- Page 1 Hybrid PV Inverter SP 5000Vitality-S...
- Page 2 (This page is intended to be blank)
-
Page 3: Table Of Contents
Table of Contents Safety Precautions ................ 4 Contact Information ..............6 Warranty Information ..............7 Hybrid PV System ................. 8 Principles of Operation ..............9 Functions ............................9 On-grid Power Manager ......................9 Off-grid Power Supply ....................... 9 Charge/Discharge Controller ....................9 UPS .............................. - Page 4 Add EMI core near AC panel on mains wires ..............25 Connecting Generator ........................ 25 Control Your Generator ......................26 Connecting Battery Bank(s) ....................27 Preparing Wires and Connectors for Battery ............... 27 Connecting Batteries ......................28 Connecting Battery Sensor ....................29 Connecting RS485 ........................
- Page 5 Setting Frame ..........................46 Error Frame ..........................46 Version Frame ........................... 47 Voltage Frame ........................... 47 Event Frame ..........................47 Monitoring SP VITALITY-S ....................... 48 Using USB ............................49 Download Data to USB stick ....................49 Firmware Upgrade ........................49 Capacity of Memory ........................
-
Page 6: Safety Precautions
Safety Precautions Refer to the Operating Manual There are information of caution, operation and installation, please read and keep this manual. Caution: Risk of Electric Shock Alternating Current (AC) and Direct Current (DC) sources are connected to this device. To prevent risk of electric shock during maintenance or installation, please ensure that all AC and DC connections are disconnected. - Page 7 Caution Must be installed by a competent person Caution Do not stay permanently at a distance of less than 30 cm to this converter. Device generates electromagnetic radiation could be harmful in such a close range. Do not Connect Generator in 0n-grid Mode In this mode, SP VITALITY-S inject power into AC mains, only grid can be connected to AC mains.
-
Page 8: Contact Information
Contact Information OPTI SOLAR Corporation http://www.opti-solar.com/index.html info@opti-solar.com... -
Page 9: Warranty Information
Warranty Information Warranty or liability will be void if damage caused by any, but not limited to the followings: 1. Unauthorized opening of the unit 2. Installation faults such as improper environment, wiring and application 3. Working conditions beyond the unit specifications 4. -
Page 10: Hybrid Pv System
Hybrid PV System Glossary 1. Hybrid/Off-grid PV Inverter: Manager of PV inputs, charging, discharging and load supplying functions 2. PV panels: Receive sunlight and convert it into electricity 3. Battery Bank: Stores energy from mains and PV inputs 4. Protected Loads: Appliances & devices take AC power from SP VITALITY-S, especially in blackout 5. -
Page 11: Principles Of Operation
Principles of Operation Functions The Hybrid PV system is an intelligent and automatic power manager, it can be On-grid Power Manager In places with grid (utility), SP VITALITY-S can manage the power from PV, grid and battery. For protected loads connected to SP VITALITY-S, during blackout, SP VITALITY-S can supply power to them from PV and/or batteries. -
Page 12: On-Grid Mode- Net Metering
MPPT Grid or Generator CHG/DisCHG This application is suitable for Blackout With utility, but user DO NOT want to use utility or use utility as a backup source In this mode, inverter output is physically separated from grid, therefore, no power can be injected to grid. -
Page 13: On-Grid Mode- Self Using
MPPT CHG/DisCHG This application is suitable for Surplus PV power can be feed to grid and paid. On-grid mode- Self Using In some applications, e.g. grid is weak or feeding grid is not beneficial, surplus power feeding is not encouraged; the PV power is used by their own. This is “Self Using”. -
Page 14: Power Priority
During the night or when no power from PV, inverter will take power from battery to supply ALL the power demands from “Protected Loads”. To do this, you have to enable the “BAT-> Load” and disable function in settings menu. BAT ->... -
Page 15: To Battery (Charging)
To Battery (Charging) The power charged to batteries from different sources follows the priorities: PV -> Mains (AC) -
Page 16: Product Overview
Product Overview Outline & Dimensions Status LED Operation Keys Display LCD Manual on/off USB port Switch RS485 port BAT Sensor Connector AC mains AC Load PV1 & PV2 inputs DC Switch CAN BUS port Generator Battery Cables (Optional) (for multiple Remote Control units operation) -
Page 17: Label
Label For models with DC switches, there will be “/s” after the model names... -
Page 18: Installation
Installation Inside the Package Item Description Inverter Mounting bracket, fix plates and screws User manual Plastic anchor & screws x 4,used to fix bracket on wall RS485 connector/plug & CANbus connection cable Battery temperature sensor Spared AC Fuse x 1 (30A/250V) Bead for RS485 cable EMI core for mains cable... -
Page 19: Assembly Chart
Assembly Chart... -
Page 20: Choosing Proper Location
