Fountain Components
Item Description
Onda Fountain
- Water Feature
Onda Fountain
- Large Disc
Onda Fountain
- Pump House
Onda Fountain
- Basin
Fountain Information:
• Two people are recommended for the installation of this fountain!
• This fountain holds approximately 25-30 gallons of water.
• This fountain uses a large fountain cover: FTNCOV-LG
• Compatible with #10 Refill Device
• A special stopper is required to use the refill kit for this fountain
Pump Information:
OEMPP800 - 800 GPH Pump (16 ft. cord length)
Tools Required:
Bubble Level
Screwdriver
Component
Quantity
Item #
FT-429A
1
FT-429AA
1
FT-429B
1
FT-429C
1
FT-429 Onda Fountain
Assembly Instructions
Pump Kit Parts List
3/4" Socket to 1/2" Threaded Sch 40
PVC Adapter
#10 Stopper
3" length of 3/4" PVC pipe (P)
25" length of 11/2" black non-kink tubing
3" length of 1" CPVC pipe (W)
Hose Clamps (large)
Proudly
MADE IN USA
Component
Quantity
PK800
Drain-7
Wedges
rev 07/26/2024
1
1
1
1
1
1
1
2
2
Advertisement
Related Manuals for YARDART Onda FT-429
Summary of Contents for YARDART Onda FT-429
- Page 1 FT-429 Onda Fountain Assembly Instructions Fountain Information: • Two people are recommended for the installation of this fountain! • This fountain holds approximately 25-30 gallons of water. • This fountain uses a large fountain cover: FTNCOV-LG • Compatible with #10 Refill Device •...
- Page 2 FT-429 Onda Fountain Assembly Instructions Two people are recommended for the installation of this fountain! Fountain Set-Up: Assembly & Installation - A fountain can be difficult to install without knowing and understanding the steps involved. To ensure your fountain is installed properly, please read our instructions and tips before you begin.
- Page 3 FT-429 Onda Fountain Assembly Instructions Step 8 - Center the top plate (FT-429AA) on the pump house (FT-429B) ensuring that it is level. FT-429AA (129 lbs) 34.25"W x 2.25"H Step 9 - Insert the 1" CPVC end (W) of the preassembled tubing into the PVC coupling in the bot- tom of the water feature (FT-429A).
- Page 4 Maintenance: Pump Care - The fountain relies heavily on the quality of the pump. A well-maintained pump can last several years. Step 1 - Fully submerge: Ensure the pump is fully submerged at all times to avoid damage. Step 2 - Ensure water level is sufficient: Check water levels regularly as water may evaporate over time, and periodically change water to avoid algae buildup.
