- Page 1 ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION OAK AIR BED - WITH SLATS 51213 OAK AIR BED - US KING SIZE - WITH SLATS 193/203/96 51214 OAK AIR BED - US QUEEN SIZE - WITH SLATS 153/203/96...
- Page 2 OAK AIR BED - WITH SLATS ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION HARDWARE ENCLOSED TOOLS JCBC Screw L Bracket M6x6 Screw Connector (4pcs) (4pcs) (8pcs) (8pcs) Countersunk Screw JCBC Screw JF Screw Washer M6x50 M6x20 M5x40 L KEY WRENCH (1pc) (4pcs) (20pcs) (12pcs) (12pcs)
- Page 3 OAK AIR BED - WITH SLATS ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION A. INSTALLING SIDERAIL + FOOTBOARD + HEADBOARD RAIL...
- Page 4 OAK AIR BED - WITH SLATS ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION B. INSTALLING HEADBOARD DO NOT FULLY TIGHTEN Note: Before placing the headboard turn the barrel (from the leg) with a screwdriver so the bolt-connectors (from the headboard) fit into the barrels. - USE DOWEL (4X) - USE BOLT CONNECTOR (4X) - USE...
- Page 5 OAK AIR BED - WITH SLATS ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION C. INSTALLING MIDDLE SUPPORT & CENTER LEG - USE JCBC SCREW M6x6mm (2X) - USE COUNTERSUNK SCREW M6x50mm (1X) - USE JCBC SCREW M6x20mm (4X) - TIGHTEN FULLY ALL SCREWS TO ADJUST HEIGHT D.
- Page 6 OAK AIR BED - WITH SLATS ASSEMBLY INSTRUCTIONS FOR BED INSTALLATION E. INSTALLING SLATS USE JF SCREW M5x40mm (8X) SLATS TO BE ASSEMBLED ARE NUMBER 1, 6, 8 AND 13 F. FINISH...
