Backyard Play Systems 4052 Manual

Playset
Hide thumbs

Advertisement

Quick Links

Download this manual
2998-20
- NOTICE -
This playset product is not intended for public use. It is intended for
residential application and is not warranted for public or commercial use.
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
Call our toll-free number:
1-866-890-2211
April through October M - F 8:00 AM to 6:00 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST
or email:
customerservice@backyard-play.com
Our staff is ready to provide assistance.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4052 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Backyard Play Systems 4052

Summary of Contents for Backyard Play Systems 4052

  • Page 1 2998-20 - NOTICE - This playset product is not intended for public use. It is intended for residential application and is not warranted for public or commercial use. STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information Call our toll-free number: 1-866-890-2211 April through October M - F 8:00 AM to 6:00 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 3 2998-20 3/10/2020 Model 4052, 4412, Backyard Play Systems Customer Service 4431, 5034, 6401 1-866-890-2211 Playset 1000 Ternes Drive Monroe, MI 48162 Recommended for Ages 3 to 11 - BEFORE YOU BEGIN - - BEFORE YOU BEGIN - Tools Required Adult Assistance required First...
  • Page 4 ASSEMBLY SAFETY and HELPFUL HINTS STOP!!! Check all parts and hardware before beginning. If any parts are missing or damaged please circle and call the phone number listed. DO NOT CONTACT THE STORE OR RETURN YOUR PLAYSET ! KEEP THIS INSTALLATION MANUAL FOR FUTURE CARE AND MAINTENANCE REFERENCE.

  • Page 5: Safety Warnings

    SAFETY WARNINGS Please read carefully. Observing the following statements and warnings reduces the likelihood of serious or fatal injury.               Never add extra length to chain or rope. The chains or rope provided are the maximum length designed for the swinging elements.

  • Page 6: Maintenance

    MAINTENANCE Periodic maintenance is required to ensure safe enjoyment of your playset and optional accessories. Observing the following procedures reduces the likelihood of serious or fatal injury.  Activity on your playset and optional accessories may loosen fasteners. Check all lock nuts, hex and lag bolts, quick clips, spring clips, acorn nuts, wood screws, and swing hangers for tightness and tighten as required.
  • Page 7 PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.

  • Page 8: Back Side

    PLAYSET ORIENTATION *Hint* Throughout this manual references made to the Left Side, the Right Side, the Front Side and the Back Side of the playset serve as a consistent reminder to help with assembly. RIGHT SIDE BACK SIDE FRONT SIDE LEFT SIDE...
  • Page 9 IMPORTANT! Use these Assembly Procedure Hints throughout the installation process. 1. All Lag Bolts must have pre-drilled holes. Use a 1/4” drill bit for all 3/8” Lag Bolts. Use a 3/16” drill bit for all 5/16” Lag Bolts. Pre-drilling pilot holes will help prevent Screws and Lag Bolts from breaking and wood from splitting during assembly.

  • Page 10: W O O D P A R T S L I S T

    W O O D P A R T S L I S T 1 x 3-3/8 x 45" 3/4 x 3-3/8 x 45-1/8" 1-3/8 x 3-3/8 x 18" 1-3/8 x 3-3/8 x 51" 2968-CC 2970-CC 2899-CC 1 x 3-3/8 x 46-5/8" 3/4 x 2-1/2 x 45"...
  • Page 11 Angle Bracket Plate Swing Beam 90 Plate Swing Beam Angled Plate Left Swing Beam Angled Plate Right 2485 L-Bracket 2412 2449 2448 2447 Swing Beam Flat Plate Anchor Stake Swing Hanger 1-1/4" (31,7 mm) WS 4456 2411 WS 4521 Trapeze Swing Climbing Rocks 04-0039-Y/Y...
  • Page 12 3/8" LOCK WASHER 3/8" LOCK NUT 3/8" T - NUT 3/8" 3/8" TRUSS HEAD 3/8" FLAT WASHER 1/4" LOCK SCREW WASHER 3/4" 1/4" 3/8" 2-1/2" 5/16" T - NUT 3/16" x 1" FENDER WASHER PAN HEAD SCREW 1" 2-1/2" 5/16" FLAT WASHER 5/16"...

