Backyard Play Systems 4097 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
2690-RR
- NOTICE -
This playset product is not intended for public use. It is intended for
residential application and is not warranted for public or commercial use.
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll-free number:
1-866-890-2211
April through October M - F 8:00 AM to 6:00 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST
or email:
customerservice@backyard-play.com
Our staff is ready to provide assistance.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4097 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Play Systems 4097

Summary of Contents for Backyard Play Systems 4097

  • Page 1 2690-RR - NOTICE - This playset product is not intended for public use. It is intended for residential application and is not warranted for public or commercial use. STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll-free number: 1-866-890-2211 April through October M - F 8:00 AM to 6:00 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 3 2690-RR 1/16/2015 Customer Service Backyard Play Systems 1-866-890-2211 Model 4097 1000 Ternes Drive Playset Model 6314 Monroe, MI 48162 Recommended for Ages 3 to 11 - BEFORE YOU BEGIN - - BEFORE YOU BEGIN - Adult Assistance required Tools Required First...
  • Page 4 ASSEMBLY SAFETY and HELPFUL HINTS STOP!!! Check all parts and hardware before beginning. If any parts are missing or damaged please circle and call the phone number listed. DO NOT CONTACT THE STORE OR RETURN YOUR PLAYSET ! KEEP THIS INSTALLATION MANUAL FOR FUTURE CARE AND MAINTENANCE REFERENCE.
  • Page 5 SAFETY WARNINGS Please read carefully. Observing the following statements and warnings reduces the likelihood of serious or fatal injury.  This playset has been designed for use by a maximum of eight occupants at one time having a combined weight of 1,200 pounds. (This weight does not include occupants in the sandbox area.) ...
  • Page 6 MAINTENANCE Periodic maintenance is required to ensure safe enjoyment of your playset and optional accessories. Observing the following procedures reduces the likelihood of serious or fatal injury.  Activity on your playset and optional accessories may loosen fasteners. Check all lock nuts, hex and lag bolts, quick clips, spring clips, acorn nuts, wood screws, and swing hangers for tightness and tighten as required.
  • Page 7 PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment.
  • Page 8 PLAYSET ORIENTATION *Hint* Throughout this manual references made to the Left Side, the Right Side, the Front Side and the Back Side of the playset serve as a consistent reminder to help with assembly. LEFT SIDE BACK SIDE FRONT SIDE RIGHT SIDE...
  • Page 9 IMPORTANT! Use these Assembly Procedure Hints throughout the installation process. 1. All Lag Bolts must have pre-drilled holes. Use a 1/4" drill bit for all 3/8" Lag Bolts. Use a 3/16" drill bit for all 5/16" Lag Bolts. Pre-drilling pilot holes will help prevent Screws and Lag Bolts from breaking and wood from splitting during assembly.
  • Page 10 W O O D P A R T S L I S T 5/4 x 4 x 45-1/8" 5/4 x 4 x 45-1/8" 5/8 x 3-1/4 x 10" WOOD SIZE CONVERSION CHART Nominal Board Size Actual Size 1" x 4" ..........3/4" x 3-3/8" ..........
  • Page 11 5/4 x 3-1/2 x 21-1/2" 5/4 x 3-1/2 x 22-1/2" 5/4 x 3-1/2 x 37-1/8" 2373-ST 2375-ST 2374-ST 5/4 x 6 x 47" 1 x 3 x 46-5/8" VIEW X 47000506-ST U 46100208-ST 3/4 x 2 -1/2 x 37-1/8" 2 x 4 x 44" 5/4 x 6 x 23 -1/2"...
  • Page 12 3/8" LOCK NUT 5/16" T - NUT 3/8" T - NUT 3/8” TRUSS HEAD SCREW 3/8" LOCK WASHER 3/8" FLAT WASHER 3/4" 3/8" 3/8" 2-1/2" 1/4" x 1" FENDER WASHER 3/16” x 1” FENDER WASHER PAN HEAD SCREW 1" 1" 2-1/2"...
  • Page 13 3/8” HEX HEAD BOLTS 1-3/4" 2" 2-1/4" 3-3/4" 3/8" 3/8" 3/8" 6" 1-1/4" 1-1/2" 3/8" 3/8" 3/8" #2 SQUARE DRIVE BIT 3/8" LAG BOLT 3/8" LAG BOLT 3/8" WOODSCREWS x111 x14 x252 x105 1-5/8" 1-1/4" 4" 2" 2-1/2" 3" 3" 1"...
