Ethnicraft TORSION 50012 Assembly Instructions

Oak dining table 90/127

Download this manual

ASSEMBLY INSTRUCTIONS FOR TABLE INSTALLATION

OAK TORSION DINING TABLE Ø90 / Ø127

CODE

DESCRIPTION

50012

OAK TORSION DINING TABLE - BLACK 127/127/76

50013

OAK TORSION DINING TABLE - BLACK 90/90/76

OAK TORSION DINING TABLE 90/90/76

50018

50019

OAK TORSION DINING TABLE 127/127/76

1/5

Need help?

Do you have a question about the TORSION 50012 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS FOR TABLE INSTALLATION OAK TORSION DINING TABLE Ø90 / Ø127 CODE DESCRIPTION 50012 OAK TORSION DINING TABLE - BLACK 127/127/76 50013 OAK TORSION DINING TABLE - BLACK 90/90/76 OAK TORSION DINING TABLE 90/90/76 50018 50019 OAK TORSION DINING TABLE 127/127/76...
Page 2 CHECK PACKAGE CONTENTS TO ASSURE ALL THE NECESSARY HARDWARE AND PARTS ARE RECEIVED UNDAMAGED. DO NOT USE DAMAGE OR DEFECTIVE PARTS/HARDWARE. CONTACT ETHNICRAFT FOR ANY MISSING PART AND /OR HARDWARE. READ THE ASSEMBLY INSTRUCTION BEFORE INSTALLATION AND CAREFULLY FOLLOW THE INSTRUCTION GIVEN.
Page 3 OAK TORSION DINING TABLE Ø90 / Ø127 ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION DISMANTLING METAL PLATE & SCREWS FROM LEG BASE H0841 H0841 H0840 H0840 H0839 H0839 DO NOT THROW AWAY THE SCREWS, THEY WILL BE USED FOR REASSEMBLY INSTALLING METAL PLATE (LARGE) TO THE CENTER LEG H0839 H0839 H0839...
Page 4 OAK TORSION DINING TABLE Ø90 / Ø127 ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION INSTALLING CENTER LEG TO TABLE TOP - ALWAYS REFER TO STICKER - USE SCREW M8x16 - TIGHTEN FULLY INSTALLING LEG BASE Make sure the holes of leg base and center leg are inline H0840 H0840...
Page 5 OAK TORSION DINING TABLE Ø90 / Ø127 ASSEMBLY INSTRUCTIONS FOR DINING TABLE INSTALLATION ADJUSTING RUBBER PAD LEVELER / RUBBER PADS POSITION STABLE UNSTABLE NOTE : THIS IS A COMPULSORY ACTION TO MAKE SURE ALL OF THE RUBBER PADS TOUCH THE GROUND!