  • Page 13: Wood Screws

    3/8” HEX HEAD BOLTS 1" 1-1/4" 2" 3/8" 3/8" 3-3/4" 3/8" 3/8" 5" LAG BOLT 3/8" LAG BOLT 3/8" 3" 4" 3/8" WOOD SCREWS x195 30 mm 2" 2-1/2" 3"...
  • Page 14 3-3/4" 4-1/2" 6" 6-1/2" 8-1/2" 3" 3/8" 3/8" HEAD BOLTS 3/8" 1-3/4” 2” ” 2-1/4” 3/8" 3/8" 3/8” 3/8” BUTTON HD. BUTTON HD. BUTTON HD. 3/8” SCREW SCREW SCREW BUTTON HD. SCREW 3/8" TORQUE WASHER 1-1/2” 1-1/2” 1-1/2” 1-1/4” 1-1/2” 1-1/2”...
  • Page 15 C L U B H O U S E P A R T S L I S T 3/4 x 3-3/8 x 19-1/4" 3/4 x 3 x 6-15/16" 1806-CC 1814-CC 5/8 x 3-1/4 x 5" 3/4 x 3 x 10-5/16" 1807-CC 1811-CC 5/8 x 1-7/8 x 12-7/16"...
  • Page 16 C L U B H O U S E H A R D W A R E 3/8” BUTTON HD. 3/8” BUTTON HD. BUTTON HD. 3/8” SCREW SCREW SCREW BUTTON HD. SCREW 3/8” 6” 1-1/2” 1-1/2” 1-1/2” 5/16" T - NUT 1-1/4”...

  • Page 17: Safety Area

    PLAYSET SET-UP SAFETY AREA 27'-1" BACK SIDE 15'-1" LADDER 13'-4" SWING 32'-8" TERRACE 25'-0" HEIGHT 13'-0" 10'-2" 13'-4" ROCK WALL SLIDE FRONT SIDE PLAYSET SET-UP WITH MONKEY BARS SAFETY AREA BACK SIDE 27'-1" MONKEY BARS 15'-1" 13'-4" 18'-8" 26'-8" 30'-8" SWING 25'-0"...

  • Page 18: Corner Posts

    FORT CORNER POSTS 3" Lag Bolt 2953-CC Lock Washer Flat Washer Flush Note hole location. 3-3/4" Hex Bolt Lock Washer Hole for Climbing Rope Flat Washer 2-1/2" Wood 2968-CC Flush Screw 3/4 x 3-3/8 x 45-1/8" 47-1/4" 12-5/8" Flush 2899-CC T-Nut 90°...
  • Page 19 FORT FRAME BRACING 3/4 x 3-3/8 x 45-1/8" 2973-CC Note hole location. Ensure all bracing is 1 x 3-3/8 x 45-1/8" square before installing 2899-CC wood screws. 2-1/2" Wood Screw 3/4 x 5-3/8 x 45-1/8" Flush 2969-CC Flat Washer Flat Washer Lock Nut Flush 5"...
  • Page 20 BOTTOM FRAME BRACE FORT FLIP ASSEMBLY OVER TO INSTALL BOTTOM BRACE. 2-1/2" Wood Screw 3/4 x 5-3/8 x 45-1/8" 90° 2969-CC Flush Flush FORT CONNECT FRAME SECTIONS Align braces with pre-drilled holes. ENSURE THESE HOLES ARE ON THIS SIDE. Flat Washer Flat Washer 5"...
  • Page 21 FORT DECK CLEAT 3/4 x 2-1/2 x 45" 2516-CC Flush 2-1/2" Wood Screws Flush 3/8" To avoid splitting wood pre-drill (2) 11/64" holes FORT DECK PLANKS Flush with post. 3/4 x 5-3/8 x 44-7/8" 2961-CC 2-1/2" Wood Screws evenly spaced 30 mm Wood Screws Flush (In center of planks)
  • Page 22 FORT DECK PLANKS 3/4 x 3 x 38-7/8" 2962-CC 2-1/2" Wood Screws Flush along outer edge Wood Screws 1-1/4" FORT DECK SUPPORT 2" Wood Screws 1-3/8 x 3-3/8 x 18" (2" screws into deck frame) 2970-CC 2" Wood Screws from inside Flush to Flush inside of 3x3...

  • Page 23: Front Side

    FORT SWING BEAM SUPPORT Note this rope-hole location 6" Carriage Bolt Torque Washer Small Holes UP Flat Washer 6" Carriage Bolt Lock Nut SET ON RAIL 2505-CC 3 x 3 x 45-1/8" Flat Washer Lock Nut Torque Washer FORT BALUSTER SUPPORTS SWING BEAM Part 1814-CC is used in several applications.

