MASCOT 2240 (P) User Manual

Charger for li-ion batteries
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
Charger for
Li-Ion Batteries
EN
User Manual
Updates and language specific user manuals are available on
www.mascot.no/downloads/usermanuals
Bruksanvisning
Käyttöohjeet
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
P.O.Box 177, N-1601 Fredrikstad, NORWAY
Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01
E-mail: sales@mascot.no • Web: www.mascot.no
Doc.no. 5170E - Part No. 205170 - 11.01.2018
MASCOT ELECTRONICS AS
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2240 (P) and is the answer not in the manual?

Questions and answers

Related Manuals for MASCOT 2240 (P)

Summary of Contents for MASCOT 2240 (P)

  • Page 1 Manual de instrucciones Istruzioni per l’uso MASCOT ELECTRONICS AS P.O.Box 177, N-1601 Fredrikstad, NORWAY Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01 E-mail: sales@mascot.no • Web: www.mascot.no Doc.no. 5170E - Part No. 205170 - 11.01.2018...

  • Page 2: Important Safety Instructions

    A version of this product, marked with a symbol Technical specifi cations for your product: with two drops of water and/or ”IP67”, may be See tables, the marking on the product available. This version is fi lled with a potting or www.mascot.no...
  • Page 3 Cautions to observe prior to use • The intended use for this product is to charge a plug into the mains socket and “switched off” battery or a battery powered electrical accessory by disconnecting the mains plug from the mains (NiCd/NiMH, Lead-Acid, Lithium-Ion or LiFePO socket.
  • Page 4 ”TERMS electrical equipment and may be used in medical OF SALES AND DELIVERY FOR MASCOT AS” applications and hospital environments. apply (available at www.mascot.com). • The product must not be used in the vicinity •...
  • Page 5 • This product complies with the requirements to as most types of plastic may be degraded by such electromagnetic compatibility for medical electric chemicals. Also make sure to position, operate and equipment and for use in residential, offi ce or light store such products away from UV-light and direct industrial environment but all electric products sunlight.
  • Page 6 typical 1C as a maximum current for Li-Ion cells. this termination method. For a 1A charger with 1C means that charge current for a 1Ah battery 0.1A current detection level the max capacity should be max 1A. Thus the typical minimum recommended will be 100 x 0.1A = 10Ah.

  • Page 7: Step 3 -Charge Complete

    Explanation of Li-Ion battery charge cycle (See tables for methods for each charger model.) Charging method A STEP 1 – CONSTANT CURRENT CHARGE To start a charge cycle; connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE.
  • Page 8 Charging method B STEP 1 - CONSTANT CURRENT CHARGE To start a charge cycle; connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE. This step allows rapid charging of your battery until the battery voltage has increased to a certain set level STEP 2 - CONSTANT VOLTAGE CHARGE When the battery voltage has increased to a certain set level the charger enters constant...
  • Page 9 Charging method C STEP 1 – CONSTANT CURRENT CHARGE To start a charge cycle; connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE (or RED 9640). This step allows rapid charging of your battery until the battery reaches typically 80 - 95% of its capacity.

  • Page 10: Error Indications

    Charging method D STEP 1 - CONSTANT CURRENT CHARGE Charge cycle starts automatically when input is connected to mains and battery is connected to the output.The charger is in constant current mode (CC), charging with the maximum current indicated on the charger. The LED-indication on the charger is YELLOW. This step allows rapid charging of your battery until the battery reaches typically 80-95% of its capacity.
  • Page 11 Diagram: D INDICATOR: INDICATOR: YELLOW INDICATOR: GREEN FLASHING YELLOW Charge Voltage Battery Voltage No voltage, Battery Voltage no current from charger! Charge Current Cut-Off Current No current (0A) Start Current Current Start-Up at Vbatt <3V/cell Error Mode if <3V/cell after 10 minutes Step 0 Step 1 Step 3...

This manual is also suitable for:

27402241(p)25442542(p)2541(p)2641 ... Show all
