Antenna Specifications
Antenna Specifications
The AP4020 has the following internal antennas:
•
Two (2) dual band 2.4 GHz and 5 GHz
•
Two (2) single band 5 GHz
•
Two (2) single band 6 GHz
•
One (1) 2 GHz/5 GHz/6 GHz sensor
•
Three (3) IoT sensors
Note
The 2 GHz/5 GHz/6 GHz sensor is available in a future software release.
Antenna Specifications
The following list shows the Gain and Beam for the AP4020 internal antenna. Use this
information when you plan your installation.
•
Omni: 4dBi on 2.4GHz; 4dBi on 5GHz and 6GHz.
•
Coverage: Symmetrical coverage
Radiation Patterns
Antenna radiation patterns are an important tool when you install your access point.
Use this information to optimize your coverage, to reduce interference from other
devices, and to ensure you comply with government regulations.
2.4 GHz Radiation Patterns
The following diagrams illustrate the radiation patterns for the AP4020 2GHz internal
antenna.