  • Page 24: Back Side

    FORT BALUSTER SUPPORT Part 1814-CC is used in several applications. Do not use the holes on the left side. 1 8 1 4 - C C Note this rope-hole location Pre-Drill 1/8" hole 3/8" SWING BEAM up from lower edge of 3/4 x 3-3/8 x 19-1/4"...
  • Page 25 AUX. FLOOR SUPPORT FORT Flush at corners 2-1/2" Wood Screw Flush 2973-CC 3/4 x 3-3/8 x 45-1/8" 59-1/4" LEFT SIDE FRONT SIDE FORT ROOF SUPPORT 2-1/2" Wood Screws 3/4 x 3-3/8 x 53-7/8" 2976-CC 4-3/8" 4-3/8"...
  • Page 26 ROCK WALL ASSEMBLE Rail (1826-CC) may have full or partiallly pre-drilled holes. Align screws with the pre-drilled holes in rails (1826-CC). 1-3/8 x 3-3/8 x 51" 1826-CC 23-3/4" 3/4 x 5-3/8 x 23-3/4" Outside 2960-CC Dimension Flush 2-1/2" Wood Screws 5-1/4"...
  • Page 27 ROCK WALL ROCKS Install rocks at pre-drilled hole locations. 1/4" x 1-1/2" Hex Bolts 1/4" Lock Washers WS 4545 1/4" Flat Washers x3 BAG T-Nuts Do NOT attach top board at this time. ROCK WALL BRACKETS 2412 5/16" T-Nut 5/16 x 1-1/2" Button Head Screw L-Bracket 5/16"...
  • Page 28 ROCK WALL INSTALL Mark (2) bracket holes. 3-3/4" Mark FRONT SIDE ROCK WALL INSTALL SEE PAGE 7 FRONT SIDE Pre-drill two 1/4" pilot holes at marked locations. Rock Wall Re-drill holes from opposite side using 3/8" bit.
  • Page 29 ROCK WALL INSTALL FRONT SIDE Rock Wall 5/16" T-Nut ROCK WALL INSTALL 5/16" Flat Washer 5/16" Lock Washer 5/16" x 1-1/4" Button Head Screw BEGIN HERE 2-1/2" Wood Screws 2-1/2" Wood Screws 2967-CC 3/4 x 3-3/8 x 27" 2" Wood Screws...
  • Page 30 INSTALL ANGLE BRACE Pre drill 3/16" pilot hole 2-1/2" Wood Screws 3/4 x 5-3/8 x 23-3/4" Flat Washer 2" deep for 4" lag bolt. 2950-CC Lock Washer 2966-CC: Flush 4" angle to inner Lag Bolt corner of 3x3 post Flush 1-3/8 x 3-3/8 x 47-3/4"...
  • Page 31 ASSEMBLE STEP LADDER 1/2" From Angle 2-1/2" Wood screws 2965-CC 3/4 x 3-3/8 x 17" STEP LADDER ASSEMBLE 5/16" Flat Washer 5/16" Lock Washer 5/16" T-Nut 5/16 x 1-1/2" Button Head Screw 5/16" L-Bracket...
  • Page 32 INSTALL STEP LADDER Flush Flush 4-3/4" Mark Bracket Hole Flush Locations. Ladder Rail BACK SIDE STEP LADDER INSTALL SEE PAGE 7 Pre-drill two 1/4" pilot holes at marked locations. Re-drill holes from opposite side using 3/8" bit. BACK SIDE...
  • Page 33 INSTALL STEP LADDER BACK SIDE Ladder 5/16" T-Nut STEP LADDER INSTALL 5/16" Flat Washer 5/16" Lock Washer 5/16" x 1-1/4" Button Head Screw...
  • Page 34 SWING BEAM SWING HANGERS - INSTALL Swing Beam Flat Washer Swing Hanger Bolt Swing Hanger Flat Washer IMPORTANT! Final position of each Spring Clip is WS 4456 perpendicular to swing beam. Swing Hanger You may need to tap with hammer to get though holes. Spring Clip SWING BEAM SWING HANGERS...
  • Page 35 UPRIGHT INSTALL Center 2977-CC. Mark and Pre drill 7/16" through holes for hex bolt. Flat Washer Lock Washer T-Nut 1-1/4" Hex Bolt SWING BEAM SUPPORT 2505-CC 1 x 3-3/8 x 47" 2977-CC Flush A - FRAME ASSEMBLE T-Nut x2 2525-CC 3 x 3 x 95"...