  • Page 14 A C T U A L S I Z E S H O W N 3-3/4" 4-1/2" 6-1/2" 9" 3-1/2" 3/8" 3/8" 3/8" TORQUE WASHER 3/8" 3/8" 5/16" 3/8" BUTTON HD. 5/16" SCREW BUTTON HD . SCREW 1-1/2" 1-1/4" 5/16" 5/16"...
  • Page 15 Angle Bracket Plate Swing Beam 90 Plate Swing Beam Angled Plate Left Swing Beam Angled Plate Right 2449 2485 Rock Wall 90 Bracket Flat Metal Bracket 2412 2448 2023 2447 Swing Beam Flat Plate Angle Bracket Slide Swing Hanger 2084 21-1/2"...
  • Page 16 SET-UP SAFETY AREA 30'-8" MONKEY BARS 18'-8" 26'-11" 10'-8" 13’-4" HEIGHT SWINGS SLIDES 13'-4" ROCK WALL LADDER FORT CORNER POSTS 3" Wood Screw 3-3/4" Hex Bolt Lock Washer Flat Washer Note 1 hole location. NOTE: Clean all debris from drill-through holes in Flush 5/4 x 4 x 45-1/8"...
  • Page 17 BASE FORT FLIP ASSEMBLY OVER TO INSTALL BOTTOM BRACE. 3-3/4" Hex Bolt Lock Washer Flat Washer 3" Wood Screws 5/4 x 6 x 45-1/8" 90° 2507-ST Flush Align braces with pre-drilled holes. Ensure all bracing is square before Flush installing wood screws. FORT CORNER POSTS Ensure all bracing is...
  • Page 18 FORT CORNER POSTS 3" Wood Screw 3-3/4" Hex Bolt Note 1 hole location. Lock Washer Flush Flat Washer 5/4 x 4 x 45-1/8" 2501-ST T-Nut Flush 47" 2501-ST 5/4 x 4 x 45-1/8" 90° Flush Note 2 hole 2503-W location. 3 x 3 x 95"...
  • Page 19 FORT FLOOR FRAME Align braces with pre-drilled holes. 3-3/4" Hex Bolt Lock Washer Flat Washer T-Nut FORT FLOOR FRAME Ensure 47" measurement from bottom of base to top of first deck. 3" Wood Screws 47" 47" Reinforce bracing with 3" wood screws at all pre-drilled holes.
  • Page 20 FORT DECK CLEAT 5/4 x 4 x 45-1/8" 2516-ST Flush 2-1/2" Wood Screws Flush FORT DECK PLANKS 5/4 x 6 x 44-7/8" 2509-ST 2-1/2" Wood Screws evenly spaced 1-5/8" Wood Screws Flush...
  • Page 21 FORT DECK PLANKS 5/4 x 4 x 39" 2510-ST 2-1/2" Wood Screws 1-5/8" Wood Screws FORT DECK SUPPORT 2" Wood Screws x4 2 x 4 x 18" through top of 1020-ST 1020-ST. Flush 3" Wood Screws x4 through bottom of 1020-ST. 1020-ST Flush with inside.
  • Page 22 FORT DECK RAILS Mark and drill 1/4" x 2" DEEP pre-drill before installing lag bolts. 5/4 x 4 x 45-1/8" 2501-ST Flat Washer Lock Washer 3" Lag Bolt Bottom flush with Flush at corners. bottom of deck boards. 3" Wood Screws BACK SIDE SWING SIDE SWING BEAM SUPPORT INSTALL...
  • Page 23 METHOD A SWING BEAM SUPPORT T-Nut Small Holes UP SIT ON RAIL 2505-ST 4 x 4 x 45-1/8” Flat Washer Lock Washer BACK SIDE 6” Hex Bolt SWING BEAM METHOD B SWING BEAM SUPPORT 6-1/2" Carriage Bolt Torque Washer 6-1/2" Carriage Bolt Torque Washer Flat Washer Small Holes UP...
  • Page 24 ROOF SUPPORTS FORT 3-3/4" Hex Bolt 5/4 x 4 x 67-11/16" Lock Washer X 67114545-ST Flat Washer T-Nut ROOF RAFTERS Pre-drill 1/8" pilot holes 2" DEEP. Install one 3" wood screw to secure 2579-ST’s. Flush at Peak 3" Wood Screw 2"...
