MASCOT 2240 User Manual

Charger for lead acid batteries
Hide thumbs Also See for 2240:

Advertisement

Quick Links

User Manual
Charger for
Lead Acid Batteries
EN
User Manual
Updates and language specific user manuals are available on
www.mascot.no/downloads/usermanuals
Bruksanvisning
Käyttöohjeet
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
P.O.Box 177, N-1601 Fredrikstad, NORWAY
Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01
E-mail: sales@mascot.no • Web: www.mascot.no
Doc.no. 5150G - Part No. 205150 - 11.02.2025
MASCOT ELECTRONICS AS
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2240 and is the answer not in the manual?

Questions and answers

Summary of Contents for MASCOT 2240

  • Page 1 Manual de instrucciones Istruzioni per l’uso MASCOT ELECTRONICS AS P.O.Box 177, N-1601 Fredrikstad, NORWAY Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01 E-mail: sales@mascot.no • Web: www.mascot.no Doc.no. 5150G - Part No. 205150 - 11.02.2025...
  • Page 2: Important Safety Instructions

    Technical specifications for your product: see A version of this product, marked with a sym- tables, the marking on the product or bol with two drops of water and/or ”IP67”, may www.mascot.no be available. This version is filled with a potting...
  • Page 3 Cautions to observe prior to use • The intended use for this product is to charge a easily accessible to facilitate immediate remov- battery or a battery powered electrical accesso- al of the products mains supply should an oper- ry (NiCd/NiMH, Lead-Acid, Lithium-Ion or LiFe- ational error occur during use.
  • Page 4 • Even though this product complies with relevant • If the product is specified to comply with the safety standards it should not be in contact with standard for Medical Electrical Equipment human skin for long periods as some people (standards based on IEC60601-1) it complies may get allergies or injuries from long-term with some of the requirements for medical elec-...
  • Page 5 ”TERMS OF SALES AND DELIVERY FOR MAS- COT AS” apply (available at www.mascot.com). • For products having a plastic casing, please avoid any contact with lotions, oils, grease and •...
  • Page 6 battery allows for the environmental conditions • To charge batteries in vehicles, first connect the present during charging. positive clip (RED) to the positive battery pole (the one not connected to the vehicles chassis), • If in doubt, contact the battery manufacturer for then connect the other clip (BLACK) to the vehi- the specific battery.
  • Page 7 Mains Cord Set is available on request if you wish your product to be ”DeskTop” Mounting and use for bracket Mascot, part no. 205800 Wall mount: Fix the bracket to the wall using screws suitable for the wall material and: head diameter: 8 - 9.5 mm, head height: max.
  • Page 8 Explanation of Lead-Acid charge cycle (See tables for methods for each charger model) Charging method A STEP 1 - BOOST CHARGE To start a charge cycle, connect the charger to the mains. The charger is in constant current mode, charging with the maximum current indicated on Orange the charger, the LED-indication on the charger is ORANGE.
  • Page 9 Charging method B Diagram: A STEP 1 - BOOST CHARGE To start a charge cycle, connect the charger to the mains. INDICATOR: ORANGE INDICATOR: GREEN Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE.
  • Page 10 Diagram: D/ E INDICATOR: INDICATOR: YELLOW INDICATOR: GREEN FLASHING YELLOW Charging method C Charge Voltage STEP 1 - BOOST CHARGE Charge Voltage To start a charge cycle, connect the charger to the mains. Orange The charger is in constant current mode, charging with the maximum current indicated on the charger, the LED-indication on the charger is ORANGE (or RED 9640).
  • Page 11 Charging method D STEP 1 - BOOST CHARGE LED-indicator: YELLOW The charger is in constant current mode (CC), charging with the maximum current until Yellow battery voltage reach Top-Up level. STEP 2 – TOP-UP CHARGE The charger is in constant voltage mode. The LED-indication will be FLASHING YELLOW during Top-up charge.
  • Page 12 Charging method E STEP 1 - BOOST CHARGE LED-indicator: YELLOW Yellow The charger is in constant current mode (CC), charging with the maximum current until battery voltage reach Top-Up level. STEP 2 – TOP-UP CHARGE The charger is in constant voltage mode. The LED-indication will be FLASHING YELLOW Yellow during Top-up charge.
  • Page 13 Medical devices manufactured by Mascot have been tested and conform with the requirements of IEC/EN 60601-1-2, 3rd & 4th edition, nevertheless, special precautions may...
  • Page 14 If the measured field strength in the location exceeds the applicable RF compliance level above, the Mascot product should be observed to verify normal operation. If abnormal per- formance is observed, additional measures may be necessary, such as re-orienting or relocating...
  • Page 15 Charge diagram/ Ladediagramm/ Schéma de charge A Orange CC ch.: 1.3A <7.35V 1A <14.7V 0.56A <29.4V 0.35A <44.1V 0.27A <58.8V 100-240Vac Input Charge LED 2240(P) Orange CV ch.: 7.35V >250mA 14.7V >250mA 29.4V >250mA 44.1V >150mA 58.8V >100mA 50-60Hz voltage indicator 2241(P) Green Float ch.:...
  • Page 16 Charge diagram B Charge diagram/ Ladediagramm/ Schéma de charge B Input Charge LED voltage indicator Orange CC ch.: 4A < 7.35V 4A < 14.7V 2A < 29.4V 1.5A < 44.1V 1A < 58.8V Orange CV ch.: 7.35V > 2A 14.7V > 2A 29.4V >...
  • Page 17 Charge diagram C Charge diagram/ Ladediagramm/ Schéma de charge C Input Charge LED voltage indicator Red/Orange CC ch.: 2.7A < 7.35V 2.7A < 14.7V 1.5A < 29.5V 1.0A < 44.1V 220-240Vac 9640 Yellow Timer CV ch.: 7.35V < 2.7A (2h) 14.7V <...
  • Page 18 Charge diagram C Charge diagram/ Ladediagramm/ Schéma de charge C Input Charge LED voltage indicator Orange CC ch.: 10A < 7.35V 10A < 14.7V 5A < 29.4V 3.3A < 44.1V 2.5A < 58.8V 100-240Vac Yellow Timer CV ch.: 7.35V < 10A (4h) 14.7V <...
  • Page 19 Charge diagram D Charge diagram/ Ladediagramm/ Schéma de charge D Input Charge LED voltage indicator Yellow CC ch.: 20A < 7.35V 20A < 14.7V 10A < 29.4V 6.7A < 44.1V 5A <58.8V 115Vac/ Flash Yellow CV ch.: 7.35V 2.5 – 20A,<4h 14.7V 2.5 –...
  • Page 20 Charge diagram E Charge diagram/ Ladediagramm/ Schéma de charge E Input Charge LED voltage indicator Yellow CC ch.: 1.5A < 7.35V 1A<14.7V 0.56A<29.4V 0.4A<44.1V 0.3A<58.8V 3743(P) 100Vac/ Flash Yellow CV ch.: 7.35V 0.4-1.5A<4h 14.7V 0.25-1A<4h 29.4V 0.15-0.56A<4h 44.1V 0.1-0.4A<4h 58.8V 0.1-0.3A<4h 3743B(P) 240Vac Green Float ch.:...
