Westin 57-93785A Installation Instructions Manual

ITEM QUANTITY
1 1
2 1
3 1
4 2
5 2
6 24
7 48
8 24
9 24
10 12
11 24
12 14
13 14
14 2
15 2
16 2
17 1
HARDWARE ITEMS BELOW ARE INCLUDED WITH THE GRILLE GUARD KIT
18 1
19 1
20 2
21 2
22 8
23 2
24 6
ANTI-SEIZE LUBRICANT MUST BE USED ON ALL STAINLESS STEEL FASTENERS TO PREVENT THREAD DAMAGE AND GALLING
1. Remove contents from box, verify if all parts listed are present and free from damage. Carefully read and understand all instruc-
tions before attempting installation.
2. Remove the factory tow hooks (if equipped). They cannot be re-used.
Westin Automotive Products, Inc.
320 Covina Blvd
San Dimas, Ca. 91773
P.N.: 75-5793785A-RevB ECO #: W21-0026
INSTALLATION INSTRUCTIONS
APPLICATION:
2015-2019 Chevy Silverado 2500/3500
PART NUMBER:
Winch Tray Kit: 46-23785
Grille Guard Kit: 57-93785A
WINCH TRAY (46-23785)
WINCH TRAY INNER MOUNTING BRACKET DRIVER (46-23785)
WINCH TRAY INNER MOUNTING BRACKET PASSENGER (46-
WINCH TRAY OUTER MOUNTING BRACKETS
WINCH TRAY MIDDLE MOUNTING BRACKETS
M10 HEX HEAD BOLT
M10 FLAT WASHER
M10 LOCK WASHER
M12 HEX HEAD BOLT
M12 FLAT WASHER
M12 LOCK WASHER
M12 LARGE FLAT WASHER
M12 FLANGE BOLT
M12 SQUARE POLY BOLT RETAINER
HDX GRILLE GUARD ( 57-93785 ONLY)
SUPPORT STRAP DRIVER SIDE & PASS (57-93785 ONLY)
SUPPORT STRAP PASSENGER SIDE (57-93785 ONLY)
SPACER BLOCKS (57-93785 ONLY)
M10 STAINLESS SHORT BUTTON HEAD BOLT (57-93785)
M10 STAINLESS CUPPED WASHER (57-93785)
M10 STAINLESS FLANGE NUT (57-93785)
M10 STAINLESS LONG BUTTON HEAD BOLT (57-93785)
HDX Winch Mount Grille Guard
DESCRIPTION
23785)
M10 HEX NUT
M12 HEX NUT
Thank You for choosing Westin products
For Additional installation assistance please call
1
Kit Number: 57-93785
TOOLS NEEDED
RATCHET
SCREWDRIVER
15MM WRENCH
15MM SOCKET
ALLEN WRENCH
18MM WRENCH
18MM SOCKET
10MM SOCKET
16MM SOCKET
16MM WRENCH
RATCHET EXT.
TORQUE WRENCH
Customer service (800) 793-7846
www.westinautomotive.com
DATE: 07/12/2021
