User Manual
Solar Hybrid Inverter
SP7000 Handy Ultra
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP7000 Handy Ultra and is the answer not in the manual?

Questions and answers

Related Manuals for opti-solar SP7000 Handy Ultra

Summary of Contents for opti-solar SP7000 Handy Ultra

  • Page 1 User Manual Solar Hybrid Inverter SP7000 Handy Ultra Version: 1.0...

  • Page 2: Table Of Contents

    Table of Contents ABOUT THIS MANUAL ........................1 Purpose ..............................1 Scope ..............................1 SAFETY INSTRUCTIONS ........................1 INTRODUCTION ..........................2 Features ............................... 2 Basic System Architecture ........................3 Product Overview ..........................4 INSTALLATION ..........................5 Unpacking and Inspection ........................5 Preparation ............................

  • Page 3: About This Manual

    ABOUT THIS MANUAL Purpose This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read this manual carefully before installations and operations. Keep this manual for future reference. Scope This manual provides safety and installation guidelines as well as information on tools and wiring. SAFETY INSTRUCTIONS WARNING: This chapter contains important safety and operating instructions.

  • Page 4: Introduction

    INTRODUCTION This is a multi-function inverter, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support in a single package. The comprehensive LCD display offers user-configurable and easy-accessible button operations such as battery charging current, AC or solar charging priority, and acceptable input voltage based on different applications.

  • Page 5: Basic System Architecture

    Basic System Architecture The following illustration shows basic application for this unit. It also required the following devices to have a complete running system: Generator or Utility mains. PV modules Consult with your system integrator for other possible system architectures depending on your requirements. This inverter can power various appliances in home or office environment, including motor-type appliances such as tube light, fan, refrigerator and air conditioners.

  • Page 6: Product Overview

    Product Overview SP7000 Handy Ultra Appendix I. NOTE: For parallel model installation and operation, please check LCD display Status indicator Charging indicator Fault indicator Function buttons Power on/off switch AC input connectors AC output connectors (Load connection) PV connectors 10. Battery connectors 11.

  • Page 7: Installation

    INSTALLATION Unpacking and Inspection Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items inside of package: Inverter unit Manual RS-232 cable Parallel communication cable Current sharing cable Preparation Before connecting all wirings, please take off bottom cover by removing two screws.

  • Page 8: Battery Connection

    Wire Size Dimensions Amperage capacity value D (mm) L (mm) SP7000 Handy Ultra 167A 250AH 1*1/0AWG 39.2 5 Nm Please follow below steps to implement battery connection: 1. Assemble battery ring terminal based on recommended battery cable and terminal size.

  • Page 9: Ac Input/Output Connection

    Suggested cable requirement for AC wires Model Gauge Torque Value SP7000 Handy Ultra 8 AWG 1.4~ 1.6Nm Please follow below steps to implement AC input/output connection: 1. Before making AC input/output connection, be sure to open DC protector or disconnector first.

  • Page 10: Pv Connection

    5. Make sure the wires are securely connected. CAUTION: Important Be sure to connect AC wires with correct polarity. If L and N wires are connected reversely, it may cause utility short-circuited when these inverters are worked in parallel operation. CAUTION: Appliances such as air conditioner are required at least 2~3 minutes to restart because it’s required to have enough time to balance refrigerant gas inside of circuits.
  • Page 11 Prepare the cable and follow the connector assembly process: Strip one cable 8 mm on both end sides and be careful NOT to nick conductors. Insert striped cable into female terminal and crimp female terminal as shown below. Insert assembled cable into female connector housing as shown below. Insert striped cable into male terminal and crimp male terminal as shown below.
  • Page 12 1. Open circuit Voltage (Voc) of PV modules not to exceeds maximum PV array open circuit voltage of the inverter. 2. Open circuit Voltage (Voc) of PV modules should be higher than the start-up voltage. SP7000 Handy Ultra INVERTER MODEL 8000W Max.