Choosing Proper Location Do not expose the SP VITALITY-S to sunlight, rain or water. Sunlight Rain or Water Install SP VITALITY-S at visible level so you can see its status. Fix SP VITALITY-S on a solid, surface Mounting Properly Direction Mount the SP VITALITY-S in vertical direction;... -
Page 21: Keeping Clearance
Keeping Clearance Reserve at least 50 cm distance between SP VITALITY-S’s. Keep distance for the airflow to dissipate heat. Mounting Procedure Dimension of Bracket The bracket is used to support SP VITALITY-S on the wall. Before fixing it, refer to drilling locations and dimensions below. -
Page 22: Mounting Bracket
Mounting Bracket Place the bracket in place you choose. Drill at the correct positions, and fix bracket with the screws in the accessories. Attaching SP VITALITY-S 1. Lift SP VITALITY-S slightly higher than bracket; Make sure all fixing points on back are at right positions 2. -
Page 23: Wire Connections- Single Unit
2. Check all supporting points; make sure they are in their right positions 3. Lock caps are fixed with screws 4. Make sure SP VITALITY-S is well installed and fixed on the wall Wire Connections- Single Unit System Diagram Off-grid Operation... -
Page 24: Connection Area
On-grid Operation Connection Area 1. Battery Cables (Negative & Positive) 2. Battery Temperature Sensor wires and socket... -
Page 25: Connecting Ac Mains
3. PV1 & PV2 inputs 4. DC SIWTCH (Optional) 5. RS485 connector, for monitoring and communication 6. CANbus port: Connected for multiple units operation 7. Cable gland for Generator remote control 8. AC Mains input 9. AC Loads output Connecting AC Mains 1. -
Page 26: Connecting Ac Loads
Protected Earth (PE) Conductor Requirement The cross section of the conductor shall not be less than Torque Information The torque for AC terminal is 0.6~0.8 Nm (Newton-meter). Connecting AC Loads 1. Prepare similar wires as AC mains 2. Repeat steps as AC mains connection 3. -
Page 27: Add Emi Core Near Ac Panel On Mains Wires
Add EMI core near AC panel on mains wires To meet EMI requirements, please add EMI core as below: Take EMI core in accessory I Insert L(ine) and N(eutral) wires into core for 4-turns as indicated in below figure The core should nears AC panel and breaker as near as possible Breaker in AC panel Line Neutral... -
Page 28: Control Your Generator
Only one AC power source can be connected You can EITHER connect grid OR generator only. These 2 sources cannot be connected to SP Vitality-S in the same time. Do not connect generator for on-grid operation This could damage the generator by inverter feed-in. Control Your Generator If your generator is equipped with remote start/control function, you can connect a wire to “Generator Remote Control”... -
Page 29: Connecting Battery Bank(S)
Controlling your Generator To turn on/off your generator, your generator also needs to have remote on/off connectors (terminals). Please refer to the specifications and manual of the generator. Connecting Battery Bank(s) The voltage of battery bank is 48V . The recommended numbers of battery packs are 1~5. -
Page 30: Connecting Batteries
BAT breaker fuse Connecting Batteries To connect battery, please follow the steps below. Pay attention and follow the instruction of warning label on the unit Prepare wires AWG 2 Crimp (+) and (-) wires with ring terminals Watch out the polarities Fix wires on both sides of DC breaker/switch Protect and hide all the cables in conduits Use battery terminal covers on all battery... -
Page 31: Connecting Battery Sensor
Battery sensor (Accessory F) Protection cover From BAT breaker 48V Battery bank Watch out polarities Reverse connections of positive (+) and negative (-) will damage the unit. Incorrect wiring is not covered by warranty. Way to Correct improper battery polarities If the battery polarity is reverse, switching on the battery breaker will cause internal fuse broken. -
Page 32: Connection
Connecting to device or computer with RS485 interface There are some points highlighted. All wires between devices and computer shall be twisted Maximum allowable wire length is 1000 meters The terminal-end device may need a terminal resistor Due to multiple connections, each individual device should be assigned an address so as to recognize by computer or device Connection The RS485 port is located beneath the inverter as below:... -
Page 33: Setting Address
RS485 RS485 RS485 RS485 To monitor device Unit 1 Unit 2 …… Terminal Unit The DIP switch is the terminal resistor switch of the RS485. The default position of this switch is “off”. However, if the communication does not work well, please try to switch it to “on”... -
Page 34: Wire Connections- Multiple Units
Wire Connections- Multiple Units System Diagram To build a bigger system with multiple units, you can build the system according to below figure. AC mains Grid or Panel & Generator breakers Battery Up to 6 units AC load Breaker Loads Common Battery Bank Use Common Battery Bank... - Page 35 …… Be Sure to Connect CANbus Cable The CANbus cable between inverters is used to control and synchronize the inverter operations. You must connect them for proper operating. Extend the CANbus cable Length If the cable is not long enough, please extend the cable length by similar wires.