  • Page 36 A - FRAME ASSEMBLE 3-3/4" Hex Bolt Lock Washer Flat Washer 2-1/2" Wood Screws 2978-CC 1 x 3-3/8 x 68-1/2" Pre-installed T-Nuts are underneath. SWING BEAM FLAT PLATE 3" Carriage Bolt 2411 Flat Washer Lock Nut...
  • Page 37 A - FRAME PLATE 2449 3-3/4" Carriage Bolt Lock Nut Flat Washer 2525-CC SWING BEAM ANGLED PLATES 3-3/8 x 5-3/8 x 95" DO NOT FULLY TIGHTEN 2502-CC CARRIAGE BOLTS AT THIS TIME Flat Washer Lock Nut 2448 4-1/2" Carriage Bolt NOTE: You may need to tap bolts with hammer to get though holes.
  • Page 38 SWING BEAM ASSEMBLE Position swing beam assembly resting upon A-frame. SWING BEAM ASSEMBLE Align holes and insert carriage bolt. Repeat where arrows are shown. NOTE: You may need to tap bolts with hammer to get though holes. Clean all debris from bolt threads before installing lock nuts 3-3/4"...
  • Page 39 SWING BEAM ASSEMBLE 6-1/2" Carriage Bolt Torque Washer You may need to tap with Flat Washer hammer to get though holes. Lock Nut SWING BEAM INSTALL Position swing beam assembly resting 8-1/2" Carriage Bolt upon plate and align with holes. 6-1/2"...
  • Page 40 SWING BEAM INSTALL SEE PAGE 7 1. Pre-drill using 3/16" bit. 2. Re-drill from opposite side using 7/16" bit. SWING BEAM INSTALL Flat Washer T-Nut Lock Washer 1" Hex Bolt...
  • Page 41 SWING BEAM ASSEMBLE 2-1/2" Pan Head Screw 1/4" Lock Washer BALUSTERS FORT Install end-balusters first, 1" 1" 1" 1" from upright. 1" 1" 1" 1" 30 mm Wood Screws 1" 2523-CC 5/8 x 3-1/4 x 29-3/4" Flush...
  • Page 42 ROCK WALL SIDE BALUSTERS FORT 5/8 x 4-7/8 x 29-3/4" 5/8 x 3-1/4 x 29-3/4" 1809-CC 1811-CC Install end-baluster first Flush tightly against fort 3x3" corner post. 30 mm Wood Screws BEGIN HERE 5/8 x 3-1/4 x 9-1/2" 1810-CC Flush (ALL) VIEW Flush...
  • Page 43 ACCESSORIES NOTICE STOP! STOP! IF YOU HAVE THE MONKEY BAR OPTION GO TO PAGE 66 FOR ASSEMBLY AND INSTALLATION INSTRUCTIONS. IF NOT, CONTINUE TO INSTALL LADDER-SIDE BALUSTERS.
  • Page 44 LADDER SIDE BALUSTERS FORT 13/16" 13/16" 13/16" 13/16" INSTALLATION: 30 mm FROM INSIDE FORT Wood Screws VIEW 5/8 x 3-1/4 x 29-3/4" BEGIN 2523-CC HERE INSIDE VIEW Flush LADDER SIDE BALUSTERS FORT 30 mm Flush Wood Screws 1" TYP. 1" TYP. BEGIN HERE INSTALLATION:...
  • Page 45 BAY WINDOW FORT 2-1/2" Wood Screws 1 x 5-3/8 x 45-1/8" 1808-CC Flush BAY WINDOW FORT 2" Wood Screws Flush 3/4 x 3 x 10-5/16" 1807-CC 3/4 x 3 x 6-15/16" 1806-CC Flush...
  • Page 46 TERRACE NOTICE STOP! STOP! YOU WILL BUILD YOUR TERRACE AT THIS TIME. GO TO NEXT PAGE.
  • Page 47 T E R R A C E P A R T S L I S T 5/8 x 3-1/4 x 29-3/4" 3/4 x 2-1/2 x 45-1/8" 2516-CC 2523-CC 1 x 3-3/8 x 45-1/8” 5/8 x 3-3/8 x 45-1/8" 1817-CC 1815-CC 5/8 x 3-1/4 x 27-1/2"...
  • Page 48 H A R D W A R E P A R T S L I S T 3/8" HEX BOLT 3/8” LOCK WASHER 3/8” T - NUT 3/8” 3/8" LOCK NUT 3/8” FLAT WASHER 5" 3/8" HEX BOLT 3/8" 3/8” 2"...
  • Page 49 FRAME ASSEMBLE Flush Flush 5/8 x 3-3/8 x 45-1/8" 1817-CC T-Nut 3/4 x 3-3/8 x 45-1/8" Flush 1820-CC BOTTOM 90° Flush Note hole locations (2) Flush T-Nut 90° 27-1/2" 1823-CC 1-3/8 x 3-3/8 x 95" Flush 62-3/4" 90-1/2" Flush 1-3/4" Wood Screws Flush Ensure Frame is square before installing wood screws.

