GROSS LOAD CAPACITY WHEN USED AS A WEIGHT CARRYING HITCH:
GROSS LOAD CAPACITY WHEN USED AS A WEIGHT DISTRIBUTION HITCH:
***DO NOT EXCEED VEHICLE MANUFACTURER'S RECOMMENDED TOWING CAPACITY.***
HAVING INSTALLATION QUESTIONS? CALL TECHNICAL SUPPORT AT
NOTE: REUSE FACTORY MOUNTING HARDWARE AND
MOVE CLIP NUTS TO SPARE TIRE SUPPORT BRACKET
SUPPORT BRACKET
SPARE TIRE
DRIVER SIDE
FRAME RAIL
REUSE FACTORY
MOUNTING HARDWARE
4 PLACES EACH SIDE
FACTORY CROSSMEMBER OR HITCH
REMOVE AND RETURN TO OWNER
HITCH WEIGHT:
38
LBS.
INSTALL TIME
30
PROFESSIONAL:
MINUTES
NOVICE (DIY):
60
MINUTES
INSTALL NOTES:
-LOWER SPARE TIRE
-REMOVE FACTORY COMPONENTS
-WELDNUT CLEANING
-NO DRILLING REQUIRED
PERIODICALLY CHECK THIS RECEIVER HITCH TO ENSURE THAT ALL FASTENERS
CURT Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser.
Scan
If the product is found to be defective, CURT Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid,
for more
with proof of purchase. Alteration to, misuse of, or improper installation of this product voids the warranty. CURT Manufacturing LLC.'s liability is limited to
information
repair or replacement of products found to be defective, and specifically excludes liability for incidental or consequential loss or damage.
CHEVROLET COLORADO & GMC CANYON
SPARE TIRE
ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND.
6,000
LBS. TRAILER WEIGHT &
8,000
LBS. TRAILER WEIGHT &
1-877-287-8634
PASSENGER SIDE FRAME RAIL
EXISTING WELDNUTS
IN VEHICLE FRAME
4 PLACES EACH SIDE
PAGE 1 of 2
900
LBS. TONGUE WEIGHT.
900
LBS. TONGUE WEIGHT
VEHICLE BUMPER
TOOLS REQUIRED
RATCHET
13mm SOCKET
21mm SOCKET
9" EXTENSION
JACK STANDS
SPRAY LUBRICANT
WIRE PIPE BRUSH
TORQUE WRENCH
