11.2 Maintenance
There are no parts which can be repaired by the user
within this product. Contact a qualified professional to
have the product checked and repaired.
• Check the product for obvious defects such as loose,
worn or damaged parts before each use.
Tool required:
• Hexagon spanner (9)
• Allen key, 5 mm (11)
• Allen key, 6 mm (12)
• Collection bucket*
* = may not be included in the scope of delivery!
11.2.1 Oil change (Fig. 1)
ATTENTION
Product damage!
If the product is operated without oil or with too little oil
or with used oil, this can lead to product damage.
– Fill with oil before starting the machine. The product
is delivered without oil.
– Do not use used oil!
– Check the oil level before each operation.
ATTENTION
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
– Fill/empty oil only on level, paved surfaces.
– Use a filling nozzle or funnel.
– Collect drained oil in a suitable container.
– Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
– Dispose of oil as per local regulations.
Change the oil every 40-50 operating hours.
1. Place the product on a level, even surface.
2. Turn the product over.
3. Remove the sight glass (4).
Use a hexagon spanner (9).
4. Let the warm oil drain into a suitable collection bucket.
5. Top up with new oil as described in 8.2.
11.2.2 Carbon brushes (13) (Fig. 2)
ATTENTION
The carbon brushes must only be replaced by an elec-
trician.
If excessive sparks are formed, have an electrician check
the carbon brushes (13).
The electrician can use the supplied hexagon spanners
(11/12) to change the carbon brush.
12 Transport
• To transport the product, disconnect the it from the
power supply and set it up in the new position you
want to use it in.
• Allow the product to cool.
• Transport the product in its transport case.
• Protect the product from impacts, shocks and severe
vibrations, e.g. during vehicular transport.
• Secure the product to prevent it slipping and toppling.
13 Storage
Store the product and its accessories in a dark, dry and
frost-free place that is inaccessible to children.
The optimum storage temperature is between 5°C and
30˚C.
Store the product in its original packaging.
Cover the product to protect it from dust or moisture.
Store the operating manual with the product.
14 Repair and ordering spare parts
After repairs or maintenance, make sure that all safety-re-
lated parts are installed and are in perfect condition. All
parts which may cause injury must be kept where they
are inaccessible to children or others.
ATTENTION
According to the German Product Liability Act, no liabili-
ty is accepted for damage caused by improper repairs
or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialists. The same applies to
accessory parts.
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the front
page.
Connections and repairs
Connections and repair work on the electrical equipment
may only be carried out by electricians.
14.1 Ordering spare parts
Please provide the following information when ordering
spare parts:
• Model designation
• Item number
• Type plate data
Spare parts / accessories
Flat chisel – Article no.:
Pointed chisel – Article no.:
14.2 Service information
With this product, it is necessary to note that the following
parts are subject to natural or usage-related wear, or that
the following parts are required as consumables.
Wearing parts*: chisels, carbon brushes
* = may not be included in the scope of delivery!
www.scheppach.com
3908201108
3908201109