  • Page 13: Final Assembly

    Final Assembly After connecting all wirings, re-connect three cables and then put bottom cover back by screwing two screws as shown below. Remote Display Panel Installation The LCD module can be removable and installed in a remote location with an optional communication cable. Please take the follow steps to implement this remote panel installation.
  • Page 14 Step 2. Prepare your mounting holes in the marked locations as shown in the illustration below. The LCD module then can be securely mounted to your desired location. Note: Wall installation should be implemented with the proper screws to the right. .

  • Page 15: Communication Connection

    Communication Connection Serial Connection Please use the supplied serial cable to connect between the inverter and your PC. Install the monitoring software from the bundled CD and follow the on-screen instructions to complete your installation. For detailed software operation, refer to the software user manual on the bundled CD. Wi-Fi Connection This unit is equipped with a Wi-Fi transmitter.

  • Page 16: Operation

    OPERATION Power ON/OFF Once the unit has been properly installed and the batteries are connected well, simply press On/Off switch (located on the display panel) to turn on the unit. Inverter Turn-on After this inverter is turned on, WELCOME light show will be started with RGB LED BAR. The scrolling LED will light up in different colors in order about 10-15 seconds.
  • Page 17 The operation and the LCD module, shown in the chart below, includes six indicators, six function keys, on/off switch and a LCD display to indicate the operating status and input/output power information. Setting LED 2 LCD display Setting LED 1 Status indicators Function keys Function keys...

  • Page 18: Lcd Display Icons

    LCD Display Icons Icon Function description Input Source Information Indicates the AC input. Indicates the PV input Indicate input voltage, input frequency, PV voltage, charger current, charger power, battery voltage. Configuration Program and Fault Information Indicates the setting programs. Indicates the warning and fault codes. Warning: flashing with warning code.
  • Page 19 > 2.017V/cell < 1.892V/cell 1.892V/cell ~ 1.975V/cell Load < 50% 1.975V/cell ~ 2.058V/cell > 2.058V/cell Load Information Indicates overload. Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%. 0%~24% 25%~49% 50%~74% 75%~100% Mode Operation Information Indicates unit connects to the mains. Indicates unit connects to the PV panel.