  • Page 25 UPRIGHT SWING BEAM SIDE Center 2539-ST. Mark and Pre drill 7/16" through holes for hex bolt. 1-3/4" Hex Bolt Lock Washer Flat Washer T-Nut 2505-ST BACK SIDE SWING BEAM BACK SIDE SWING BEAM 2539-ST 5/4 x 4 x 47" UPRIGHT SLIDE SIDE Center 2787-ST.
  • Page 26 ROOF TRIM INSTALL DO NOT OVER-TIGHTEN SCREWS. KEEP SCREW HEAD FLUSH WITH TOP OF BOARD. Flush LEVEL Flush Flush Flush 2512-ST 5/8 x 3-1/4 x 35-3/4" 1-5/8" Wood Screws ROOF TRIM INSTALL Center 2513-ST on 2512-ST with mark and secure using two 1-5/8" screws. 5/8 x 3-1/4 x 10"...
  • Page 27 ROOF TRIM INSTALL R OOF/CANOPY Install 2511-ST centered and flush to bottom of 2512-ST using four 1-5/8" screws from inside. Pre-drill 1/8" pilot holes. 1-5/8" Wood Screws Flush 2511-ST DO NOT OVER-TIGHTEN SCREWS. KEEP 5/4 x 6 x 11-3/4" SCREW HEAD FLUSH WITH TOP OF BOARD. Flush ROOF PLANKS INSTALL...
  • Page 28 ROOF PLANKS INSTALL INSTALL Install 3 roof slats on both sides of roof. 2-1/2" Wood Screws BEGIN HERE Install all roof boards Flush. 5/4 x 6 x 47" X 47000506-ST 5/4 x 6 x 47" X 47000506-ST Insert panels fully seated.
  • Page 29 ROOF PLANKS INSTALL Install cleat (U46100208-ST) WARNING! Install screws flush with roof board to avoid protruding below roof. centered under planks on both sides of roof. Install first screws into cleat at bottom plank. 1 x 3 x 46-5/8" U 46100208-ST 1"...
  • Page 30 This space intentionally left blank. ROCK WALL ASSEMBLE Place and align planks parallel on a level surface. We recommend a soft surface to protect planks. *Hint: Number the order of each plank for correct re-orientation, top to bottom. Mark parts on back side or use masking tape. Arrange the Rocks in an attractive and practical fashion.
  • Page 31 ROCK WALL ASSEMBLE Flip each plank over and pound in 1/4” T-Nuts 5/16" (Included in Climbing Rock Bag) at each hole location. (Provided in separate bag) (Provided in separate bag) 2452 x1 BAG Remove Rocks and drill 1/4" holes through all planks. Flip each plank.
  • Page 32 ROCK WALL ASSEMBLE Place Planks 3 through 9 onto Rails, flush to each other. With all Planks flush and snug, Secure Plank 9 ONLY using 4 screws. Maintain dimension shown. - Do not attach any other planks at this time. 23-3/4"...
  • Page 33 ROCK WALL ASSEMBLE 2451 1/4" x 1-1/2" Hex Bolts x1 BAG 1/4" Lock Washers 1/4" Flat Washers T-Nuts Do NOT attach top board at this time. ROCK WALL ASSEMBLE 5/16" T-Nut 5/16 x 1-1/2" Button Head Screw L-Bracket 5/16" Lock Washer 5/16"Flat Washer 2412...
  • Page 34 ROCK WALL INSTALL Flush Place rock wall ladder assembly flush with top of cross brace. Locate right side ladder brace centered on edge of post. Mark bracket holes. LEFT SIDE ROCK WALL INSTALL SEE PAGE 7 LEFT SIDE Rock Wall Pre-drill two 1/4"...
  • Page 35 ROCK WALL INSTALL LEFT SIDE Rock Wall 5/16" T-Nut INSTALL ROCK WALL 5/4 x 4 x 17" Flush 2222-ST Flush 2-1/2" Wood screws...
  • Page 36 ROCK WALL INSTALL 5/16" Flat Washer Secure middle brace with (2) 5/16" Lock Washer 2-1/2" Wood Screws from behind. 5/16 x 1-1/4" Button Head Screw BEGIN HERE 2-1/4" Pan Head screw Flat Washer Flush Flush BEGIN HERE 2-1/4" Pan Flat Washer Head Screw 2514-ST 2"...
