Installation
7. Connect the network cable.
8. Replace the ceiling tiles.
Install the Access Point to a T-bar with a ACC-BKT-AX-TBW
Before You Begin
The following hardware is required for installing the ACC-BKT-AX-TBW accessory on a
T-bar:
•
An indoor access point
•
One ACC-BKT-AX-TBW Accessory
•
Two M3.5 screws (included in the -TBW accessory)
Note
The screws come with the accessory and are partially attached in place.
About This Task
You can use the ACC-BKT-AX-TBW accessory for T-bar installation. The -TBW bracket is
used for 1.5 inch wide T-bars with varying thickness from 3.175 mm to 6.350 mm, with
flush ceiling tiles.
The following ceiling tile protrusions are accommodated by the -TBW mounting
bracket:
•
If the T-bar is 0.25 inches thick, the -TBW bracket will only accommodate flush
ceiling tiles
•
If the T-bar is 0.1875 inches thick, the -TBW bracket will accommodate flush ceiling
tiles as well as ceiling tiles with 0.062 inches protrusion
•
If the T-bar is 0.125 inches thick, the -TBW bracket will accommodate flush ceiling
tiles as well as ceiling tiles up to 0.125 inches protrusion
