1.2 Key Features
● Arbitrary format conversion between 12G SDI, HDMI2.0 and fiber signals.
● Multiple embedded test pattern for HDMI, SDI, fiber signal tests.
● LCD touch screen for input signal monitoring and menu operation.
● Two external batteries as main and backup power supplies, allowing automatic
battery switch.
● Built-in audio and 1-CH analog audio input and audio output.
● Network level-up support and constant optimized product performances.
1.3 Panel Introduction
1.3.1 Front Panel Description
No.
Item
LCD Screen
MSP 405
Description
Built-in preview monitor for signal monitoring.
Fiber input/output port icon.
SDI input/output port icon.
User Manual
7
