C.H110M-T PLUS V21
Colorful Technology Website:
http://www.colorful.cn
Thanks for purchasing Colorful series motherboard. This series of motherboards provides excellent performance and quality
assurance.
C.H110M-T PLUS V21 motherboard based on Intel H110 Chipset, support Intel LGA1151 processors, support dual channel
DDR4 2133/2400MHz memory, support PCI-E 3.0 standard.
The motherboard provides 1*HDMI port、1*VGA port、2*DDR4 memory slots、4*SATA3.0 ports、6*USB2.0&4*USB3.0
ports(including the header)、 onboard 6-CH audio chipset、 onboard 1000M LAN chipset, it's a Cost-effective motherboard !
The motherboard provides 1*PCI Express3.0 x16 slot、1*PCI Express x1 slots,it had good extensibility !
1.1.Packing Contents
1* Colorful C.H110M-T PLUS V21 motherboard
2* SATA cables
1* Driver/Utility CD
1* User's Guide
1* I/O shield
1.2.MOTHERBOARD SPEC
CPU
·support Intel LGA1151 processors
Chipset
·Intel H110
・Dual-Channel DDR4 2133/2400MHz support
Main
·Offer 2 DIMM slots
Memory
・1*PCI Express 3.0 x16 slot
Slots
·1*PCI Express x1 slot
Storage
·4*SATA3.0 port
USB
・4*USB3.0+6*USB2.0(including the header)
・2*PS/2 Mouse/ Keyboard ports
Rear IO
Connector
・1*LAN(RJ45) port
・2*USB 2.0 ports
・2*USB 3.0 ports
・6-Channel Audio I/O
・1*VGA Port
·1*HDMI Port
・1*24-pin ATX Power connector
・1* 4-pin ATX 12V Power connector
・1*9-pin Front panel audio connector(F_AUDIO)
・1*System panel connector(FPANEL)
・2*USB2.0 headers(FUSB1,FUSB2)
Other
・1*USB3.0 header(F_SUSB1)
Connectors
・1*PC speaker connector(SPEAK)
・1*Debug card connector(JLPC)
・1*COM header(JCOM)
・1*CMOS jumper(JBAT)
・1*ME header(JME)
·2*FANs headers(CFAN1,SFAN1)
High
・Onboard 6-channel High Definition audio chipset
Definition
·Support 3D surround sound
Audio
・Onboard 1000M LAN
Onboard
LAN
·Provides 10/100/1000Mb Ethernet

Advertisement

loading
Need help?

Need help?

Do you have a question about the C.H110M-T PLUS V21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Colorful C.H110M-T PLUS V21

  • Page 1 Thanks for purchasing Colorful series motherboard. This series of motherboards provides excellent performance and quality assurance. C.H110M-T PLUS V21 motherboard based on Intel H110 Chipset, support Intel LGA1151 processors, support dual channel DDR4 2133/2400MHz memory, support PCI-E 3.0 standard. The motherboard provides 1*HDMI port、1*VGA port、2*DDR4 memory slots、4*SATA3.0 ports、6*USB2.0&4*USB3.0 ports(including the header)、...
  • Page 2 1.3.Motherboard Layout 1、PS/2 Mouse/ Keyboard port 2、Connect to HDMI monitor 3、Connect to VGA monitor 4、Connect to USB3.0 devices 5、Connect to USB2.0 devices and LAN 6、Audio devices 7、Fan connector(CFAN1,SFAN1) 8、4-pin Power connector 9、Intel LGA1151 socket 10、DIMM slots 11、24-pin ATX Power connector 12、USB 3.0 header 13、SATA3.0 ports 14、PCI Express 3.0 X16 slot, for VGA Card...
  • Page 3 2.1.Safety Instructions To reduce the risk of fire, electric shock, and injury, always follow basic safety precautions. Remember to remove power from your computer by disconnecting the AC main source before removing or installing any equip- ment from/to the computer chassis. 2.2.Preparing the Motherboard The motherboard shipped in the box does not contain a CPU or memory.
  • Page 4 The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! 2.3.Installing Memory DIMMs Your new motherboard has 2 slots for DDR4 memory. They support dual channel DDR4 memory technology. There must be at least one memory bank populated to ensure normal operation.
  • Page 5 2.5.Installing the I/O Shield The motherboard kit comes with an I/O shield that is used to block radio frequency transmissions, protects internal components from dust and foreign objects, and promotes correct airflow within the chassis. Before installing the motherboard, install the I/O shield from the inside of the chassis. Press the I/O shield into place and make sure it fits securely.
  • Page 6 2.7.2.ATX power connectors (24-pin ATXPWR, 4-pin ATX12V) These connectors are for an ATX power supply. The plugs from the power supply are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. 2.7.3.Serial ATA 3.0 6Gb/s connectors (7-pin) These connectors connect to Serial ATA 3.0 6Gb/s hard disk drives and optical drives via Serial ATA 3.0 6Gb/s signal cables.
  • Page 7 Parts PS/2 Mouse/ Keyboard Connectort This connector is for a PS/2 mouse/Keyboard. The standard RJ-45 jack is for connection to single Local Area Network (LAN). LAN Jack You can connect a network cable to it. Lie-In(Blue) Used for external CD player, tape player or other audio devices. Line Out(Green) This connector for speakers or headphones.
  • Page 8 2.7.8.System panel connector This connector supports several chassis-mounted functions. System power LED (2-pin PLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. Hard disk drive activity LED (2-pin IDE_LED) This 2-pin connector is for the HDD Activity LED.
  • Page 9 2.7.10.CPU, Chassis, and Power fan connectors (4-pin CPU_FAN, 3-pin PWR_FAN) Connect the fan cables to the fan connectors on the motherboard, making sure that the black wire of each cable matches the ground pin of the connector. 2.7.11.COM header:JCOM This COM header is for COM serial devices. 2.7.12.ME header:JME Intel Management Engine Interface,it is Intel management engine driven, is a heat management driver launched by Intel for its desktop series chipset.When you start the machine, Using a jumper cap or a metal short JME header in seconds, the ME...
  • Page 10 Clear CMOS PROCEDURE You can clear CMOS by shorting 1-2 pin. Before you clearing the CMOS, following next procedure: 1.Turn off the AC power supply and connect pins 1 and 2 together using the jumper cap. 2.Return the jumper setting to normal (pin 2) or Remove the jumper cap 3.Turn the AC power supply back on.
  • Page 11 F9: Optimized Defaluts Network Device BBS F10: Save&Exit Priorities ESC/Right Click: Exit CSM parameters 4.Copyright Notice Copyright This motherboard manual belongs to Colorful Technology and Development CO, LTD. No one is permitted to copy, change, or translate without our written permission.
  • Page 12 Disclaimer The products name we mentioned in this manual is only for identifying, all of the brands belong to other company. The registered trademarks of IBM, VGA and PS/2 belong to International Business Machines. The registered trademarks of Intel, Pentium, Pentium Ⅱ, Celeron, Pentium III and Pentium 4 belong to Intel. The registered trademark of Athlon belongs to Advanced Micro Devices, Inc.