  • Page 37 INSTALL FORT BRACING Pre-drill 3/16" pilot hole Re-drill through hole from opposite side using 7/16" bit. Flat Level Washer Lock Flush 5/4 x 4 x 58-1/2" Washer 2538-ST 2-1/4" Hex Bolt Level 2538-ST 5/4 x 4 x 58-1/2" 3" Lag Lock Flat Flush...
  • Page 38 SWING BEAM SWING HANGERS Place Cap on threads Swing Hanger Bolt must protrude at least after tightening 3-1/2 x 5-1/2 x 95" TWO Threads beyond Lock Nut. 2752-W IMPORTANT! 2 Threads MIN. Use a socket wrench to tighten Lock Nut securely against washer.
  • Page 39 A - FRAME ASSEMBLE 3-3/4" Hex Bolt Lock Washer Flat Washer Pre-installed T-Nuts 2506-ST are underneath. 5/4 x 6 x 70-3/4" SWING SWING BEAM 3-1/2" Carriage Bolt 2411 Flat Washer Lock Nut...
  • Page 40 A - FRAME INSTALL 244 9 3-3/4" Carriage Bolt Lock Nut Flat Washer 2525-W SWING BEAM INSTALL 3-1/2 x 5-1/2 x 95" DO NOT FULLY TIGHTEN 2752-W CARRIAGE BOLTS AT THIS TIME. Flat Washer Lock Nut 2448 4-1/2" Carriage Bolt NOTE: You may need to tap bolts with hammer to get though holes.
  • Page 41 SWING BEAM INSTALL Position swing beam assembly resting upon A-frame. SWING A - FRAME Align holes and insert carriage bolt. Repeat where arrows are shown. NOTE: You may need to tap bolts with hammer to get though holes. Clean all debris from bolt threads before installing lock nuts.
  • Page 42 SWING BEAM ASSEMBLY INSTALL 6-1/2" Carriage Bolt Torque Washer You may need to tap with Flat Washer hammer to get though holes. Lock Nut SWING SWING BEAM Position swing beam assembly resting upon plate and align with holes. 9" Carriage Bolt 6-1/2"...
  • Page 43 SWING SWING BEAM SEE PAGE 7 1. Pre-drill using 3/16" bit. 2. Re-drill from opposite side using 7/16" bit. SWING SWING BEAM Flat Washer T-Nut Lock Washer 1-1/4" Hex Bolt...
  • Page 44 SWING LEVEL Level swing beam and tighten all swing beam fasteners. Mark and drill 1/4" x 2" DEEP pre-drill before installing lag bolts. Tighten all fasteners. 3" Lag Bolt Lock Washer Flat Washer SWING A - FRAME 2-1/2" Pan Head Screw 1/4 x 1"...
  • Page 45 BALUSTERS SWING SIDE OF TOWER 3-1/4" 3-1/4" Install first ballusters 1" from 3-1/4" 3-1/4" 3-1/4" 3-1/4" upright 2539-ST and deck. 1-1/4" Wood screws 2523-ST 5/8 x 3-1/4 x 29-3/4" Flush 1" SPACE CANOPY FRAME Flush L E V LEVEL 2375-ST 2501-ST 2375-ST 5/4 x 4 x 22-1/2"...
  • Page 46 CANOPY FRAME 5/4 x 4 x 21-1/2" 2373-ST LEVEL Flush Pre-drill 1/8" pilot hole through (2373-ST) into Flush (2375-ST). 3" Wood Screws CANOPY ASSEMBLE Lay canopy flat and attach to 2474-ST at 37-1/8" Wide bottom, 2565-ST at top as shown. Install x 41"...
  • Page 47 CANOPY INSTALL Install top of canopy flush and centered (as shown in Fig. 1 - Fig. 2) with wood screws spaced evenly through back of upper support into (2565-ST). EQUAL EQUAL 1-1/4" Wood Screws Fig.1 2565-ST Flush to top of rail. Fig.2 2526-ST 2565-ST...
  • Page 48 CANOPY INSTALL Before permanently securing the front rail, the canopy must be installed taut enough so it doesn’t sag. Tautness can be acheived by rotating the front rail (with canopy attached). Follow the steps below. Begin the rotation of Keep rotating ... the front rail like this.