-
Page 36: Ready To Start
Ready to Start Check List Before starting the system, check following items: Item Point of check Checked? Mounting SP VITALITY-S is firmly mounted on the bracket 2 lock caps are secured All wires are firmly fixed on terminals ... -
Page 37: Start-Up Procedure
Start-up Procedure Start Check List & Settings? Switch on BAT then PV Switch on main AC breaker. Wait for 30 seconds Switch off AC; check AC LCD turns connections Initial Setup Refer to trouble Fault? shooting and correct Check RS485 RS485 connection... -
Page 38: Operation
Operation Display and Keys Display Status LED Text display Operation Keys 1. Status LED: There are 2 LED’s to indicate SP VITALITY-S status. In normal condition, green one turns on; in abnormal or warning conditions, red one turns on 2. Text display: 2 lines, showing status, data and instructions Operation keys Function Note... -
Page 39: Settings
Settings Will not appear for off- grid models Initial Settings I ni t i a l SETTI NGS Setting Flow TAP [ t o St a r t SYSTEM CONNCTI ON Si ngl e Si ngl e TAP [ t o Ent e r SET M ODE Ne t M e t e r i ng BAT- >Loa d:... -
Page 40: System Connection
You need to set inverters after first installation so as to have proper operation in the future. After switching on SP VITALITY-S of the first installation, the initial setting frame comes out automatically. The chart is indicated. Flow of Initial Settings Initial Settings is a “one-way”... -
Page 41: Buzzer Configuration
Make sure clock is correct Incorrect clock causes improper operations. Make sure SP Vitality’s clock is correct all the time. Time of keeping clock setting after losing power In case switching off SP Vitality for more than 5 days, the internal clock setting will lose and change back to the default settings. -
Page 42: Battery Configuration
Battery Configuration This text shows the battery type and its string number. The available selections are: Generic: It is for general type of Lead-acid battery. If you are using types other than official ones, please select this type YUASA NPA100-12I CHLORIDE12CDC100 Panasonic LC-T12105x 3K EBB100... -
Page 43: Mains Charging Battery
Mains Charging Battery This item is to set whether inverter will use AC mains to charge battery or not. In some applications, you may need AC mains (Grid or Generator) to charge the battery bank when PV power is not enough and battery capacity is low. Select “Enable”... -
Page 44: Factory Setting
SETTI NGS Up/Down Keys Enter Enter/Escape TAP [ 3 t i me s SYSTEM CONNCTI ON Si ngl e Si ngl e TAP [ t o Ent e r SET M ODE Ne t M e t e r i ng BAT- >Loa d: Ne t M e t e r i ng TAP [... -
Page 45: Manual On/Off
Manual ON/OFF The manual ON/OFF switch is on the right side as figure. This switch is used to turn on/off inverter manually. There are some situations: AC presents: turning off inverter switches load to AC mains No AC input: In case battery capacity is enough, push the button to start inverter Inverter... -
Page 46: Lcd Frames
LCD Frames Frame Chart Inverter Starts BOOT Ve r 1. 0 Up/Down Keys 03/ DEC/ 14 09: 35 Loc a l Loa d 1250W BAT Cha r gi ng F/ W Ve r s i on 03/ DEC/ 14 09: 35 BAT Le ve l M EDI UM 01. -
Page 47: Power Frame 1
Warning Refer to warning On warning or error happening, message Inverter shows the warning messages Error Refer to error On error happening, SP message VITALITY-S shows the error messages Manual Off Manual off. Manual Off, Push On/Off to Load will continuously be turn on supplied by AC mains if it exists. -
Page 48: Battery Frame
MEtoday XXXkWh Mains Energy supplied of the day in total. If “- “ appears in front of XXXkWh, it means feed-in energy is more than consuming. Battery Frame Showing battery status. Display Description Battery status. “Charging”, Charging “Discharging”, ”Standby” or “Disconnected” BAT Level Battery capacity level. -
