LCD Setting

After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press "UP" or "DOWN"
button to select setting programs. And then, press "ENTER" button to confirm the selection or ESC button to
exit.
Setting Programs:
Program Description
00 Exit setting mode
Output source priority:
01 To configure load power
source priority
Maximum charging current:
To configure total charging
current for solar and utility
02 chargers.
(Max. charging current =
utility charging current +
solar charging current)
03 AC input voltage range
05 Battery type
Selectable option
Escape
Utility first (default)
Solar first
SBU priority
60A (default)
Appliances (default)
UPS
AGM (default)
15
Utility will provide power to the
loads as first priority.
Solar and battery energy will
provide power to the loads only
when utility power is not available.
Solar energy provides power to the
loads as first priority.
If solar energy is not sufficient to
power all connected loads, Utility
energy will supply power to the
loads at the same time.
Solar energy provides power to the
loads as first priority.
If solar energy is not sufficient to
power all connected loads, battery
energy will supply power to the
loads at the same time.
Utility provides power to the loads
only when battery voltage drops to
either low-level warning voltage or
the setting point in program 12.
Setting range is from 10A to 120A.
Increment of each click is 10A.
If selected, acceptable AC input
voltage range will be within
90-280VAC.
If selected, acceptable AC input
voltage range will be within
170-280VAC.
Flooded