  • Page 49 SWINGS INSTALL Attach a Quick-Clip at the end of each swing and trapeze chain. Attach a Quick-Clip at the end of each swing and trapeze chain. Attach the swings and trapeze to the Quick Clips on the swing Then, using the Quick-Clips, attach the swings and trapeze beam, as shown below.
  • Page 50 CLIMBING ROPE INSTALL OPTIONAL: Tie several single knots in locations to allow logical hand-grab points. Step 1 Feed top of Climbing Rope through front of Upper Rail (2526-ST) and tie a double knot on the back side ( Fig. 1) Step 2 Fig.
  • Page 51 INSTALL STAKES 1015 1 x 1-3/8 x 17" 3" Wood Screws Make sure all base pieces and uprights 3" Wood Screws are resting flat on the ground. It may be necessary to loosen the soil beneath Playset to make everything level. 1015 1 x 1-3/8 x 17"...
  • Page 52 FORT DECK SUPPORT 2" Wood 2 x 4 x 18" Screws x4 1020-ST through top of 1020-ST. Flush 3" Wood Screws x4 through bottom of 1020-ST. 1020-ST Flush with inside. Pre-Drill 1/8" holes through lower ends of 1020-ST. SLIDES INSTALL NOTE: IF SLIDE HAS TWO HOLES, INSTALL SCREWS 2-1/2"...
  • Page 53 SLIDES INSTALL NOTE: IF SLIDE HAS THREE HOLES, INSTALL SCREWS 2" FROM FRONT OF DECK. 2-1/2" Pan Head Wood Screw 1/4 x 1" Fender Washer Locate Slide in the opening between Balusters on the FRONT SIDE of the Tower. Pre-drill 1/8” pilot holes through Slide at dimples, through deck planks, and into lower slide support.
  • Page 54 SANDBOX SEATS INSTALL Pre-drill 1/8" pilot holes. 5/4 x 6 x 22-1/2" 1120-ST 2-1/2" Wood Screws Flush Flush MONKEY BARS OVERVIEW...
  • Page 55 MONKEY BARS TOP LADDER 2-1/2" Pan Head Screw 2759 3 x 3 x 82" 2767-W 1/4" Lock Washer Important measurement! 18-1/2" Ensure holes face downward when installing ladder rungs. Note hole location. MONKEY BARS TOP LADDER / ANGLE BRACKETS 2084 4"...
  • Page 56 MONKEY BARS TOP LADDER / METAL BRACKETS TOP RAIL / METAL BRACKETS FLIP TOP RAIL ASSEMBLY OVER. 2023 No Hex Bolt at end hole. 3/8" Flat Washer 3/8" Lock Washer T-Nut 3" Hex Bolt MONKEY BARS END RAIL TOP RAIL / METAL BRACKETS 3 x 3 x 82"...
  • Page 57 MONKEY BARS TOP LADDER / END RAIL TOP RAIL / METAL BRACKETS Position for assembly. Flush 6" Hex Bolt 2763-ST to inside. 3/8" Flat Washer T-Nut 3/8" Lock Washer 6" Hex Bolt 3" Hex Bolt T-Nut MONKEY BARS INSTALL POSITION * USE CARE WHEN INSTALLING MONKEY BAR ASSEMBLY * TWO PEOPLE AND A STEP LADDER...
  • Page 58 MONKEY BARS INSTALL - STEP 1 Mark 4 drill-holes at brackets. Center Monkey Bar Assembly between corner posts. Align Monkey Bar Assembly flush with top rail. Flush Flush HINT: Clamp Monkey Bars to top rail during installation. RIGHT SIDE MONKEY BARS INSTALL - STEP 2 SEE PAGE 7 Drill-through 3/16"...
  • Page 59 MONKEY BARS INSTALL - STEP 3 Flush at T-Nut top. Flush at top. Flat Washer Lock Washer 1-1/4" Hex Bolt MONKEY BARS ROCK WALL 3" Wood Screw Flush to back of post. Flush 2 x 4 x 44" 2766-ST 25-3/16"...
  • Page 60 ROCK WALL PLANKS MONKEY BARS Place and align planks parallel on a level surface. We recommend a soft surface to protect planks. *Hint: Number the order of each plank for correct re-orientation, top to bottom. Mark parts on back side or use masking tape. Arrange ALL Rocks in an attractive and practical fashion.
