Westin 46-23685 Instructions Manual

2014-2015 chevy silverado & gmc sierra 1500 winch tray, 2014-2015 chevy silverado 1500 sportsman & hdx winch mount grille guards

Advertisement

Quick Links

AUTOMOTIVE PRODUCTS, INC.
ITEM
QUANTITY
1
1
2,3
2
4
2
5
4
6
6
7
2
8
2
9
6
10
4
11
4
12
2
13
2
14
2
15
1
16
1
17,18
8
19
2
20
2
21
4
22
2
23
2
24
4
25
4
26
8
27
4
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
1.
Remove contents from box, verify if all parts listed are present and free from damage. Carefully read and understand all instruc-
tions before attempting installation. Failure to identify damage before installation could lead to a rejection of any claim.
2.
Remove the filler panel from the front of the vehicle (Figures 1-4).
3.
If installing a Winch Mounted Grille Guard kit remove the vehicle's grille (Figures 5 - 6). Skip this step if installing kit 46-
23685.
2014-2015 CHEVY SILVERADO & GMC SIERRA 1500 WINCH TRAY
APPLICATION PART #'S: 45-93680, 40-93685, 57-93680, 57-93685
2014-2015 CHEVY SILVERADO 1500 SPORTSMAN & HDX
WINCH TRAY MOUNTING BRACKETS (DRV & PASS)
M12 HEX BOLTS (LONG)
M12 HEX BOLTS (SHORT)
M12 FLAT WASHERS (NARROW)
M12 FLAT WASHERS (THICK)
M12 FLAT WASHERS (WIDE)
M12 LOCK WASHERS
M12 FLANGE BOLTS
M12 SERRATED FLANGE NUTS
M10 FLANGE BOLTS
M10 SERRATED FLANGE NUTS
HDX GRILLE GUARD (57-93680, 57-93685 ONLY)
SPORTSMAN GRILLE GUARD (45-93680, 40-93685 ONLY)
UPPER SUPPORT STRAPS (57-93680/85, 45-93680, 40-93685 ONLY)
SPACER BRACKETS (57-93680/85, 45-93680, 40-93685 ONLY)
M10 BUTTON HEAD BOLT (57-93680/85, 45-93680, 40-93685 ONLY)
M10 FLAT WASHER (57-93680/85, 45-93680, 40-93685 ONLY
M10 LOCK WASHER (57-93680/85, 45-93680, 40-93685 ONLY)
M10 HEX NUT (57-93680/85, 45-93680, 40-93685 ONLY)
M12 BUTTON HEAD BOLT (57-93680/85, 45-93680, 40-93685 ONLY)
M12 FLAT WASHER (57-93680/85, 45-93680, 40-93685 ONLY
M12 FLANGE NUT (57-93680/85, 45-93680, 40-93685 ONLY)
M12 FLANGE BOLT (57-93680/85, 45-93680, 40-93685 ONLY)
INSTRUCTIONS
APPLICATION PART #: 46-23685
WINCH MOUNT GRILLE GUARDS
DESCRIPTION
WINCH TRAY
M12 HEX NUTS
Thank you for choosing Westin products.
1
TOOLS NEEDED
RATCHET
SCREWDRIVER
15MM WRENCH
15MM SOCKET
ALLEN WRENCH
18MM WRENCH
18MM SOCKET
10MM SOCKET
7MM SOCKET
16MM SOCKET
16MM WRENCH
RATCHET EXT.
TORQUE WRENCH
UTILITY KNIFE

Advertisement

loading
Need help?

Need help?

Do you have a question about the 46-23685 and is the answer not in the manual?

Questions and answers

Summary of Contents for Westin 46-23685

  • Page 1 Remove the filler panel from the front of the vehicle (Figures 1-4). If installing a Winch Mounted Grille Guard kit remove the vehicle’s grille (Figures 5 - 6). Skip this step if installing kit 46- 23685. Thank you for choosing Westin products.
  • Page 2 They will pop loose when you pull on the grille. Remove the front bumper assembly (Figures 7 & 8). If equipped, remove the factory tow hooks and foam tow hook covers (Figures 9 & 10). Thank you for choosing Westin products.
  • Page 3 (Figures 11 & 12). Note: The thick M12 washers are placed inside the large holes in the bottom of the frame then secured in place with the wide M12 washers, lock washers and hex bolts. Fig. 11 Fig. 12 Loosely install the brackets using M12 Slip the Winch Tray Mount Brackets into the frame rails. hardware. Thank you for choosing Westin products.
  • Page 4 14. With assistance loosely install the Grille Guard on the previously installed Spacer Brackets using the supplied M12 Button Head Bolts (Figure 16). 15. Loosely bolt the Upper Support Strap to the Grille Guard using the supplied M10 hardware (Figure 16). Thank you for choosing Westin products.
  • Page 5 Sportsman Winch GG Installation Complete HDX Winch GG Installation Complete 12. Align and adjust the Grille Guard as necessary. Tighten all remaining hardware; M10 to 30-35 ft-lbs., M12 to 50-55 ft-lbs. WINCH TRAY MOUNTING EXPLODED VIEW Thank you for choosing Westin products.
  • Page 6: Care Instructions

     STAINLESS STEEL PRODUCTS CAN BE CLEANED WITH MILD SOAP AND WATER. STAINLESS STEEL POLISH SHOULD BE USED TO POLISH SMALL SCRATCHES.  GLOSS BLACK FINISHES SHOULD BE CLEANED WITH MILD SOAP AND WATER Thank you for choosing Westin products.