Page 49: Version Frame
Total Errors can be logged The total errors can be recorded are 50. For error large than 50, latest one will replace earliest one. If you like to view the error type, please tap ENTER and using UP and DOWN keys to see the detail. -
Page 50: Monitoring Sp Vitality-S
AC frequency is less Silent AC FREQ LOW fac XX.X Hz than lower limit PV is higher than upper Cont. PV VOLT HIGH Vpv XXX V limit Battery voltage is Cont. BAT VOLT HIGH Vbat XX.X V higher than upper limit Output is overloaded Cont. -
Page 51: Using Usb
Using USB Download Data to USB stick You can plug in a pre-formatted USB stick into USB port to download the operation data. The stick must be FAT or FAT32 formatted. To do this, plug in a USB stick. LCD will show “Download Data Processing”. - Page 52 Backup Data Periodically Once data in the logger has been deleted, it cannot be recovered. Therefore it’s recommended to backup the data periodically if you wish to retain this information.
-
Page 53: Trouble Shooting
Trouble Shooting In case SP VITALITY-S detects any problem, it will behave as the situations in table below. Please follow the instruction to solve the problem. If the problem continues, please contact your local service for further assistance. Trouble Treatment 1. - Page 54 Check the insulation between PV+ (or PV-) and GND If error continues, please contact with your local service If you find this in initial installation, please check AC mains and Load connection AC load is to be connected to load, NOT X4 appears AC main If error continues, please contact with your...
- Page 55 wattage is small. In this case, please correct or replace such kinds of loads Caution of Adjusting Operation Parameters This may violate local grid-tie regulation. Please ask your qualified technical support to do this ONLY!
-
Page 56: Maintenance
Maintenance Regular maintenance For best results, please follow below points: 1. Keep proper distance from other obstacles. Make sure air-flow and heat dissipation path is cleared 2. Clean up any dust on this unit, especially on the ventilation holes 3. Check operation and status if possible 4. -
Page 57: Replacing Ac Fuse
2. Remove screws, open fan cover 3. Remove screws of fan 4. Take fan out 5. Unplug fan connector 6. Replace new fan supplied by authorized dealer 7. Close and fix this cover again with screws Replacing AC Fuse For some abnormal situations such as over load on AC out, the AC fuse may be broken. -
Page 58: Appendix
Appendix Specifications Model Unit SP5000 Vitality Item Input (Mains, AC) Nominal Voltage 190 ~ 300 Voltage Range Nominal 50/60 Frequency 0.99 Power Factor Maximum Current Inrush Current A/μS 100/200 Max. Power 5500 Input (PV, DC) Maximum Power 5000 Maximum Voltage MPPT Range 100~450 Start-up Voltage... - Page 59 Model Unit SP5000 Vitality Item Max. Power 5000 Inrush Current A/μS 100/200 Max. Fault Current Max. Protection Over-current Nominal Voltage Nom. Frequency 50/60 THDV Voltage Regulation DC injection ±100 60 seconds for 100% ≤ load ≤ 110% Overload Capacity 30 seconds for 110% < load ≤ 150% 10 seconds for 150% <...
-
Page 60: Battery Charging/Discharging
Model Unit SP5000 Vitality Item Max. Units for Parallel Operation Mechanical W x H x D 580 x 408 x 168 Weight 23.8 DC switch Optional Battery Capacity 48Vdc, 100Ah/12V x 4 per bank Official Type Refer to table below Note: Specifications are subject to change without prior notice There are some variations for each model. -
Page 61: Charging/Discharging Parameters
Float stage: Constant voltage charging with lower voltage Charging/Discharging Parameters Buck Absorption Cut-off Type Charging Float Voltage Voltage Voltage Current 14.1 13.7 10.8 14.1 13.7 10.8 14.1 13.7 10.8 14.1 13.7 10.8 ≥500 14.1 13.7 10.8 14.5 13.7 10.2 14.5 13.7 10.2 14.5... - Page 62 (This page is intended to be blank...