  • Page 61 MONKEY BARS ROCK WALL PLANKS Flip each plank over again and install rocks using fasteners (provided in separate bag) to T-Nuts as shown. Keep planks in order. 1/4 x 1-1/2" Hex Bolt Flip each plank. 1/4" Lock Washer 1/4" Flat Washer T-Nuts MONKEY BARS ROCK WALL...
  • Page 62 MONKEY BARS ROCK WALL Pre-drill 1/8" through- holes at all screw locations. 1-1/4" RECOMMENDED 3" Wood Screws - INSIDE - 1-5/8" Wood Screws - INSTALL LAST - - INSTALL FIRST - Pre-drill 1/8" Flush to edge of plank. 2765-ST 5/8 x 3 -1/4 x 25-1/4" Angled screw-pattern.
  • Page 63 MONKEY BARS ROCK WALL Match height at top of both parts 2763-ST 2763-ST before installing. L E V Flush 3" Wood Screws 2763-ST Measure and mark 5/4 x 4 x 29-3/4" each side equally. LEVEL MONKEY BARS ROCK WALL STEP Equal overhang at 5/4 x 6 x 23-1/2"...
  • Page 64 MONKEY BARS ROPE BRACE 2 x 4 x 29-3/4" 2762-ST Flush 3" Wood Screws Flush Flush MONKEY BARS BALUSTERS Install balusters flush to Monkey Bar L-Brackets. Flush to bracket. 5/8 x 3-1/4 x 33" 2537-ST 1-1/4" Wood Screws 1-1/4" 1-1/4" RIGHT SIDE...
  • Page 65 MONKEY BARS TIC TAC TOE TOP VIEW Pre-drill 1/8" through hole 5/4 x 4 x 31-3/4" through 2537-ST at each 2768-ST screw location. 2537-ST 3" 2768-ST Install 1-1/4" Wood Screws through 2537-ST LEVEL into 2768-ST from inside Clamp during 23-1/2" Playset.
  • Page 66 MONKEY BARS TIC TAC TOE Flush at top. CENTER CENTER Install 1-1/4" Wood Screws through 2581-ST into 2768-ST from inside 5/8 x 3-1/4 x 23" Playset. 2581-ST TOP VIEW 2768-ST 2581-ST 1-1/4" Wood Screws Do not over drive screws. INSIDE PLAYSET MONKEY BARS CLIMBING ROPE Step 1...
  • Page 67 MONKEY BARS CLIMBING ROPE OPTIONAL: Tie several single knots in locations to allow logical hand-grab points. Step 2 Feed lower end of Climbing Rope through hole in bottom Rock Wall board (2527-ST) and tie a double knot on the back side (Fig.
  • Page 68 MONKEY BARS HAND LOOPS Step 1 Insert eyebolt into pre-drilled hole on underside of top rail. Tighten until no threads are visible. Use a screwdriver to help turn eyebolt. Top Rail Turn eyebolt so it is perpendicular with the top rail (Fig. 1). PERPENDICULAR Top Rail Fig.1...
  • Page 69 MONKEY BARS HAND LOOPS Step 4 Install seven more hand loops by following STEPS 1 through 3 as previously shown. 2624 Hand Loop MONKEY BARS STAKES Pound in stakes so they are flush at top. 1 x 1-3/8 x 17" 3"...
  • Page 70 SAFETY HANDLES INSTALL Flat Washer 1-1/2" Lag Bolt 2405 DO NOT OVER-TIGHTEN LAG BOLTS STEERING WHEEL INSTALL Install 2008-ST inside fort. Flat Washer 1-1/2" Lag Bolt DO NOT OVER-TIGHTEN LAG BOLTS. Steering Wheel Cap 2008-A...
  • Page 71 TELESCOPE INSTALL 1-1/4" Screws Telescope 2073 Telescope Bracket Any Top Rail...
  • Page 72 Systems. Labor warranty does NOT apply to Do-It-Yourself playset kits or kits installed by a third party. Backyard Play Systems will repair, replace or pay for the affected part at our discretion. In no event shall Backyard Play Systems pay the cost of labor or installation or any other costs related thereto.
  • Page 73 Backyard Play Systems does not assume, or authorize any person to assume for us, any other liability in connection with the sale of our products.

This manual is also suitable for:

6314