  • Page 20: Lcd Setting

    LCD Setting General Setting ” After pressing and holding “ button for 3 seconds, the unit will enter the Setup Mode. Press “ ” or “ ” button to select setting programs. Press “ ” button to confirm you selection or “ ”...
  • Page 21 60A (default) Appliances (default) If selected, acceptable AC input voltage range will be within 90-280VAC. AC input voltage range If selected, acceptable AC input voltage range will be within 170-280VAC. AGM (default) Flooded User-Defined If “User-Defined” is selected, battery charge voltage and low DC cut-off voltage can be set up in Battery type program 26, 27 and 29.
  • Page 22 Restart disable (default) Restart enable Auto restart when overload occurs Restart disable (default) Restart enable Auto restart when over temperature occurs 50Hz (default) 60Hz Output frequency 220V 230V (default) Output voltage 240V Maximum utility charging 30A (default) current Note: If setting value in program 02 is smaller than that in program in 11, the inverter will apply charging...
  • Page 23 46V (default) Setting voltage point back to utility source when selecting “SBU” (SBU priority) in program 01.
  • Page 24 Battery fully charged 54V (default) Setting voltage point back to battery mode when selecting “SBU” (SBU priority) in program 01.
  • Page 25 If this inverter is working in Line, Standby or Fault mode, charger source can be programmed as below: Solar first Solar energy will charge battery as first priority. Utility will charge battery only when solar energy is not available. Solar and Utility (default) Solar energy and utility will charge battery at the same time.
  • Page 26 Stay at latest screen If selected, the display screen will stay at latest screen user finally switches. Backlight on (default) Backlight off Backlight control Alarm on (default) Alarm off Beeps while primary source is interrupted Bypass disable (default) Bypass enable Overload bypass: When enabled, the unit will transfer to line mode if...
  • Page 27 default: 54.0V Floating charging voltage If self-defined is selected in program 5, this program can be set up. Setting range is from 48.0V to 62.0V. Increment of each click is 0.1V. Single: This inverter is used Parallel: This inverter is operated in in single phase application.
  • Page 28 default: 58.4V Battery equalization voltage Setting range is from 48.0V to 62.0V. Increment of each click is 0.1V. 60min (default) Setting range is from 5min to 900min. Increment of each click is 5min. Battery equalized time 120min (default) Setting range is from 5min to 900 min.
  • Page 29 If selected, the maximum Disable (Default) discharge current limits protection is disabled. It will be protected by overload. The setting range is from 30 A to 150 A. Increment of each click is 10A. Setting to limit maximum Max. discharging current discharge current.
  • Page 30 High Scrolling Breathing RGB LED effects Solid on C01: Violet-White-Sky blue C02 default: White-Yellow-Green Color of RGB LED to show energy source: Grid-PV-Battery Not reset (Default) Reset Erase all data log 3 minutes 5 minutes Data log recorded interval *The maximum data log number is 1440.
  • Page 31 30 minutes 60 minutes For minute setting, the range is from 0 to 59. Time setting – Minute For hour setting, the range is from 0 to 23. Time setting – Hour For day setting, the range is from 1 to 31. Time setting–...
  • Page 32 Step 2: Press “ ”, “ ” or “ ” button to enter the selectable setting programs (detail descriptions in Step 3).. Step 3: Please select setting program by following the procedure. Program# Operation Procedure LCD Screen This function is to upgrade inverter firmware. If firmware upgrade is needed, please check with Upgrade your dealer or installer for detail instructions.
  • Page 33 Error message for USB On-the-Go functions: Error Code Messages No USB disk is detected. USB disk is protected from copy. Document inside the USB disk with wrong format. If any error occurs, error code will only show 3 seconds. After three seconds, it will automatically return to display screen.
  • Page 34 3. Timer Setting for the Charger Source Priority This timer setting is to set up the charger source priority per day. Procedure LCD Screen Step 1: Press and hold “ ” button for 3 seconds to enter Timer Setup Mode for charging source priority.

  • Page 35: Lcd Display

    LCD Display The LCD display information will be switched in turn by pressing the “UP” or “DOWN” button. The selectable information is switched as the following table in order. Selectable information LCD display Input Voltage=230V, output voltage=230V Input voltage/Output voltage (Default Display Screen) Input frequency=50Hz Input frequency...
  • Page 36 PV1 current = 2.5A (dual input model) PV2 current = 2.5A (dual input model) PV power = 500W PV1 power = 500W (dual input model) PV power PV2 power = 500W (dual input model)
  • Page 37 AC and PV charging current=50A PV charging current=50A Charging current AC charging current=50A AC and PV charging power=500W PV charging power=500W Charging power AC charging power=500W Battery voltage=51V, output voltage=230V Battery voltage and output voltage...
  • Page 38 Output frequency=50Hz Output frequency Load percent=70% Load percentage When connected load is lower than 1kVA, load in VA will present xxxVA like below chart. Load in VA When load is larger than 1kVA (≧1KVA), load in VA will present x.xkVA like below chart. When load is lower than 1kW, load in W will present xxxW like below chart.
  • Page 39 This PV Today energy = 3.88kWh, Load Today energy= 9.88kWh. PV energy generated today and Load output energy today This PV month energy = 388kWh, Load month energy= 988kWh. PV energy generated this month and Load output energy this month. This PV year energy = 3.88MWh, Load year energy = 9.88MWh.