  • Page 50: Side Rails

    SIDE RAILS INSTALL 1-3/4" Wood Screws 2" Hex Bolt Lock Washer 5/8 x 3-3/8 x 45-1/8" 1817-CC Flat Washer Flush Flush Flush 90° 90° 1 x 3-3/8 x 45-1/8" 27-1/2" 1815-CC Flush 59-1/4" Ensure Side Rails are square before installing fasteners. SIDE RAILS INSTALL Flush...
  • Page 51 TERRACE ASSEMBLE Flush Flush Flush Ensure side rails are level Flush before installing wood screws. L E V E L E V E L Attach Terrace to playset tower frame. 2-1/2" Wood Screws L E V E Flush L E V E L 59-1/4"...
  • Page 52 INSTALL DECK SUPPORT & BAR TOP 3/4 x 2-1/2 x 42-1/2" Pre-drill 1/8" holes to avoid splitting 1825-CC " 3 / 4 2-1/2" Wood Screws 1 5 - Flush to top of 2490-CC slide block Pre-drill 1/8" holes to avoid splitting 1-3/4"...
  • Page 53 INSTALL DECK PLANKS Wood Screws 30 mm 2-1/2" Wood Screws 3/4 x 5-3/8 x 30-1/2" 1819-CC Note hole location. End Screws: 2-1/2" (24) Middle Screws: 30 mm (12) Equally spaced End Screws: 2-1/2" Ensure equal spacing of deck planks before Top View installing wood screws.
  • Page 54 INSTALL BALUSTERS Use a baluster as a spacer to ensure correct baluster placement. 30 mm Wood Screws 3-1/4" From Corner Post BACK SIDE 5/8 x 3-1/4 x 29-3/4" 2523-CC Flush Ensure balusters are spaced evenly before installing wood screws. INSTALL BALUSTERS Use a baluster as a spacer to BEGIN MEASURING...
  • Page 55 INSTALL ENTRY ARCH 3/4 x 5-1/2 x 45-1/8" 2-1/2" Wood Screws 1822-CC Flush Install Entry Arch fl ush up against bottom of playset roof rail. Flush FORT BALUSTER SUPPORTS Flush 2-1/2 Wood 3/4 x 3-3/8 x 12" Screws 2975-CC Flush...

  • Page 56: Safety Barrier

    FORT SAFETY BARRIER VIEW FROM UNDER TERRACE LEVEL EQUAL EQUAL Flush 2973-CC 2-1/2" Wood Screws 3/4 x 3-3/8 x 45-1/8" INSTALLATION: UNDER TERRACE BALUSTERS FORT INSTALLATION: 2-1/2" 2-1/2" FROM INSIDE FORT VIEW FROM INSIDE FORT VIEW 30 mm Wood Screws 5/8 x 3-1/4 x 29-3/4"...

  • Page 57: Outside View

    FORT BAY WINDOW 30 mm Wood Screws Flush at top Flush at top Flush 5/8 x 3-1/4 x 12-7/16" 2853-CC BEGIN HERE Flush at corner. BAY WINDOW FORT EQUAL EQUAL Flush Flush Flush 5/8 x 3-1/4 x 12-7/16" 5/8 x 1-7/8 x 12-7/16" 2853-CC 2852-CC 30 mm Wood Screws...
  • Page 58 FORT BAY WINDOW 5/8 x 3-1/4 x 12-7/16" 30 mm Wood Screws 2855-CC Flush Flush OUTSIDE VIEW Flush FORT BAY WINDOW SIDE VIEW EQUAL 2855-CC #8 x 3/4" Flat Head PF2990 Phillips Screws EQUAL EQUAL EQUAL OUTSIDE VIEW...

