Assa Abloy Norton Rixson 27QT Installation Instructions

27QT Removable Floor Closer
with Threshold
3/4" Offset Pivoted - Handed
Installation Instructions
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65warnings.ca.gov.
13/16
3/4
3/16 R.
Bevel Edge
of Door
1/8" in 2"
Jamb
2-1/16 R.
2-1/16
1-5/16
3/4
2-1/4
3/4
1-1/4
Right Hand Shown
Conversion from inches to metric: inch x 25.4
Use only with 1-3/4" doors.
Where vertical adjustment is necessary,
two (2) 1/16" thick shims are provided to be
placed between arm and torque washer.
Copyright © 2002, 2009, 2022, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
2700QT Rev 3 01/22
1/8 Min. Clearance Required
Between Door and Stop
Arm
3/4
Floor Plate
9-13/16 Cement Case
10-13/16 Styrofoam
Drill (3) 3/8" Dia. Clearance Holes
in Door for Arm Mounting Screws.
12-1/8
4" 1"
2-3/8
3 Holes for
1/4"-20 x 2-1/8" Long
Truss Head Machine Screw
3/8
1-35/64
25/64
Jamb
Bevel Edge
of Door
1/8 in 2
5-7/8
5/8
Cement
7/16
Case
3/4
6-1/16
3/4
Styro-
foam
1/16
3/4
1-1/8
3/4
4-7/8
Set Cement Case 3/4" Below Surface of Finished Floor
1-7/16
1-15/16
3-9/16
4-5/8
5"
5/16
13/16
4-1/4
3-55/64
2-45/64
1/8 R.
Holes for
13/16
1/4-20x5/8" FHMS or
#14x1-1/2" FHWS
C L
1/4
3/4
3/16
Threshold
WITH THRESHOLD
Bevel Heel Edge of Door 1/8 in 2
13/16
3/4
1/4
3/4
Door Leaf Jamb Leaf
3/8 7/16
2-1/2
1-1/8
4-1/4
NORTON
RIXSON
180 Top Pivot
23/64
45/64
1-1/16
2
3/4
1/4
Door Mortised "A"
Deep for Arm
"A" "B"
1/4 Threshold 9/16 15/16
1/2 Threshold 5/16 11/16
B
5/16
5/16
3/16 R.
1/8 Min.
Clearance
1-1/8
1-17/32
2-1/2
3-15/32
4-9/16
5"
5/16
13/16
1-1/8
