Table 1: Controls, Connectors, and Indicators (Cont)
BANDWIRTH Upper Bandwidth Selector. The Upper Bandwidth Selector reduces electrical
interference by limiting the frequency response of the amplifier to FULL (1 MHz),
100Hz | 100 kHz, 3 kHz, or 100 Hz.
4O00kHz |
FULL |
Output Connector. The output connector contains connections for the TEXPROBE
interface and signal output.
Determining the Effective Volts/Division
If your oscilloscope cannot read the scale factor information, see Table 2 to
determine the effective volts/division setting. The effective volts per division is
the volts per division setting of the oscilloscope divided by the gain setting of
the ADA4OOA Differential Preamplifier. For example, if the volts/division
setting on the oscilloscope is 500 mV/division and the gain setting is [0, the
Table 2: Effective Volts Per Division Settings
Effective Volts Per Division
Scope Volts/Div | Gain = 1 Gain =1 Gain = 10 Gain = 100
1 10 1 100m 10m
500 m 5 500 m 50m 5m
200 m 2 200m 20m 2m
100m 1 100m 10m im
50m 500m 50m 5m 500
20m 200m 20m 2m 200 U
10m 100m 10m im 100 UW
5m 50m 5m 500 50M
2m 20m 2m 200 [1 20
im 10m tm 100 2 10
8 ADA4OOA Instruction Manual
