Curt Manufacturing 18123 Installation Manual

INSTALLATION MANUAL
Level of Difficulty
Easy
Installation difficulty levels are based on time
and effort involved and may vary depending on
the installer level of expertise, condition of the
vehicle and proper tools and equipment.
Weight Carrying Capacity
Roof Rack
Parts List
Item Qty Description
1 1 Front basket
2 1 Rear basket
3 1 Spoiler
4 1 Cargo net
5 2 Water caps
6 2 Straps
7 2 Spacer tubes
8 4 Roof rack clamp assembly
9 8 Bhcs, M6 x 65mm
10 8 Bhcs M6 x 50mm
11 2 Bhcs M6 x 16mm
12 8 Lock washer, M6
13 1 Allen wrench, 5mm
14 1 Allen wrench, 4mm
15 6 Tube clamps
16 6 Bhcs, M6 x 25mm
17 6 Nylock nuts, M6
Tools Required
Allen wrench, 4mm Allen wrench, 5mm
(included) (included)
Torque Specifications
M6 bolt 7 ft-lbs.
Use above torque setting unless otherwise noted
CURTMFG.COM
• PRODUCT SUPPORT: 877.287.8634
WARNING
Never exceed the factory weight rating of the OEM
roof rack, including the weight of the cargo carrier.
Product Photo
150 lbs.
NOTICE
Visit www.curtmfg.com for a full-color copy of this
instruction manual, as well as helpful videos, guides and much more!
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Periodic inspection of your product should be performed
to ensure all hardware and / or components remain secure.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.
Cargo roof rack rating: 150 lbs. limited to your vehicles factory roof rack weight limit.
Product Registration and Warranty
CURT stands behind our products with industry-leading warranties. To get copies of the product
warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys
• 18123-INS-RA • 01/23/2024 • ECN11481 • PAGE 1
18123
