ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION
SPINDLE BED - QUEEN SIZE
CODE
51247
OAK SPINDLE BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97
WALNUT SPINDLE BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97
45187
OAK SPINDLE BLACK BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97
51237
DESCRIPTION
1/7
Advertisement
Related Manuals for Ethnicraft 51247
Summary of Contents for Ethnicraft 51247
- Page 1 ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION SPINDLE BED - QUEEN SIZE CODE DESCRIPTION 51247 OAK SPINDLE BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97 WALNUT SPINDLE BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97 45187 OAK SPINDLE BLACK BED - EU QUEEN SIZE – WITHOUT SLATS 160/200/97...
- Page 2 DAMAGE. CHECK PACKAGE CONTENTS TO ASSURE ALL THE NECESSARY HARDWARE AND PARTS ARE RECEIVED UNDAMAGE. DO NOT USE DAMAGED OR DEFECTIVE PARTS/ HARDWARE. CONTACT ETHNICRAFT FOR ANY MISSING PART AND OR HARDWARE. READ THE ASSEMBLY INSTRUCTION BEFORE HEADBOARD 1piece INSTALLATION AND CAREFULLY FOLLOW THE...
- Page 3 SPINDLE BED - QUEEN SIZE ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION HARDWARE ENCLOSED H0667 H0666 H0308 H0742 H0228 HALFMOON WASHER HALFMOON BOLT DOWEL JCBC SCREW LONG NUT M8x100 Ø12x50 mm M6x70 (4pcs) (4pcs) (8pcs) (3pcs) (2pcs) H0951 H0949 H0757 H0746 L BRACKET JCBC SCREW JF SCREW M6x6...
- Page 4 SPINDLE BED - QUEEN SIZE ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION CONNECTING SIDERAIL AND HEAD / FOOTBOARD ATTACH SIDERAIL WITH DRILL HOLE TO HEADBOARD D (L) - USE DOWEL Ø12x50 (8X) - USE HALFMOON BOLT M8x100 (4X) - USE HALFMOON WASHER (4X) - TIGHTEN FULLY CONNECTING CENTER LEG TO CENTER SUPPORT - USE JF SCREW M6x50 (1X)
-
Page 5: Installing L Bracket
SPINDLE BED - QUEEN SIZE ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION INSTALLING CENTER SUPPORT TO ADJUST HEIGHT - USE L BRACKET (2X) - USE JCBC SCREW M6x6 (2X) - USE JF SCREW M6x50 (4X) - USE WASHER M6 (4X) - USE NUT M6 (4X) - TIGHTEN FULLY ALL SCREWS INSTALLING L BRACKET - USE L BRACKET (6X) - Page 6 SPINDLE BED - QUEEN SIZE ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION INSTALLING BED HEAD INSTALL SCREW ON THE MIDDLE SIDE FIRST - USE JCBC SCREW M6x70 (1X) - DO NOT FULLY TIGHTEN THEN INSTALL SCREW ON THE OTHER SIDE - USE JCBC SCREW M6x70 (2X) - USE WASHER M6x18 (2X) - USE SPRING WASHER M6 (2X) - USE LONG NUT M6 (2X)
- Page 7 SPINDLE BED - QUEEN SIZE ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION RE-TIGHTEN THE SCREWS TIGHTEN FULLY ALL SCREWS FINISH...
