User Manual WEB
Charger for
NiCd/NiMH batteries
2015, 2115, 2116, 2215,
2216, 2415, 2515, 3015
EN
User Manual
Language specific user manuals are available on
www.mascot.no/downloads/usermanuals
Bruksanvisning
Käyttöohjeet
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
Istruzioni per l'uso
Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01
E-mail: sales@mascot.no • Web: www.mascot.no
Doc.no. 5110A - Part No. 205110 - 04.05.2015
MASCOT ELECTRONICS AS
P.O.Box 177, N-1601 Fredrikstad, NORWAY
Advertisement
Related Manuals for MASCOT 2015
Summary of Contents for MASCOT 2015
- Page 1 Manual de instrucciones Istruzioni per l’uso MASCOT ELECTRONICS AS P.O.Box 177, N-1601 Fredrikstad, NORWAY Phone: +47 69 36 43 00 • Telefax: +47 69 36 43 01 E-mail: sales@mascot.no • Web: www.mascot.no Doc.no. 5110A - Part No. 205110 - 04.05.2015...
-
Page 2: Important Safety Instructions
”IP67”, may be available. This version is filled with a potting Technical specifications for your product: compound and is dust-tight and protected against See tables, the marking on the the effects of temporary immersion in water accor- product or www.mascot.no... - Page 3 Cautions to observe prior to use • The intended use for this product is to charge a • The product is “switched on” by inserting the battery or a battery powered electrical accessory mains plug into the mains socket and “switched (NiCd/NiMH, Lead-Acid, Lithium-Ion or LiFePO off”...
- Page 4 Medical Electrical Equipment (stan- ”TERMS OF SALES AND DELIVERY FOR MAS- dards based on IEC60601-1) it complies with COT AS” apply (available at www.mascot.com). some of the requirements for medical electrical equipment and may be used in medical applica- •...
- Page 5 ctric equipment and for use in residential, office and solvents as most types of plastic may be or light industrial environment but all electric degraded by such chemicals. Also make sure to products imply a potential for electromagnetic position, operate and store such products away or other interference between the product and from UV-light and direct sunlight.
- Page 6 Mascot CPM charge diagram Top-off charge Initiation* Fast charge Trickle charge (Green LED (Yellow LED) (Orange LED) (Green LED) w. yellow flash) Battery Voltage Start timer prevents Sudden –dV not caused premature –dV by fully charged battery is disregarded Charge current...
-
Page 7: Safety Features
Most charge parameters may be altered using disregarded. an external programming tool. Contact Mascot • Top-off charge following –dV detection ensures for details. that all cells in a battery pack reaches full... - Page 8 How to use the charger The charger is started by connecting the battery hours. If in doubt; contact the battery manufacturer pack to the charger and then connecting the for details. charger to the mains. If the safety timer runs out before –dV is detected, The LED (light emitting diode) will be yellow before the charger will go directly to trickle charge mode the fast charge starts and the LED changes to...
- Page 9 Temperature control (optional feature) lf the charger is used with a temperature sensor current will then remain low until the temperature (NTC-resistor in the battery) it is possible to add is at a level where fast charge can start. lf the control to the battery charging process.
-
Page 10: Common Technical Data
How to connect exchangeable DC-output plugs To connect for desired polarity, both plug ends are clearly marked. When connected, the female plug is also mar- ked on each side to identify plug polarity. Shows the center polarity of the plug. Common technical data NiCd/NiMH 5-10...
