Backyard Play Systems PB 8326 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Model: PB 8326
Customer Service
1-866-890-2211
1000 Ternes Drive
Monroe, MI 48162
IMPORTANT!!
PLEASE READ BEFORE BEGINNING ASSEMBLY!!
Please make sure all lumber, hardware and accessory parts are accounted for.
If you are missing anything, please DO NOT RETURN to the store where purchased.
Please call our Customer Service Department at the number below.
ASSEMBLY INSTRUCTIONS
Email us at: customerservice@backyard-play.com or call us at 1-866-890-2211
Printed in USA
LDR 3-9-2015
LA 7510
