Tools Required
First...
Check with your homeowner's association before
assembling.
Socket Set
Read instructions thoroughly before you begin. If you
have purchased accessories to accompany this play
Hammer
set, please read all installation instructions before
beginning assembly of this structure.
9/16" Combination
Check All Parts
Wrench
If a part is missing, circle the part in question and call.
Important
3/16" Allen Wrench
In a drawing, a dotted line represents a part hidden
from view (like a part under a panel).
#2 Square Drive
Bit (included)
#3 Phillips Bit
Cordless Drill
w/Charger
1/8" Drill Bit
7/16" Drill Bit
1/4" Drill Bit
3/8" Drill Bit
Tape Measure
Level
C - Clamps
6' Step Ladder
Framing/Speed
Square
This playset product is not intended for public use. It is intended for
residential application and is not warranted for public or commercial use.
Your premium playset is manufactured from wood which has many natural characteristics and blemishes that may be present in some of the pieces in your playset. These natural characteristics may include knots or minor
cracks/splits. All individual parts have been cut to provide a smooth and safe surface. All parts have been inspected to assure we pack only the safest, most durable wood product. Any minor blemishes in your playset will
not affect the strength, durability, or structural integrity of the fi nished product. Our limited warranty does not cover the imperfections not resulting in structural failure.
Backyard Play Systems
Playset
Recommended for Ages 3 to 11
- BEFORE YOU BEGIN -
- BEFORE YOU BEGIN -
- NOTICE -
Model 4136
Model 6259
Adult Assistance required
Assistance is necessary to handle, t
and secure some components.
Squareness is very Important!
Start with a level surface and keep 90° corners and 90°
perpendiculars throughout the assembly to ensure all
components fi t together.
Safety!
Check for protruding screws and bolts, verify all screw
and bolt lengths during assembly.
Always wear OSHA-APPROVED safety
glasses throughout assembly process.
2286
05/22/2012