  • Page 59: Inside View

    SWING BEAM SIDE WINDOWS FORT 30 mm Wood Screws 5/8 x 3-1/4 x 14-3/4" 5/8 x 2-15/16 x 16-13/16" 2855-CC 2864-CC Flush 1-11/16 INSTALLATION: FROM INSIDE FORT 1-11/16 INSIDE VIEW SWING BEAM SIDE WINDOWS FORT SIDE VIEW #8 x 3/4" Flat Head EQUAL PF2990 Phillips Screws...
  • Page 60 ROOF FRAME Orient 2963-CC so that pre-drilled holes at the top are horizontal. If the holes are not horizontal, rotate the board. Secure 2964-CC and 2963-CC using 3" screws. Look for Pre-Drill at end of 2964-CC 1 x 3-3/8 x 40-1/2" Flush 2963-CC 1 x 3-3/8 x 37-1/8"...
  • Page 61 ACCESSORIES NOTICE STOP! STOP! REFER TO THE WOOD ROOF MANUAL AT THIS TIME.
  • Page 62 SWINGS INSTALL Attach Playset Plaque using one 1" philips head screw (provided) at each corner of plaque. SA 4220 04-0006-G/G TRAPEZE 04-0039-Y/Y 04-0039-Y/Y SWING SWING 53" Adjust chains at Top 8" 8" Minimum when occupied. Adjust chains at Top.

  • Page 63: Steering Wheel

    STEERING WHEEL INSTALL Install 07-0004-Y inside fort. Flat Washer 1-1/2" Lag Bolt DO NOT OVER-TIGHTEN LAG BOLTS. Steering Wheel Cap 07-0004-Y TELESCOPE INSTALL Telescope and Bracket 1. Position Mounting Bracket in desired location (any Top Rail). 07-0040-G/Y 2. Attach Mounting Bracket to Top Rail using the Mounting Screw provided.
  • Page 64 STAKES FORT 1-1/2" Metal Anchor Lag Bolts Straps Flat Washers Metal Anchor Straps Flat Washers 1-1/2" Lag Bolts SWING BEAM SIDE WS 4521 WS 4521 Install stakes into 3 x 3" uprights. Locate stakes as shown. Make sure all base pieces and uprights are resting fl at on the ground.
  • Page 65 ACCESSORIES CLIMBING ROPE 2968-CC OPTIONAL: Tie several single knots in locations to allow logical hand-grab points. 2974-CC Step 1 Feed top of Climbing Rope through front of Upper Rail (2968-CC) and tie a double knot on the back side ( Fig.

  • Page 66: Safety Handle

    ACCESSORIES SAFETY HANDLES - STEP LADDER 07-0005-G 1-1/2" Lag Bolt Flat Washer DO NOT OVER-TIGHTEN LAG BOLTS. ACCESSORIES SAFETY HANDLE 07-0005-G Flat Washer 1-1/2" Lag Bolt DO NOT OVER-TIGHTEN LAG BOLTS!

  • Page 67: Front Side

    ACCESSORIES FLAGS Locate fl ag base EQUALLY from top, bottom and end of upper top rail (Fig. 1). Attach each fl ag with 4 screws. 3/4" Truss Head Screws EQUAL EQUAL EQUAL FRONT SIDE Fig. 1 ACCESSORIES SLIDE Secure Slide using (4) 1-3/4" Pan Head Locate Slide centered in the opening between Screws through slide and into deck board.
  • Page 68 ACCESSORIES SLIDE SURFACING MATERIAL (not supplied) Apply Surfacing Material at recommended depth, or deeper. Hammer PF 6295 Ground Stake into ground on either side of slide and attach to INSIDE slide wall 4" using (2) 1-1/4" Screws. 1-3/8 x 3-3/8 x 17" PF 6295 ACCESSORIES MONKEY BAR...
  • Page 69 M O N K E Y B A R P A R T S L I S T End Ladder Angle Brace Anchor 1-3/8 x 3-3/8 x 57" 2983-CC WS 4522 End Ladder Bottom Support 1-3/8 x 3-3/8 x 80-1/2" 2985-CC Top Ladder Rail Support 1-3/8 x 3-3/8 x 78"...

