- Page 1 Installation Guide Models Covered: TGRDC06 TGRDMOP06 Please keep this booklet for future reference. Installer: When you have read these instructions, please ensure you leave them with the user.
-
Page 2: Table Of Contents
I N T R O D U C T I O N Thank you for buying a Heritage Product. When you buy a Heritage product, you can be confident that it not only features a beautiful, distinctive, classic design, but that it has also been made to the very highest quality standards. -
Page 3: Safety Notes
RM12 6NB, Tel: 01708 472791 S P E C I F I C AT I O N OPERATING PRESSURE RANGE (BAR): TGRDC06/TGRDMOP06 - Min 0.2 bar, Max 5.0 bar MAXIMUM STATIC PRESSURE (BAR): 10 bar INLET WATER TEMPERATURE RANGE: Cold - Min 5°C, Max 25°C Hot - Max 65°C... -
Page 4: Pack Contents
P A C K C O N T E N T S TGRDC06... -
Page 5: Installation
I N S TA L L AT I O N On the side bodies, prise out the indices and unscrew the screws to remove the handles. Unscrew the shrouds. Feed the side bodies from underneath. The bodies are marked (H) for hot and (C) for cold. - Page 6 I N S TA L L AT I O N Connect the centre tee to the sidebodies by hand using Secure the spout the flexible tails. using the backnut and washers. Connect the hot and cold water supplies to the threaded tails. Fit the centre tee onto the spout and tighten the nut on...
-
Page 7: Operation
I N S TA L L AT I O N Screw the horizontal arm, ball side first into the waste body ensuring Connect the rods using the washer is in place. the pop up connector. Tighten screws to secure. Operation Push to Close Waste;... -
Page 8: Maintenance
M A I N T E N A N C E REMEMBER Clean/Replace Valves Be careful of the plated finish on the valves! Use a suitable spanner to remove the valves. Prise out the indices and unscrew the screws to remove the handles. -
Page 9: Caring For Your Product
C A R I N G F O R Y O U R P R O D U C T Heritage products are made from premium materials, with hand polishing and electroplated finishes. Your product should be regularly cleaned with warm water, a mild pH-neutral liquid soap, and polished with a soft cloth. -
Page 10: Troubleshooting
T R O U B L E S H O O T I N G Symptom Cause Remedy Partially closed isolation valve. Open isolation valve. Instantaneous water heater cycles on and off Increase water flow rate or pressure as flow rate or pressure is too low. through system. -
Page 11: Notes
N O T E S... - Page 12 If you have any queries, our dedicated customer service teams and products experts are available to help. www.heritagebathrooms.com enquire@heritagebathrooms.com 0330 026 8503 Website Email us Call us UK: Heritage Bathrooms, Pooley Hall Drive, Birch Coppice Business Park, Dordon, Tamworth B78 1SG EU: Masco Europe S.à.r.l., 14 Rue Strachen, 6933 Mensdorf, Luxembourg.
