Product Owner's Manual
UM Ultrasonic Tee Flowmeter
1", 1-1/2", 2", 3", & 4" Socket
06/2024
Find Quality Products Online at:
NSF
1", 1-1/2", 2", 3", & 4" FNPT
1", 1-1/2", & 2" FBSPT
3" & 4" ANSI Flange
GlobalTestSupply
www.
UM Ultrasonic Tee Flowmeter with Socket Fittings
and Electronic Option QUDSBAN1 Shown.
Versions:
3" & 4" DIN Flange
.com
EN
920901-06 Rev E
sales@GlobalTestSupply.com
Advertisement
Table of Contents
Related Manuals for Flomec UM Series
Summary of Contents for Flomec UM Series
- Page 1 Product Owner’s Manual UM Ultrasonic Tee Flowmeter with Socket Fittings and Electronic Option QUDSBAN1 Shown. UM Ultrasonic Tee Flowmeter Versions: 1”, 1-1/2”, 2”, 3”, & 4” Socket 1”, 1-1/2”, 2”, 3”, & 4” FNPT 1”, 1-1/2”, & 2” FBSPT 3” & 4” ANSI Flange 3”...
- Page 2 Please save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage. Please refer to back cover for information regarding this product’s warranty and other important information.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Getting Started ---------------------------------------------- 4 General Safety Instructions ------------------------------ 5 Using the UM Manuals ------------------------------------ 5 General -------------------------------------------------------- 6 Specifications ------------------------------------------------ 6 Socket Fitting Meters --------------------------------- 8 NPT Fitting Meters ------------------------------------ 9 BSPT Fitting Meters -------------------------------- 10 ANSI Flange Meters -------------------------------- 11 DIN Flange Meters ---------------------------------- 12 K-Factor Chart ---------------------------------------- 13 Installation -------------------------------------------------- 14... -
Page 4: Before You Begin
BEFORE YOU BEGIN Usage Requirements This flowmeter is for use with water only. • This flowmeter is not legal for trade applications. • This flowmeter has a permanent factory setting for measuring water • only. Flow must go uphill through the flowmeter, never downhill through the •... -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS IMPORTANT: It is your responsibility to: Ensure that all equipment operators have access to adequate instructions • concerning safe operating and maintenance procedures. This product is not approved for use with petroleum products (diesel fuel, unleaded gasoline, jet fuel, kerosene, etc.), aromatic hydrocarbons or other incompatible chemicals. -
Page 6: General
GENERAL The FLOMEC® Ultrasonic Tee meter consists of a tee housing, specially designed to accept the FLOMEC Ultrasonic Electronics package. The electronics package consists of the ultrasonic insert, the electronics module, and the Q9 computer display. Ultrasonic Insert: The ultrasonic insert locates inside the tee locked in place with the quick release pin. - Page 7 SPECIFICATIONS – Common (Continued) Pressure vs Temperature Graph GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 8: Socket Fitting Meters
SPECIFICATIONS - Socket Fitting Meters Model UM025SK UM040SK UM050SK UM080SK UM100SK Size 1 Inch 1-1/2 Inch 2 Inch 3 Inch 4 Inch Inlet / Outlet 1 in. Socket 1 1/2 in. Socket 2 in. Socket 3 in. Socket 4 in. Socket Connections Tee Housing 1.45 lbs. -
Page 9: Npt Fitting Meters
SPECIFICATIONS – NPT Fitting Meters Model UM025NF UM040NF UM050NF UM080NF UM100NF Size 1 Inch 1-1/2 Inch 2 Inch 3 Inch 4 Inch Inlet / Outlet 1 in. NPT 1 1/2 in. NPT 2 in. NPT 3 in. NPT 4 in. NPT Connections Female Female... -
Page 10: Bspt Fitting Meters
SPECIFICATIONS – BSPT Fitting Meters Model UM025TF UM040TF UM050TF Size 1 Inch 1-1/2 Inch 2 Inch Inlet / Outlet 1 in. BSPT 1 1/2 in. BSPT 2 in. BSPT Connections Female Female Female Tee Housing 1.65 lbs. 1.96 lbs. 2.13 lbs. Weight (0.75kg) (0.89kg) -
Page 11: Ansi Flange Meters
SPECIFICATIONS – ANSI Flange meters Model UM080FA UM100FA Size 3 Inch 4 Inch Inlet / Outlet 3 in. ANSI 4 in. ANSI Connections Flange Flange Tee Housing 7.77 lbs. 11.08 lbs. Weight (3.52kg) (5.03kg) Dimensions Model UM080FA UM100FA Size 3 Inch 4 Inch 13.38 in. -
Page 12: Din Flange Meters
SPECIFICATIONS – DIN Flange Meters Model UM080FD UM100FD Size 3 Inch 4 Inch Inlet / Outlet 3 in. DIN 4 in. DIN Connections Flange Flange Tee Housing 8.19 lbs. 10.24 lbs. Weight (3.71kg) (4.64kg) Dimensions Model UM080FD UM100FD Size 3 Inch 4 Inch 13.38 in. -
Page 13: K-Factor Chart
K-Factor Information NOTE: The meter size is molded on the vertical stem of the Tee. FLOMEC ultrasonic flowmeters use typical K-Factor values specific to the adjoining pipe used in the application for greatest accuracy during calibration. These values are derived by calibrating the meters using NIST traceable instrumentation. -
Page 14: Installation
INSTALLATION Typical UM Tee meter (Tee with ultrasonic electronics) shown below Figure 2 (UM050SK shown) GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 15 INSTALLATION (Continued) NOTE: Allow room above the insert for the electronic module and computer display (see Specifications for dimensions). UM ultrasonic meters should be installed with straight runs of pipe equal to 10 pipe diameters upstream, and 5 times the pipe diameter downstream to prevent turbulence that can decrease the meter’s accuracy.
-
Page 16: Connections - Socket Fitting Meters
INSTALLATION (Continued) Socket Fitting Meters - Connections Remove all burrs from the O.D. and I.D. edges of the pipe ends, and the I.D. edges of the Tee sockets (see Figure 4). Clean and apply primer to the pipe ends and Tee sockets (see Figure 5) Apply PVC cement to pipe ends and Tee sockets and quickly assemble the parts while the cement is fluid, following the cement manufacturer’s instructions (see Figure 6). -
Page 17: Connections - Npt/Bspt Fitting Meters
INSTALLATION (Continued) NPT and BSPT Fitting Meters - Connections Installation to metal connections is not recommended. Seal all pipe threads with an appropriate non-lubricated thread sealant (such as Loctite® No More Leaks™ Plastic Pipe Thread Sealant or NSF equivalent for NSF applications). -
Page 18: Troubleshooting
Do not install within 20 pipe diameters downstream of pressure regulation equipment. These devices cause any entrained air in the line to expand, and could cause your FLOMEC Ultrasonic Meter to become inaccurate. The faces of the transducers need to be clean and free of oily substances for accurate operation. -
Page 19: Repair, Repair Parts List
REPAIR There are no repairs that can be made to the Tee housing. Replacement Tee housings are available as replacement parts. See the specific section of the Ultrasonic Electronics Manual for available repair parts for the ultrasonic insert, electronic module, and computer display. REPAIR PARTS LIST Model No. -
Page 20: Parts & Service
NOTES: ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... - Page 21 NOTES: ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 22 NOTES: ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