  • Page 70: Actual Size

    M O N K E Y B A R H A R D W A R E - NOTICE - Depending on your playset model, you will have extra hardware left over. 3/8" FLAT WASHER 3/8" x 1-1/2" 3/8" T NUT BUTTON HD.
  • Page 71 MONKEY BAR METAL PARTS 18-1/2" 21-1/2" Flat Metal Bracket L-Bracket Top Rung End Rung 2023 2084 PF 4972 PF 3297 FASTENERS FOR METAL RUNGS 2-1/2" Lock Flat 1/4" Washer Washer Pan Head Screw TOP RAIL MONKEY BARS 1" x 18-1/2" 1-3/8 x 3-3/8 x 78"...
  • Page 72 END RAIL ASSEMBLY 1-3/8 x 3-3/8 x 81-1/16" 2-1/2" Pan Head Screw 1 x 21-1/2" 2986-CC PF 3297 1/4" Lock Washer Flat side against wood. Align with pre-drilled holes ASSEMBLY TOP RAIL / BRACKETS 1-3/8 x 3-3/8 x 78" Flat Washer 2984-CC Lock Washer 2023...
  • Page 73 END LADDER / TOP LADDER ASSEMBLY END RAIL Flat Washer Lock Washer 1-1/2" Button Head Screw T-Nut 3-1/4" Hex Bolt TOP RAIL Lock Washer Flat Washer T-Nut 1-1/2" Button Head Screw Lock Washer Flat Washer Flat Washer Lock Washer 3-1/4" Hex Bolt...
  • Page 74 INSTALL ANGLE BRACES / BOTTOM SUPPORT Flat Washer (x2) Lock Washer 3-3/4" T-Nut Hex Head Bolt (x2) 1-3/8 x 3-3/8 x 57" 2983-CC 2-1/2" Hex Head Bolt (x2) Lock Washer Flat Washer 4-3/4" Hex Head Bolt (x2) T-Nut 2985-CC 1-3/8 x 3-3/8 x 80-1/2" 2-1/2"...
  • Page 75 MONKEY BAR INSTALL POSITION * USE CARE WHEN INSTALLING MONKEY BARS TERRACE SIDE SWING BEAM SIDE * TWO PEOPLE AND A STEP LADDER ARE RECOMMENDED FOR THIS STEP MONKEY BAR INSTALL - STEP 1 Ensure inner side of Flush at Top Ladder Rail is flush *Hint –...
  • Page 76 MONKEY BAR INSTALL - STEP 2 Drill-Through 3/16" marked locations. Re-Drill through using 7/16" bit from inside fort. MONKEY BAR INSTALL - STEP 3 Flush at T-Nut Flat Washer LockWasher 1" Hex Bolt Bolts must not protrude beyond T-Nut. Add flat washers as needed.
  • Page 77 INSTALL ANCHOR STAKES Metal Straps 1/4 x 1-1/2" Lag Bolts WS 4522 Flat Washers Install on Bottom Rail. Instructions for anchoring your playset product to the ground. 1. Determine the final location of your playset product. 2. Place the Anchor Stakes adjacent to the base and near the corners of your playset product (at the bottom of the legs on swing sets) and twist the auger-style Anchor Stakes into the ground until only the loop is exposed.
  • Page 78 ACCESSORIES NOTICE STOP! STOP! AFTER INSTALLING MONKEY BAR ACCESSORY RETURN TO PAGE 42 AND CONTINUE INSTALLING LADDER-SIDE BALUSTERS. ACCESSORIES NOTICE STOP! STOP! IF YOU HAVE THE ACTIVITY TABLE ACCESSORY OPTION REFER TO THAT MANUAL AT THIS TIME...
  • Page 79 (This page intentionally left blank.)
  • Page 80 (This page intentionally left blank.)
  • Page 81 (This page intentionally left blank.)

  • Page 82: Warranty Registration

    Systems. Labor warranty does NOT apply to Do-It-Yourself playset kits or kits installed by a third party. Backyard Play Systems will repair, replace or pay for the affected part at our discretion. In no event shall Backyard Play Systems pay the cost of labor or installation or any other costs related thereto.
  • Page 83 Backyard Play Systems does not assume, or authorize any person to assume for us, any other liability in connection with the sale of our products.

This manual is also suitable for:

4412443150346401
