User Manual
Charger for
LiFePO
Batteries
4
EN User Manual
Updates and language specific user manuals are available on
www.mascot.no/downloads/usermanuals
P.O.Box 177, N-1601 Fredrikstad, NORWAY
Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01
E-mail: sales@mascot.no • Web: www.mascot.no
Doc.no. 5250F - Part No. 205250 - 11.02.2025
Bruksanvisning
Käyttöohjeet
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
MASCOT ELECTRONICS AS
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MASCOT 2240
Summary of Contents for MASCOT 2240
- Page 1 Manual de instrucciones Istruzioni per l’uso MASCOT ELECTRONICS AS P.O.Box 177, N-1601 Fredrikstad, NORWAY Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01 E-mail: sales@mascot.no • Web: www.mascot.no Doc.no. 5250F - Part No. 205250 - 11.02.2025...
-
Page 2: Important Safety Instructions
Technical specifications for your product: see A version of this product, marked with a sym- tables, the marking on the product or bol with two drops of water and/or ”IP67”, may www.mascot.no be available. This version is filled with a potting... - Page 3 Cautions to observe prior to use • The intended use for this product is to charge be easily accessible to facilitate immediate a battery or a battery powered electrical removal of the products mains supply should accessory (NiCd/NiMH, Lead-Acid, Lithium-Ion an operational error occur during use.
- Page 4 • Even though this product complies with relevant same type and rating must be used. safety standards it should not be in contact with human skin for long periods as some people • If the product is specified to comply with the may get allergies or injuries from long-term standard for Medical Electrical Equipment contact with moderate temperatures and/or...
- Page 5 However; the guarantee times indicated in document ”TERMS OF SALES AND DELIVERY • For products having a plastic casing, please FOR MASCOT AS” apply (available at www. avoid any contact with lotions, oils, grease mascot.com). and solvents as most types of plastic may be degraded by such chemicals.
- Page 6 Cautions to observe prior to charging LiFePO -batteries • LiFePO chargers are designed for charging • Please ensure correct polarity when connecting Li-FePO (LFP) batteries only. Make sure you to the battery terminals. Reverse polarity conne- have the correct battery charger for the che- ction may, in some chargers (see the chargers mistry and number of cells in series.
- Page 7 Explanation of LiFePO battery charge cycle (See tables for methods for each charger model) Charging method A STEP 1 – BOOST CHARGE To start a charge cycle, connect the charger to the mains. The charger is in constant current mode, charging with the maximum current indicated on Orange the charger, the LED-indication on the charger is ORANGE.
- Page 8 Charging method B Diagram: A STEP 1 – BOOST CHARGE Orange To start a charge cycle, connect the charger to the mains. INDICATOR: ORANGE INDICATOR: GREEN Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE.
- Page 9 Charging method C Orange STEP 1 – BOOST CHARGE To start a charge cycle, connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated Orange on the charger, the LED-indication on the charger is ORANGE (or RED 9640). This step allows rapid charging of your battery until the battery reaches typically 80 - 95% of its capacity.
- Page 10 Charging method D STEP 1 - BOOST CHARGE Yellow LED-indicator: YELLOW The charger is in constant current mode (CC), charging with the maximum current until battery voltage reach Top-Up level. STEP 2 – TOP-UP CHARGE The charger is in constant voltage mode. The LED-indication will be FLASHING YELLOW Yellow during Top-up charge.
- Page 11 Diagram: D INDICATOR: INDICATOR: YELLOW INDICATOR: GREEN FLASHING YELLOW Charge Voltage Charge Voltage Battery Voltage Charge Current Cut-Off Current Start Current Current Start-Up at Vbatt <2.6V/cell Error Mode if <2.6V/cell after 10 minutes Step 0 Step 1 Step 2 Step 3 Start Timer Boost Charge Float Charge...
- Page 12 Mains Cord Set is available on request if you wish your product to be ”DeskTop” Mounting and use for bracket Mascot, part no. 205800 Wall mount: Fix the bracket to the wall using screws suitable for the wall material and: head diameter: 8 - 9.5 mm, head height: max.
-
Page 13: Electromagnetic Compatibility
Medical devices manufactured by Mascot have been tested and conform with the requirements of IEC/EN 60601-1-2, 3rd & 4th edition, nevertheless, special precautions may... - Page 14 If the measured field strength in the location exceeds the applicable RF compliance level above, the Mascot product should be observed to verify normal operation. If abnormal per- formance is observed, additional measures may be necessary, such as re-orienting or relocating...
- Page 15 Orange CC ch.: 1.3A < 3.65V 1.3A < 7.3V 1.3A < 10.95V 0.9A < 14.6V 0.88A < 18.25V 100-240Vac 2240(P) Orange CV ch.: 3.65V > 100mA 7.3V > 100mA 10.95V > 100mA 14.6V > 100mA 18.25V > 100mA 50-60Hz 2241(P) Green ch.
- Page 16 Charge diagram/ Ladediagramm/ Schéma de charge B Charge diagram B Charge LED Input voltage 1-cell (3.2V) 2-cell (6.4V) 3-cell (9.6V) 4-cell (12.8V) 5-cell (16V) indicator Orange CC ch.: 4.5A < 3.65V 4.5A < 7.3V 4.5A < 11.0V 4A < 14.6V 3.9A <...
- Page 17 Charge diagram B Charge diagram/ Ladediagramm/ Schéma de charge B Charge LED Input voltage 6-cell (19.2V) 7-cell (22.4V) 8-cell (25.6V) 9-cell (28.8V) 10-cell (32V) indicator Orange CC ch.: 3.3A < 21.9V 2.8A < 25.55V 2.5A < 29.2V 2.2A < 32.85V 1.95A <...
- Page 18 Charge diagram B Charge diagram/ Ladediagramm/ Schéma de charge B Input Charge LED 11-cell (35.2V) 12-cell (38.4V) 13-cell (41.6V) 14-cell (44.8V) 15-cell (48V) 16-cell (51.2V) voltage indicator Orange CC ch.: 1.8A < 40.15V 1.65A < 43.8V 1.5A < 47.45V 1.4A < 51.1V 1.3A <...
- Page 19 Charge diagram C Charge diagram/ Ladediagramm/ Schéma de charge C Charge LED Input voltage 1-cell (3.2V) 2-cell (6.4V) 3-cell (9.6V) 4-cell (12.8V) 5-cell (16V) indicator 2040(P) Orange CC ch.: 4A < 11V 3.5A < 14.6V 2A < 18.3V 2041(P) 100-240Vac Orange CV ch.: 11V <...
- Page 20 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Input voltage Charge LED indicator 1-cell 2-cell 3-cell 4-cell 5-cell 6-cell Yellow CC ch.: 20A < 3.65V 20A < 7.3V 20A < 10.95V 20A < 14.6V 16A < 18.25V 13.4A < 21.9V 220-240Vac Yellow CV ch.: 3.65V >...
- Page 21 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Input voltage Charge LED indicator 7-cell 8-cell 9-cell 10-cell 11-cell 12-cell Yellow CC ch.: 10A < 25.55V 10A < 29.2V 9.0A < 32.85V 8.0A < 36.50V 7.3A < 40.15V 6.7A < 43.8V 220-240Vac Yellow CV ch.: 25.55V >...
- Page 22 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Input voltage Charge LED indicator 13-cell 14-cell 15-cell 16-cell Yellow CC ch.: 6.1A < 47.45V 5.5A < 51.1V 5.2A < 54.75V 5.0A < 58.4V 220-240Vac Yellow CV ch.: 47.45V > 5.0A 51.1V >...
