breathing system COSY (top view) The following designation has changed: M Connection for sample gas return line Supplement Fabius GS premium SW 3.n...
- Page 3 Overview The views of the power supply unit for the COSY heater have changed: Power supply unit for COSY heating (front view) A LED indicator for COSY heating B On/Off switch C Fuse Supplement Fabius GS premium SW 3.n...
- Page 4 Overview Power supply unit for COSY heating (rear view) A Power inlet B LED indicator for power supply C Cable clamp Supplement Fabius GS premium SW 3.n...
-
Page 5: Interface Panel
Power inlet with power fuses C Connection for APL hose J Connection for PEEP hose D Socket for O sensor E Socket for airway pressure sensor F Socket for flow sensor G On/Off switch optional Supplement Fabius GS premium SW 3.n... -
Page 6: Product Labels
Transport information, see chapter "Preparing for storage or transport". Trolley version: Observe the weight of the nominal configuration and the total permissible weight, see chapter "Technical data". nom. 134 kg (296 lbs) max. 300 kg (661 lbs) Supplement Fabius GS premium SW 3.n... -
Page 7: Assembly And Preparation
The terminology for the O2 sensor has changed. Inserting a new O sensor capsule WARNING Risk of electric shock If the O sensor capsule is replaced during operation, leakage currents may be transferred. Do not touch the patient. Supplement Fabius GS premium SW 3.n... - Page 8 – Make sure that the O sensor capsule is correctly inserted in the O sensor housing. – Make sure that the O sensor is correctly inserted in the inspiratory valve. Supplement Fabius GS premium SW 3.n...
-
Page 9: Troubleshooting
When the BATTERY LOW !! alarm message (remaining battery charge 10 %) is displayed, the ventilator will continue to operate for only a few minutes more. Restore mains power supply. Afterwards, the automatic ventilation is available again. Supplement Fabius GS premium SW 3.n... - Page 10 Check that the O sensor capsule has been cor- rectly inserted into the O sensor housing. Connect the O sensor correctly and recalibrate. Supplement Fabius GS premium SW 3.n...
-
Page 11: Alarm - Cause - Remedy
SENSOR CAL DUE ! More than 18 hours have Perform the procedure for passed since the last O sen- calibration of the O sensor sor calibration. (see chapter on calibrating the O sensor). Supplement Fabius GS premium SW 3.n... -
Page 12: Cleaning, Disinfection And Sterilization
Before removing the compact breathing system, the following hoses and cables must be removed: – Flow sensor cable – O sensor cable and O sensor – Pressure measurement hose – APL bypass hose – PEEP/PMAX hose Supplement Fabius GS premium SW 3.n... -
Page 13: Reprocessing Methods
Oxycide Ecolab USA Perform Schülke & Mayr Virkon DuPont Quaternary ammonium com- Mikrozid sensitive liquid Schülke & Mayr pounds Mikrozid sensitive wipes Aldehydes Buraton 10 F Schülke & Mayr 1) Virucidal against enveloped viruses Supplement Fabius GS premium SW 3.n... - Page 14 Only disinfect the device surface and cables using the moist scrub-wipe disinfection method and ensure that no fluid enters the device. 2 Perform surface disinfection (scrub-and-wipe disinfection). 3 After the contact time has elapsed, remove disinfectant residues. Supplement Fabius GS premium SW 3.n...
-
Page 15: Reprocessing List
– Flow control valves – APL valve – O sensor housing – Writing tray – Grip bar on trolley – Drawer handles – Standard rails on both sides – Clic adapter, Clic absorber Supplement Fabius GS premium SW 3.n... -
Page 16: Maintenance
– Check the locking device of the anesthetic vaporizer. – Check the function of the power failure alarm and the battery function. – Check the operation of the battery failure alarm. – Check S-ORC functionality. Supplement Fabius GS premium SW 3.n... -
Page 17: Preventive Maintenance
Inspection and service Service personnel Lead-gel battery Every 3 years Replace Experts Cylinder pressure reducer for After 6 years Basic overhauling Experts high-pressure cylinders Pressure reducer for PIN After 6 years Replace Experts index 1) optional Supplement Fabius GS premium SW 3.n... -
Page 18: Technical Data
Vaporizers and anesthetic agents can limit the use of an anesthesia workstation with regard to its temperature range and maximum fresh-gas flow. Therefore when using additional devices, follow the associated instructions for use. Supplement Fabius GS premium SW 3.n... -
Page 19: Device Data
Power supply Inrush current approx. 25 to 50 A peak General safety standards for anesthesia workstations The following sentence has been deleted: The following also apply for devices manufactured from July 2014 on: Supplement Fabius GS premium SW 3.n... - Page 20 ISO 21647 and ISO 80601-2-55 1) Max. ±4 % of the measured value or ±2 cmH O (±2 hPa), depending on which value is higher. Supplement Fabius GS premium SW 3.n...
- Page 21 No demonstrable quantitative effect on the gas measurement due to ambient conditions. Maximum period of use of O >12 months at 25 °C (77 °F), 50 % relative humidity, 50 % O in fresh sensor cell gas (or >5000 hours at 100 Vol% O Supplement Fabius GS premium SW 3.n...
- Page 22 Expose the O sensor to ambient air for 2 minutes. Start the calibration. Insert the O sensor back in the cover of the inspiratory valve. Calibrate the flow sensor. Supplement Fabius GS premium SW 3.n...
- Page 23 This page intentionally left blank. Supplement Fabius GS premium SW 3.n...
- Page 24 Manufacturer Distributed in the USA by Dräger Medical GmbH Draeger Medical Inc. Moislinger Allee 53 – 55 3135 Quarry Road D-23542 Lübeck Telford, PA 18969-1042 Germany U.S.A. +49 451 8 82-0 (215) 721-5400 +49 451 8 82-2080 (800) 4DRAGER http://www.draeger.com (215) 723-5935 http://www.draeger.com As of 2015-08:...