  • Page 40: Operating Mode Description

    Main CPU version 00014.04. Main CPU version checking. Secondary CPU version 00012.03. Secondary CPU version checking. Secondary Wi-Fi version 00000.24. Secondary Wi-Fi version checking. Operating Mode Description Operation mode Description LCD display Charging by utility and PV energy. Charging by utility. Standby mode Note: No output is supplied by the...
  • Page 41 Operation mode Description LCD display Charging by utility and PV energy. Charging by utility. Fault mode Note: *Fault mode: Errors are PV energy and utility can caused by inside circuit error charge batteries. or external reasons such as over temperature, output Charging by PV energy.
  • Page 42 Operation mode Description LCD display If either “SUB” (solar first) or “SBU” is selected as output source priority and battery is not connected, solar energy and the utility will provide the loads. The unit will provide output power from the mains. It will Line Mode also charge the battery at line mode.

  • Page 43: Faults Reference Code

    Faults Reference Code Fault Code Fault Event Icon on Fan is locked when inverter is off. Over temperature Battery voltage is too high Battery voltage is too low Output short circuited. Output voltage is too high. Overload time out Bus voltage is too high Bus soft start failed PV over current PV over voltage...

  • Page 44: Warning Indicator

    Warning Indicator Warning Warning Event Audible Alarm Icon flashing Code Beep three times every Fan is locked when inverter is on. second Over temperature None Battery is over-charged Beep once every second Low battery Beep once every second Overload Beep once every 0.5 second Output power derating Beep twice every 3 seconds PV energy is low.

  • Page 45: Battery Equalization

    BATTERY EQUALIZATION Equalization function is added into charge controller. It reverses the buildup of negative chemical effects like stratification, a condition where acid concentration is greater at the bottom of the battery than at the top. Equalization also helps to remove sulfate crystals that might have built up on the plates. If left unchecked, this condition, called sulfation, will reduce the overall capacity of the battery.

  • Page 46: Specifications

    SPECIFICATIONS Table 1 Line Mode Specifications MODEL SP7000 Handy Ultra Input Voltage Waveform Sinusoidal (utility or generator) Nominal Input Voltage 230Vac 170Vac±7V (UPS) Low Loss Voltage 90Vac±7V (Appliances) 180Vac±7V (UPS); Low Loss Return Voltage 100Vac±7V (Appliances) High Loss Voltage 280Vac±7V High Loss Return Voltage 270Vac±7V...
  • Page 47 Table 2 Inverter Mode Specifications MODEL SP7000 Handy Ultra Rated Output Power 7200W Output Voltage Waveform Pure Sine Wave Output Voltage Regulation 230Vac±5% Output Frequency 60Hz or 50Hz Peak Efficiency Overload Protection 100ms@≥205% load;5s@≥150% load; 10s@110%~150% load Surge Capacity 2* rated power for 5 seconds...
  • Page 48 Table 3 Charge Mode Specifications Utility Charging Mode MODEL SP7000 Handy Ultra Charging Current (UPS) @ Nominal Input Voltage Flooded 58.4 Battery Bulk Charging Voltage AGM / Gel 57.6 Battery Floating Charging Voltage 55.2Vdc Overcharge Protection 66Vdc Charging Algorithm 3-Step...
  • Page 49 Table 4 General Specifications MODEL SP7000 Handy Ultra Safety Certification Operating Temperature Range -10°C to 50°C Storage temperature -15°C~ 60°C Humidity 5% to 95% Relative Humidity (Non-condensing) Dimension 142.5x 308 x477.5 (D*W*H), mm Net Weight, kg 11.3 Table 5 Parallel Specifications (Parallel model only)

  • Page 50: Trouble Shooting

    TROUBLE SHOOTING Problem LCD/LED/Buzzer Explanation / Possible cause What to do Unit shuts down LCD/LEDs and buzzer automatically will be active for 3 The battery voltage is too low 1. Re-charge battery. during startup seconds and then (<1.91V/Cell) 2. Replace battery. process.

