MASCOT 2240 User Manual

Charger for li-ion batteries
Hide thumbs Also See for 2240:

Advertisement

Quick Links

Download this manual
User Manual
Charger for
Li-Ion Batteries
EN
User Manual
Updates and language specific user manuals are available on
www.mascot.no/downloads/usermanuals
Bruksanvisning
Käyttöohjeet
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
P.O.Box 177, N-1601 Fredrikstad, NORWAY
Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01
E-mail: sales@mascot.no • Web: www.mascot.no
Doc.no. 5180J - Part No. 205180 - 11.02.2025
MASCOT ELECTRONICS AS
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2240 and is the answer not in the manual?

Questions and answers

Related Manuals for MASCOT 2240

Summary of Contents for MASCOT 2240

  • Page 1 Manual de instrucciones Istruzioni per l’uso MASCOT ELECTRONICS AS P.O.Box 177, N-1601 Fredrikstad, NORWAY Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01 E-mail: sales@mascot.no • Web: www.mascot.no Doc.no. 5180J - Part No. 205180 - 11.02.2025...

  • Page 2: Important Safety Instructions

    Technical specifications for your product: see A version of this product, marked with a sym- tables, the marking on the product or bol with two drops of water and/or ”IP67”, may www.mascot.no be available. This version is filled with a potting...
  • Page 3 Cautions to observe prior to use • The intended use for this product is to charge be easily accessible to facilitate immediate a battery or a battery powered electrical removal of the products mains supply should accessory (NiCd/NiMH, Lead-Acid, Lithium- an operational error occur during use.
  • Page 4 • Even though this product complies with relevant • If the product is specified to comply with the safety standards it should not be in contact with standard for Medical Electrical Equipment human skin for long periods as some people (standards based on IEC60601-1) it complies may get allergies or injuries from long-term with some of the requirements for medical...
  • Page 5 ”TERMS OF SALES AND DELIVERY FOR MAS- • For products having a plastic casing, please COT AS” apply (available at www.mascot.com). avoid any contact with lotions, oils, grease and solvents as most types of plastic may be de- •...
  • Page 6 Cautions to observe prior to charging Li-Ion-batteries • Li-Ion chargers are designed for charging Li- • Please ensure correct polarity when connecting Ion (LI) batteries only. Make sure you have the to the battery terminals. Reverse polarity conne- correct battery charger for the chemistry and ction may, in some chargers (see the chargers number of cells in series.
  • Page 7 Mains Cord Set is available on request if you wish your product to be ”DeskTop” Mounting and use for bracket Mascot, part no. 205800 Wall mount: Fix the bracket to the wall using screws suitable for the wall material and: head diameter: 8 - 9.5 mm, head height: max.
  • Page 8 Explanation of Li-Ion battery charge cycle (See tables for methods for each charger model) Charging method A STEP 1 – CONSTANT CURRENT CHARGE To start a charge cycle, connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE.
  • Page 9 Charging method B Diagram: A STEP 1 - CONSTANT CURRENT CHARGE To start a charge cycle, connect the charger to the mains. INDICATOR: ORANGE INDICATOR: GREEN Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE.
  • Page 10 Charging method C STEP 1 – CONSTANT CURRENT CHARGE To start a charge cycle, connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE (or RED 9640). This step allows rapid charging of your battery until the battery reaches typically 80 - 95% of its capacity.
  • Page 11 Charging method D STEP 1 - CONSTANT CURRENT CHARGE Charge cycle starts automatically when input is connected to mains and battery is Yellow connected to the output. The charger is in constant current mode (CC), charging with the maximum current indicated on the charger. The LED-indication on the charger is YELLOW.
  • Page 12 Diagram: D INDICATOR: INDICATOR: YELLOW INDICATOR: GREEN FLASHING YELLOW Charge Voltage Battery Voltage No voltage, Battery Voltage no current from charger! Charge Current Cut-Off Current No current (0A) Start Current Current Start-Up at Vbatt <3V/cell Error Mode if <3V/cell after 10 minutes Step 0 Step 1 Step 2...

