Chapter 7 Customer Replaceable Units (CRUs)
Rack Mounting the Autoloader
Rack Mounting the Autoloader
86
3 Rotate the magazine blank 180 degrees so that what was the front of
the magazine is now the back.
4 Add the appropriate right or left handle to the front of the rotated
magazine blank.
5 Snap the handle back on the front of the magazine blank.
6 Install the two screws to attach the handle securely to the magazine
blank.
The autoloader can be rack mounted in two ways:
•
Attached directly to the cabinet rails (stationary)
•
Attached to an optional V-Rail kit
Both installations are included in this manual.
SuperLoader 3 Autoloader User's Guide
7