  • Page 51: Appendix I: Parallel Function (Parallel-Able Models Only)

    Recommended AC input and output cable size for each inverter: Model AWG no. Torque SP7000 Handy Ultra 8 AWG 1.4~ 1.6 Nm You need to connect the cables of each inverter together. Take the battery cables for example: You need to use a connector or bus-bar as a joint to connect the battery cables together, and then connect to the battery terminal.
  • Page 52 SP7000 Handy Ultra 250A/70VDC *If you want to use only one breaker at the battery side for the whole system, the rating of the breaker should be X times current of 1 unit. “X” indicates the number of inverters connected in parallel.
  • Page 53 Three inverters in parallel: Power Connection Communication Connection Four inverters in parallel: Power Connection Communication Connection...
  • Page 54 Five inverters in parallel: Power Connection Communication Connection Six inverters in parallel: Power Connection Communication Connection...
  • Page 55 4-2. Support 3-phase equipment Two inverters in each phase: Power Connection Communication Connection Four inverters in one phase and one inverter for the other two phases: Power Connection Communication Connection...
  • Page 56 Three inverters in one phase, two inverters in second phase and one inverter for the third phase: Power Connection Communication Connection Three inverters in one phase and only one inverter for the remaining two phases: Power Connection Communication Connection Two inverters in two phases and only one inverter for the remaining phase:...
  • Page 57 Power Connection Communication Connection Two inverters in one phase and only one inverter for the remaining phases: Power Connection Communication Connection One inverter in each phase:...
  • Page 58 Power Connection Communication Connection WARNING: Do not connect the current sharing cable between the inverters which are in different phases. Otherwise, it may damage the inverters. 5. PV Connection Please refer to user manual of single unit for PV Connection. CAUTION: Each inverter should connect to PV modules separately.
  • Page 59 6. LCD Setting and Display Setting Program: Program Description Selectable option Single When the unit is operated alone, please select “SIG” in program 28. When the units are used in parallel Parallel for single phase application, please select “PAL” in program 28. Please refer to 5-1 for detailed information.
  • Page 60 Fault code display: Fault Code Fault Event Icon on Power feedback protection Firmware version inconsistent Current sharing fault CAN fault Host loss Synchronization loss Battery voltage detected different AC input voltage and frequency detected different AC output current unbalance AC output mode setting is different Code Reference: Code Description...
  • Page 61 automatically restart. If detecting AC connection, they will work normally. LCD display in Master unit LCD display in Slave unit Step 5: If there is no more fault alarm, the parallel system is completely installed. Step 6: Please switch on all breakers of Line wires in load side. This system will start to provide power to the load.
  • Page 62 8. Trouble shooting Situation Solution Fault Fault Event Description Code Restart the inverter. Check if L/N cables are not connected reversely in all inverters. For parallel system in single phase, make sure the sharing are Current feedback into connected in all inverters. the inverter is For supporting three-phase system, make sure the sharing cables are detected.

  • Page 63: Appendix: Bms Communication Installation

    Appendix II: BMS Communication Installation 1. Introduction If connecting to lithium battery, it is recommended to purchase a custom-made RJ45 communication cable. Please check with your dealer or integrator for details. This custom-made RJ45 communication cable delivers information and signal between lithium battery and the inverter.
  • Page 64 3. Installation and Operation After configuration, please install LCD panel with inverter and Lithium battery with the following steps. Step 1. Use custom-made RJ45 cable to connect inverter and Lithium battery. Note for parallel system: 1. Only support common battery installation. 2.
  • Page 65 Step 5. Be sure to select battery type as “PYL” in LCD program 5. If communication between the inverter and battery is successful, the battery icon on LCD display will flash. Generally speaking, it will take longer than 1 minute to establish communication. Active Function This function is to activate lithium battery automatically while commissioning.
  • Page 66 successfully, buzzer beeps immediately. Battery number is changed. It probably is Press “UP” or “DOWN” key to switch LCD because communication lost between display until below screen shows. It will battery packs. have battery number re-checked and 62 warning code will be clear.
