Westin HDX 46-22275 Instructions Manual

Grille guard winch tray 2007–13 chevy silverado 1500 (except “classic”)
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
AUTOMOTIVE PRODUCTS, INC.
ITEM
QUANTITY
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
1
10
2
11
6
12
18
13
10
14
2
15
10
16
4
17
8
18
4
19
4
20
4
21
2
22
4
23
2
24
2
25
2
26
2
27
2
28
2
29
2
30
2
31
4
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
INSTRUCTIONS
APPLICATION: 2007–13 CHEVY SILVERADO 1500 (except "Classic")
MAX WINCH TRAY: HDX 46-22275
SPORTSMAN WINCH MOUNT GRILLE GUARD: 45-92270, 40-92275
HDX WINCH MOUNT GRILLE GUARD: 57-92270, 57-92275
DESCRIPTION
WINCH TRAY (46-22275)
WINCH TRAY MOUNTING BRACKETS DRIVER (46-22275)
WINCH TRAY MOUNTING BRACKET PASSENGER (46-22275)
SPORTSMAN GRILLE GUARD (40-92275– 45-92270)
UPPER SUPPORT STRAP DRIVER (40-92275, 45-92270)
UPPER SUPPORT STRAP PASSENGER (40-92275, 45-92270)
HDX GRILLE GUARD (57-92270– 57-92275)
UPPER SUPPORT BRACKET DRIVER (57-92270, 57-92275)
UPPER SUPPORT BRACKET PASSENGER (57-92270, 57-92275)
SPACER (57-92270, 57-92275)
M12 HEX HEAD BOLT (46-22275*)
SMALL M12 FLAT WASHER (46-22275*)
M12 SPLIT LOCK WASHER (46-22275*)
LARGE M12 FLAT WASHER (46-22275*)
M12 HEX NUT (46-22275*)
LONG M12 BUTTON HEAD BOLT (46-22275*)
SMALL M12 FLAT WASHER (SS) (40-92275*, 57-92275*, 45-92270, 57-92270)
M12 LOCK WASHER (SS) (40-92275*, 57-92275*, 45-92270, 57-92270)
M12 HEX NUT (SS) (40-92275*, 57-92275*, 45-92270, 57-92270)
LONG M12 BUTTON HEAD BOLT (SS) (40-92275*, 57-92275*, 57-92270)
SHORT M10 BUTTON HEAD BOLT (SS) (40-92275*, 45-92270)
M10 FLAT WASHER (SS) (40-92275*, 45-92270)
M10 LOCK WASHER (SS) (40-92275*,45-92270)
M10 HEX NUT (SS) (40-92275*, 45-92270)
LONG M10 BUTTON HEAD BOLT (SS) (57-92275*, 57-92270)
M10 BELLVILLE WASHER (SS) (57-92275*, 57-92270)
M10 SERRATED FLANGE NUT (SS) (57-92275*, 57-92270)
M10 HEX HEAD BOLT (57-92270, 57-92275)**
M10 FLAT WASHER (57-92270, 57-92275)**
M10 LOCK WASHER (57-92270, 57-92275)**
SHORT M12 BUTTON HEAD BOLT (SS) (45-92270)
NOTE:*(BLACK), **(YELLOW), SS (Stainless steel)
1
TOOLS NEEDED
TORQUE WRENCH
ALLEN WRENCH
Thank You for choosing Westin products.
21mm SOCKET
18mm SOCKET
18mm WRENCH
17mm SOCKET
15mm SOCKET
RACHET
1/2" DRILL BIT
1/4" DRILL BIT

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDX 46-22275 and is the answer not in the manual?

Questions and answers

Related Manuals for Westin HDX 46-22275

Summary of Contents for Westin HDX 46-22275

  • Page 1 INSTRUCTIONS APPLICATION: 2007–13 CHEVY SILVERADO 1500 (except “Classic”) MAX WINCH TRAY: HDX 46-22275 SPORTSMAN WINCH MOUNT GRILLE GUARD: 45-92270, 40-92275 AUTOMOTIVE PRODUCTS, INC. HDX WINCH MOUNT GRILLE GUARD: 57-92270, 57-92275 ITEM QUANTITY DESCRIPTION TOOLS NEEDED WINCH TRAY (46-22275) 21mm SOCKET...
  • Page 2  STAINLESS STEEL PRODUCTS CAN BE CLEANED WITH MILD SOAP AND WATER. STAINLESS STEEL POLISH SHOULD BE USED TO POLISH SMALL SCRATCHES.  GLOSS BLACK FINISHES SHOULD BE CLEANED WITH MILD SOAP AND WATER. Thank You for choosing Westin products.
  • Page 3 THE BUMPER (Fig.2). IT MAY BE NECESSARY TO WIGGLE VALANCE AND BUMPER TO REMOVE STUD PLATE. Fig.1 If equipped, remove tow hooks using an 18mm socket Fig.3 Fig.2 Fig.4 PASSENGER AND DRIVER BRACKETS ITEMS 2 & 3 Thank You for choosing Westin products.
  • Page 4 LOCATION BY PLACING THE BRACKET BACK ON THE INSTALLED POSITION, THEN OPEN THE PILOT HOLE BY DRILLING THROUGH USING 1/2” DRILL BIT. NOTE: PASSENGER SIDE ONLY REQUIRES ONE HOLE TO BE DRILLED INTO THE FRAME. Fig.7 Thank You for choosing Westin products.
  • Page 5 INSTALLED, TAKE THE FACTORY BUMPER AND VALANCE ASSEMBLY. HOLD IT UP TO THE VEHICLE, MARK WHERE MOUNTING BRACKETS COME IN CONTACT WITH THE LOWER VALANCE AND TRIM TO FIT. AFTER DOING SO, RE-INSTALL BUMPER AND VALANCE TO VEHICLE. Fig.11 Thank You for choosing Westin products.
  • Page 6 GRILLE MOUNTING CLIPS. BEGIN FROM ONE END OF THE GRILLE AND INSERT A SMALL SCREWDRIVER INTO THE CLIPS TO PREVENT THEM FROM POPPING BACK INTO PLACE. REMOVE THE GRILLE BY PULLING ON IT GENTLY AND EVENLY FORWARD. Fig.16 Thank You for choosing Westin products.
  • Page 7 Fig.17 RE-INSTALL FACTORY GRILLE SHELL AT THIS TIME, LINE UP THE CLIPS AND GENTLY PUSH GRILLE SHELL INTO PLACE. DO NOT RE-INSTALL TOP COVERS. FACTORY BOLT Fig.18 Fig.19 GRILLE GUARD HDX BRACKET Fig.20 SHOWN Thank You for choosing Westin products.
  • Page 8 P/n 57-92275 Shown here, Installation complete P/n 40-92275 shown here, Installation complete Fig.23 Fig.24 ALIGN & ADJUST GRILLE GUARD AS NECESSARY THEN TIGHTEN ALL REMAINING HARDWARE: M10 to 30-35 ft-lbs., M12 to 50-55 ft-lbs. Thank You for choosing Westin products.