  • Page 13: Electromagnetic Compatibility

    Medical devices manufactured by Mascot have been tested and conform with the requirements of IEC/EN 60601-1-2, 3rd & 4th edition, nevertheless, special precautions may...
  • Page 14 If the measured field strength in the location exceeds the applicable RF compliance level above, the Mascot product should be observed to verify normal operation. If abnormal per- formance is observed, additional measures may be necessary, such as re-orienting or relocating...
  • Page 15 Input voltage Charge LED indicator Orange CC ch.: 1.3A < 4.2V 1.3A < 8.4V 1.2A < 12.6V 0.9A <16.8V 0.7A < 21V 100-240Vac 2240(P) Orange CV ch.: 4.2V > 100mA 8.4V >100mA 12.6V >100mA 16.8V >100mA 21V >100mA 50-60Hz 2241(P) Green ch.
  • Page 16 Charge diagram/ Ladediagramm/ Schéma de charge B Charge diagram B 1-cell (3.6V) 2-cell (7.2V) 3-cell (10.8V) 4-cell (14.4V) 5-cell (18V) Input voltage Charge LED indicator Orange CC ch.: 4.5A < 4.2V 4.5A < 8.4V 4.5A < 12.6V 3.5A < 16.8V 3.3A <...
  • Page 17 Charge diagram B Charge diagram/ Ladediagramm/ Schéma de charge B Input voltage Charge LED indicator 6 -cell (21.6V) 7-cell (25.2V) 8-cell (28.8V) 9-cell (32.4V) 10-cell (36V) Orange CC ch.: 2.8A <25.2V 2.5A <29.4V 2.1A <33.6V 1.9A <37.8V 1.8A <42V 100-240Vac Orange CV ch.: 25.2V >1.6A 29.4V >0.8A...
  • Page 18 Charge diagram B Charge diagram/ Ladediagramm/ Schéma de charge B Input voltage Charge LED indicator 11-cell (39.6V) 12-cell (43.2V) 13-cell (46.8V) 14-cell (50.4V) 15-cell (54V ) 16-cell (57.6V) Orange CC ch.: 1.6A < 46.2V 1.45A < 50.4V 1.35A < 54.6V 1.3A <...
  • Page 19 Charge diagram C Charge diagram/ Ladediagramm/ Schéma de charge C 1-cell (3.6V) 2-cell (7.2V) 3-cell (10.8V) 4-cell (14.4V) 5-cell (18V) Input voltage Charge LED indicator Orange CC ch.: 4A < 12.6V 3.5A < 16.8V 2A < 21V 2040(P) 100-240Vac Yellow Timer CV ch.: 12.6V <...
  • Page 20 Charge diagram/ Ladediagramm/ Schéma de charge C Charge diagram C Input voltage Charge LED indicator 11-cell (39.6V) 12-cell (43.2V) 13-cell (46.8V) 14-cell (50.4V) 16-cell (57.6V) Orange CC ch.: 1.3A < 46.2V 1.2A < 50.4V 1.1A < 54.6V 1A < 58.8V 2040(P) 100-240Vac Yellow Timer CV ch.:...
  • Page 21 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Charge LED Input voltage 1-cell 2-cell 3-cell 4-cell 5-cell 6-cell 7-cell indicator Yellow CC ch.: 20A < 4.2V 20A < 8.4V 20A <12.6V 17.5A <16.8V 14A < 21V 10A < 25.2V 10A <...
  • Page 22 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Charge LED Input voltage 8-cell 9-cell 10-cell 11-cell 12-cell 13-cell 14-cell indicator Yellow CC ch.: 8.7A < 33.6V 7.7A < 37.8V 7.0A < 42.0V 6.3A < 46.2V 5.8A < 50.4V 5.2A <...
  • Page 23 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D 1-cell Input voltage Charge LED indicator EasyPack S EasyPack L EasyPack XL EasyPack PLUS Yellow CC ch.: 0.45A < 4.2V 0.85A < 4.2V 1.5A < 4.2V 1.5A < 4.2V 100-240Vac 3745(P) Yellow CV ch.: 4.2V >...
